Block Design Review: ONL Header Format

1
Block Design ReviewONL Header Format
Michael Wilson mlw2_at_arl.wustl.edu http//www.arl.w
ustl.edu/projects/techX
2
Revision History

• 4/10/07 (MLW)
• Released
• 4/11/07 (MLW)
• Updates from feedback at 10 April meeting

3
Header Format Inputs/Outputs
xScale
xScale
TCAM
Assoc. Data ZBT-SRAM
SRAM
32KW
HdrFmt (1 ME)
Parse, Lookup, Copy (3 MEs)
Rx (2 ME)
Mux (1 ME)
Tx (1 ME)
QM (1 ME)
NN
64KW
SRAM
32KW Each
NN
NN
NN
NN
SRAM Ring
Plugin1
Plugin2
Plugin3
Plugin4
Plugin5
SRAM
xScale
Scratch Ring
NN Ring
NN

• slide taken from ONL_NProuter.ppt

4
Header Format Inputs/Outputs
xScale
xScale
TCAM
Assoc. Data ZBT-SRAM
SRAM
32KW
HdrFmt (1 ME)
Parse, Lookup, Copy (3 MEs)
Rx (2 ME)
Mux (1 ME)
Tx (1 ME)
QM (1 ME)
NN
64KW
SRAM
32KW Each
NN
NN
NN
NN
SRAM Ring
Plugin1
Plugin2
Plugin3
Plugin4
Plugin5
SRAM
xScale
Scratch Ring
NN Ring
NN

• slide taken from ONL_NProuter.ppt

5
Contents

• Overview
• Latency Analysis
• Code Locations (Planned)
• Test Procedures (Planned)
• Implementation Status

6
Overview

• Initialization
• Initialize local table of Source MAC addresses
  for output ports
• Processing (Main Loop)
• Receive handle from QM
• Copy to output registers
• Buffer Handle (from NN ring if not chained, from
  buffer descriptor Buffer_Next otherwise)
• Destination MAC, EtherType (from buffer
  descriptor)
• Source MAC address (from local memory, indexed by
  port)
• If chained, free the header buffer
• Update Stats (index from buffer descriptor)
• Forward packet to TX
• Update TX Counters
• Header Format will be written in C, not microcode

7
Latency Analysis
Critical Path Latency360 Cycles
dl_source
Negligible cycles
Is Valid?
No
Yes
Read Buffer Descriptor
150 cycles
Read Source MAC
Is Chained
No
Yes
Write Buffer_NextNULL
Write Stats
150 cycles
150
60 cycles
60
60
dl_sink
60 cycles
8
Performance

• What is our performance target?
• To hit 5 Gb rate
• Minimum Ethernet frame 76B
• 64B frame 12B InterFrame Spacing
• 5 Gb/sec 1B/8b packet/76B 8.22 Mpkt/sec
• IXP ME processing
• 1.4Ghz clock rate
• 1.4Gcycle/sec 1 sec/ 8.22 Mp 170.3 cycles
  per packet
• compute budget (MEs170)
• 1 ME 170 cycles
• 2 ME 340 cycles
• 3 ME 510 cycles
• 4 ME 680 cycles
• latency budget (threads170)
• 1 ME 8 threads 1360 cycles
• 2 ME 16 threads 2720 cycles
• 3 ME 24 threads 4080 cycles
• 4 ME 32 threads 5440 cycles

• slide taken from ONL_NProuter.ppt

9
dl_sink Semantics

• One of my optimizations requires a change to
  dl_sink semantics. In pseudo-code
• signal_t sig1, sig2, sig3
• send_stats(stats, sig1) // 60 cycles
• free_block(hdr_buf, sig2) // 60 cycles
• dl_sink(data_buf, sig3) // 60 cycles
• wait(sig1, sig2, sig3) // 60606060
• As of 10 April Meeting, this optimization is no
  longer necessary for Header Format.
• Header Format has enough slack to skip exotic
  optimizations
• Header Format can start all of the scratch ring
  writes and then dl_sink, do the wait after
  dl_sink. PLC does not have this option, but this
  doesnt impact Header Format.

10
File locations (in /ONL_Router/)

• Code
• src/hdrFormat/ONL/hdrfmt.c
• Includes
• src/dispatch_loop/ONL/dl_source.h,c
• dl_source() and dl_sink() functions

11
Test and Validation

• All validation tests will done with 8 threads
• Header Format has no loops and only two
  conditionals. All code paths will be tested
  once.
• Invalid handle (Valid bit not set)
• Unchained packet
• Chained packet
• Need to decide correct behavior in the face of
  erroneous input (port out of range)
• Test back-pressure from TX through HdrFmt to QM
• HdrFormat will be tested at high speeds to ensure
  I/O contention is not an issue

12
Implementation Status

• Still in pseudo-code
• Working on a C-equivalent of the HdrFmt Stub as a
  framework for my implementation
• Bugs
• Doesnt compile, as there is no source yet.
• Untested
• Everything
• Optimizations not taken (but available if needed
  later)
• The Buffer_Next field of the buffer descriptor
  can be read and written back-to-back because the
  memory controller guarantees in-order execution.
  Thus, we dont need to read, check to see if we
  need to write, and then write. We can issue both
  at once and worry afterward. This wont work
  with multi-buffer payload, but neither will the
  rest of Header Format.

13
Extra Slides
14
ONL Buffer Descriptor
Buffer_Next (32b)
LW0
Buffer_Size (16b)
LW1
Reserved (4b)
Free_list 0000 (4b)
Ref_Cnt (8b)
Packet_Size (16b)
LW2
MAC DAddr_47_32 (16b)
Stats Index (16b)
LW3
MAC DAddr_31_00 (32b)
LW4
Reserved (16b)
EtherType (16b)
LW5
Reserved (32b)
LW6
Packet_Next (32b)
LW7
1 Written by Rx, Added to by Copy Decremented
by Freelist Mgr
Written by Freelist Mgr
Written by Rx
Written by Copy
Written by Rx and Plugins
Written by QM
