Data in P2P Systems

1
Data in P2P Systems

• Deepak Verma
• Sanjay prasad

2
What are P2P systems

• Every node is designed to provide some service
  that helps other nodes in the network to get
  service.
• The main goal of Peer to peer networking is to
  allow users to share files without putting them
  on central servers. They are used mainly for file
  sharing.
• P2P is not a new concept. The IP routers are peep
  to peer.

3
Client Server vs Peer-to-Peer
4
P2P System Goals

• Cost sharing/reduction.
• Improved scalability/reliability.
• Resource aggregation and interoperability
• Increased autonomy
• Anonymity/privacy
• Dynamism
• Enabling ad-hoc communication and collaboration.

5
Computer system Taxonomy
Computer Systems
Centralized Systems (mainframes, SMPs,
workstations)
Distributed Systems
Client - server
Peer to Peer
Flat
Hierarchical
pure
Hybrid
6
P2P Taxonomy
P2P systems
Distributed Computing
File sharing
Collaboration
platforms
7

• Parallelizable Parallelizable P2P applications
  split a large task into smaller sub-pieces that
  can execute in parallel over a number of
  independent peer nodes.
• Content and file management. Content and file
  management P2P applications focus on storing
  information on and retrieving information from
  various peers in the network.

8

• Collaborative Collaborative P2P applications
  allow users to collaborate, in real time, without
  relying on a central server to collect and relay
  information.

9
P2P System Architecture
tools
applications
services
Application specific Layer
Class specific Layer
scheduling
Meta-data
messaging
management
Resource aggregation
Robustness Layer
security
reliability
Locating and routing
Group Management Layer
discovery
Communication Layer
communication
10

• Communication The fundamental challenge of
  communication in a P2P community is overcoming
  the problems associated with the dynamic nature
  of peers.
• Group Management This includes discovery of
  other peers in the community and location and
  routing between those peers.
• Robustness There are three main components that
  are essential to maintaining robust P2P systems
  security, resource aggregation and reliability.

11

• Class specific application-specific components
  abstract functionality from each class of P2P
  application.
• Application specific Tools, applications, and
  services implement application-specific
  functionality, such as content file management.

12
P2P system characteristics

• Systems discover topology and maintain it.
• Systems are neither client nor server.
• Systems continually talk to each other.
• They are inherently fault tolerant.
• Systems are autonomous.

13
P2P system characteristics

• Systems have no distinguished role.
• No single point of bottleneck or failure.
• Routing will depend on service and data.
• Some applications (like Napster) are a mix of P2P
  and centralized systems.

14
P2P file sharing vs. web resource sharing

• P2P file systems are easily to set up rather than
  maintaining a web server for an ordinary user.
  Applications like Napster provide easy to use
  interface.
• P2P users can share specific type of contents
  like music, video etc.,
• Massive storage is possible because of
  distributed sharing.

15
P2P Architecture Classification

• Centralized service Location (SCL)
• Napster
• Distributed service location with flooding(DSLF)
• Gnutella
• Distributed service location with hashing(DSLH).
• CAN,pastry,Tapestry,Chord

16
Centralized Service Architecture
17
Distributed Search/Flooding
18
Distributed Search/Flooding
19
Distributed search with hash table
20
Distributed search with hash table
21
Comparison
22
Comparison

• CSL has services bottleneck
• DSLF has occasional failure to find a file
• DSLH more scalable

23
Data-Sharing P2P Systems Open Problems
24
Implementation Choices

• Topology
• How elements are put together
• From free to rigid topologies
• Data and meta-data placement
• Gnutella, super-peer networks, Chrod
• Message routing
• Query language
• Keyword-based (less expressive), SQL-like (more
  expressive)

25
Resulting properties

• Autonomy
• How, to whom and what to share, how to answer,
  etc
• Robustness
• Maintain the quality of searches with the
  presence of failures
• Efficiency
• Absolute resources consumed (processing power,
  disk storage, bandwidth, etc)
• More efficiency higher throughput
• Accuracy of answers
• Depends mostly on the query language
• Comprehensiveness
• Sometimes is not reachable (partial search)

26
Research Challenges

• Autonomy/Efficiency correlation
• Autonomy/Robustness correlation
• Finding techniques to decouple or best tradeoffs
• More autonomy but more complex sophisticated
  search alg.
• Data and meta-data replication technigues

27
Research Challenges, contd

• Quality of Service (QoS)
• Different metrics to measure (number of results,
  response time, comprehensiveness, etc)
• Problem of achieving required QoS as efficient as
  possible
• E.g., number of results is important for QoS in
  Gnutella the QoS/efficiency tradeoff
• Problem of making QoS invariable to changes of
  other factors (topology, number of nodes, etc)

28
The Lookup Problem

• The lookup problem is simple to state Given a
  data item X stored at some dynamic set of nodes
  in the system, find it.
• One approach is maintain a central database that
  maps a file name to the locations of servers that
  store file.
• The traditional approach to achieving scalability
  is to use hierarchy.
• Symmetric lookup algorithms. Unlike the
  hierarchy, no node is more important than any
  other node as far as the lookup process is
  concerned.

29
Distributed Hash Table (DHT)

• A hash-table interface is an attractive
  foundation for a distributed lookup algorithm
  because it places few constraints on the
  structure of keys or the values they name.
• The main requirements are that data be identified
  using unique numeric keys, and that nodes be
  willing to store keys for each other.

30
Distributed Hash Table (cont.)

• A DHT implements just one operation lookup(key)
  yields the network location of the node currently
  responsible for the given key.

31
Distributed Hash Table (cont.)

• Mapping keys to nodes in a load-balanced way.
• Forwarding a lookup for a key to an appropriate
  node.
• Distance function.
• Building routing tables adaptively.

32
P2P Algorithms

• Routing in One Dimensions
• Chord skiplist-like routing
• Pastry tree-like data structure.
• Routing in Multiple Dimensions
• Content-Addressable Network (CAN)

33
Example of Chord
34
Lookup in Chord

• Each node in Chord has a finger table containing
  the IP address of a node halfway around the ID
  space from it, a quarter-of-the-way, and so forth
  in power of two.
• A node forwards a query for k to the node in its
  finger table with the highest ID not exceeding k
  the ID of this node is called successor of k .

35
Lookup in Chord (cont.)

• The power-of-two structure of the finger table
  ensures that the node can always forward the
  query at least half of the remaining ID-space
  distance to k.
• As a result Chord lookups use O(logN) messages to
  resolve a query.

36
Lookup in Chord (cont.)

• Chord ensures correct lookups in the face of node
  failures and arrivals using a successor list
  each node keeps track of IP address of the next r
  nodes immediately after it in ID space.
• A query to make incremental progress in ID space
  even if many finger-table entries turn out point
  to failed or nonexistent nodes.

37
Lookup in Chord (cont.)
6
Successor(6) 0
Successor(2) 3
Finger tables and key locations for a net with
nodes 0, 1, and 3, and keys 1, 2, 6.
38
Node Joins Chord

• When a node n joins the network
• Initialize the predecessor and fingers of node n.
• Update the fingers and predecessors of existing
  nodes to reflect the addition of n.
• Copy all keys for which node n has became their
  successor to n.

39
Example for Addition
Finger tables and key locations after node 6
joins.
40
Ad-hoc networks and Peer to Peer

• Wireless adhoc networks have many similarities to
  peer to peer systems.
• No a priori knowledge.
• No given infrastructure.

41
References

• www.oreilly.com
• P2P Journal
• P2P tutorial Don Towsley
