Heavy Metals Special Topic: Tributyltin

1
Heavy Metals Special TopicTributyltin

• BIOL4000/5000
• Topic 11

2
Learning goals

• To understand sources and environmental fate of
  tributyltin
• To learn mechanisms of endocrine disruptors using
  TBT as an example
• To understand the general mechanism of EPA
  criteria for water quality

3
Sources of TBT in the biosphere
4
Organotins

• Stabilizers of plastics
• Biocides
• Fungicide
• Insecticide
• Bactericide
• Anti-fouling paints

5
(No Transcript)
6
Negative effects of fouling

• Increases drug
• Reduces speed
• Increases fuel consumption
• Requires frequent (and expensive) cleaning and
  re-painting

7
Antifouling paints

• Copper-containing
• Mercury-containing
• 1970-1980 TBT-containing

8
Tributyltin (TBT)
9
Anti-fouling effects of TBT
Image by M T Chemicals Inc., Woodbridge, NJ.
10
TBT in the environment

• Slow biodegradation
• Up to 5 month under aerobic conditions and 1-2
  month under anaerobic conditions
• Accumulates in water and sediment
• Marinas
• Harbours
• Bioaccumulation

11
Environmental TBT concentrations are correlated
with navigational activity
Strand Asmund (2003)
12
Imposex
13
Morphology of imposex in snails
14
Imposex as a biomarker for TBT pollution

• Experimental studies show direct causal link
  between TBT exposure and the incidence of imposex
• Field studies show strong correlation between TBT
  concentration and the incidence of imposex
• Easy to score
• U.K. and Canada community-based biomonitoring
  programs

15
Mechanisms of TBT-induced imposex
16
Steroid hormone metabolism
TBT
P450 aromatase
17
TBT disrupts hormonal balance in shellfish
Ruditapes decussatus
Testosterone levels
Rates of conversion of testosterone to estrogens
Morcillo Porte 2000
18
Shell chambering in oysters
19
Is it all just about shellfish?

• For as wisdom grows, vexation grows To
  increase learning is to increase heartache.
• Ecclesiastes, 1 18

20
Vertebrates Fish
21
TBT causes masculinization in fish
TBT (ng/L)
Fish exposed to TBT from hatch for 70 days
McAllister Kime, 2003
22
TBT effects on Danio rerio
Control
1 ng/L
100 ng/L
McAllister Kime, 2003
23
In human cells, TBT inhibits P450 aromatase
expression
Saitoh et al., 2001
24
and activity!
Saitoh et al., 2001
25
As a result, there are less female hormones
produced
Saitoh et al., 2001
26
EPA Major steps for setting criteria for TBT in
water

• Standard chronic and acute toxicity tests
• LC50 or EC50 ? Final Acute Value
• Chronic toxicity limits ? Final Chronic Value
  (0.0658 ?g/L for saltwater)
• Weight of Evidence Considerations
• Lowering criteria if sound scientific evidence
  indicates that adverse effects may be expected on
  important species
• Imposex in snails at lower TBT concentrations
  than FCV
• Bioaccumulation and bioconcentration
• Immune effects in oysters

27
(No Transcript)
28
Current EPA water quality criteria for TBT

• Based on Section 304 (a) (1) of Clean Water Act
• Freshwater standards (not to be exceeded more
  than once in 3 years)
• Chronic 0.072 ?g/L (4-day averages)
• Acute 0.46 ?g/L (hourly averages)
• Saltwater standards (not to be exceeded more than
  once in 3 years)
• Chronic 0.0074 ?g/L (4-day averages)
• Acute 0.42 ?g/L (hourly averages)

29
Are there environment-friendly alternatives to
TBT?
30
TBT good old antifouling paints
www.ortepa.org
31
Self-polishing resins Better coats for more
controlled release
www.ortepa.org
32
Alternative solutions Silicon-based foul release
coating
www.dt.navy.mil
33
Foul release coating systems
www.dt.navy.mil
34
(No Transcript)
35
How Does Fouling Happen?
36
Australian red seaweed, Delisea pulchra
37
Bacterial Abundance onCo-occurring Seaweeds
Sargassum sp. Delisea pulchra
38
Inhibition of Pigment in Chromobacterium violaceum
39
Halogenated Furanones
Halogenated furanones from Delisea pulchra
Acylated homoserine lactones
40
Furanones Penetrate Biofilms, Prevent Signalling
and Cause Detachment
no addition
5 µg/ml C56
10 µg/ml C56
Day 1
Day 4
Day 6
Day 10
41
Does This Actually Work?
42
Field trial, furanones in polymers ( 5 months)
43
Advantages of furanones

• Non-toxic to humans and aquatic wildlife
• Does not persist in the environment
• No possibility of resistance development
• Low effective does (µg/L)
• Can be incorporated into polymers (plastics and
  paints)
• Water soluble
• Cost effective

44
Other Uses

• New class of antibiotics
• Use in contact lens and catheters
