Title: Quantum Cryptography


1
Quantum Cryptography
  • Brandin L Claar
  • CSE 597E
  • 5 December 2001

2
Overview
  • Motivations for Quantum Cryptography
  • Background
  • Quantum Key Distribution (QKD)
  • Attacks on QKD

3
Motivations
  • Desire for privacy in the face of unlimited
    computing power
  • Current cryptographic schemes based on unproven
    mathematical principles like the existence of a
    practical trapdoor function
  • Shors quantum factoring algorithm could break
    RSA in polynomial time
  • Quantum cryptography realizable with current
    technology

4
Photons
  • Photons are the discrete bundles of energy that
    make up light
  • They are electromagnetic waves with electric and
    magnetic fields represented by vectors
    perpendicular both to each other and the
    direction of travel
  • The behavior of the electric field vector
    determines the polarization of a photon

5
Polarizations
  • A linear polarization is always parallel to a
    fixed line, e.g. rectilinear and diagonal
    polarizations
  • A circular polarization creates a circle around
    the axis of travel
  • Elliptical polarizations exist in between

6
The Poincaré Sphere
z
  • Any point resting on the surface of the unit
    sphere represents a valid polarization state for
    a photon
  • The x, y, and z axes represent the rectilinear,
    diagonal, and circular polarizations respectively

(0,0,1)
(-1,0,0)
(0,1,0)
(0,-1,0)
y
(1,0,0)
x
(0,0,-1)
7
Bases
  • Diametrically opposed points on the surface of
    the sphere form a basis
  • Here, P,-P and Q,-Q represent bases
  • Bases correspond to measurable properties
  • Conjugate bases are separated by 90?

z
P
-Q
y
Q
-P
x
8
Quantum Uncertainty
  • Quantum mechanics is simply the study of very
    small things
  • Heisenburgs uncertainty principle places limits
    on the certainty of measurements on quantum
    systems
  • Inherent uncertainties are expressed as
    probabilities

9
Measuring Polarization
z
  • Imagine a photon in state Q, measured by P,-P
    where ? is the angle between P and Q
  • It behaves as P with probability

P
y
Q
  • It behaves as -P with probability

-P
x
10
Measuring Polarization
  • This phenomenon produces some interesting
    behavior for cryptography
  • Prob(P) Prob(-P) 1
  • If ? is 90? or 270?, Prob(P) Prob(-P) .5
  • If ? is 0? or 180?, Prob(P) 1

z
P
y
Q
-P
x
11
Properties for Cryptography
  • Given 2 conjugate bases, a photon polarized with
    respect to one and measured in another reveals
    zero information
  • Dirac this loss is permanent the system jumps
    to a state of the measurement basis
  • Only measurement in the original basis reveals
    the actual state

12
Key to Quantum Cryptography
z
  • Imagine a bit string composed from 2 distinct
    quantum alphabets
  • It is impossible to retrieve the entire string
    without knowing the correct bases
  • Random measurements by an intruder will
    necessarily alter polarization resulting in
    errors

1
(0,0,1)
(-1,0,0)
0
(0,1,0)
(0,-1,0)
y
(1,0,0)
1
x
0
(0,0,-1)
13
History
  • Conjugate Coding, Stephen Wiesner (late 60s)
  • CRYPTO 82 Quantum Cryptography, or unforgeable
    subway tokens
  • Charles H. Bennett, Gilles Brassard use photons
    to transmit instead of store

14
Quantum Key Distribution
  • Experimental Quantum Cryptography, Bennett,
    Bessette, Brassard, Salvail, Smolin (1991)
  • Allows Alice and Bob to agree on a secure random
    key of arbitrary length potentially for use in a
    one-time pad

15
The Protocol
  • Communication over the Quantum Channel
  • Key Reconciliation
  • Privacy Amplification

16
The Quantum Channel
lens
free air optical path (32cm)
Wollaston prism
LED
photomultiplier tubes
pinhole
interference filter
Pockels cells
17
Basic Protocol
  • Alice sends random sequence of 4 types of
    polarized photons over the quantum channel
    horizontal, vertical, right-circular,
    left-circular
  • Bob measures each in a random basis
  • After full sequence, Bob tells Alice the bases he
    used over the public channel
  • Alice informs Bob which bases were correct
  • Alice and Bob discard the data from incorrectly
    measured photons
  • The polarization data is converted to a bit
    string (? ? 0 and ? ? 1)

18
Basic Protocol Example
? ? ? ? ? ? ? ? ?
o o o o
? ? ? ? ? ? ?
o o o
Y Y Y Y
? ? ? ?
1 0 1 1
19
Key Reconciliation
  • Data is compared and errors eliminated by
    performing parity checks over the public channel
  • Random string permutations are partitioned into
    blocks believed to contain 1 error or less
  • A bisective search is performed on blocks with
    incorrect parity to eliminate the errors
  • The last bit of each block whose parity was
    exposed is discarded
  • This process is repeated with larger and larger
    block sizes
  • The process ends when a number of parity checks
    of random subsets of the entire string agree

20
Privacy Amplification
  • A hash function h of the following class is
    randomly and publicly chosen
  • With n bits where Eves expected deterministic
    information is l bits, and an arbitrary security
    parameter s, Eves expected information on h(x)
    will be less than
  • h(x) will be the final shared key between Alice
    and Bob

21
Attacking QKD
  • Intercept/Resend Attack
  • Beamsplitting Attack
  • Estimating Eves Information

22
Intercept/Resend Attack
  • Allows Eve to determine the value of each bit
    with probability
  • At least 25 of intercepted pulses will generate
    errors when read by Bob
  • All errors are assumed to be the result of
    intercept/resend
  • Hence, a conservative estimate of Eves
    information on the raw quantum transmission
    (given t detected errors) is

23
Errors with Intercept/Resend
24
Beamsplitting Attack
  • Ideally, each pulse sent by Alice would consist
    of exactly 1 photon
  • The number of expected photons per pulse is ?
  • Eve is able to learn a constant fraction of the
    bits by splitting a pulse
  • Given N pulses, the number of bits lost to Eve
    through beamsplitting is estimated to be less
    than

25
Estimating Eves Information
  • Given a bit error rate p and a pulse intenstity
    ?, Eve is expected to learn a fraction of the raw
    key
  • Alice and Bob can estimate the number of leaked
    bits and use this to eliminate Eves information
    in the privacy amplification stage

26
Other protocols
  • Quantum Oblivious Transfer
  • Einstein-Podolsky-Rosen (EPR) effect
