SFI-4.1

1
SFI-4.1

• Brian Von Herzen, Ph.D.
• Xilinx Consultant, www.FPGA.com

2
OIF Electrical Interfaces

• What are the OIF Electrical Interfaces?
• SPI-5
• SFI-5
• SPI-4.2
• SPI-4.1
• SFI-4
• SPI-3

3
SFI-4

• SFI-4 (OC-192 SERDES-Framer Interface)
  OIF-PLL-02.0 Proposal for a common electrical
  interface between SONET framer and
  serializer/deserializer parts for OC-192
  interfaces)

4
System Packet Interface Level 5 (SPI-5) OC-768
System Interface forPhysical and Link Layer
Devices

• SPI-5 connects Physical to Link Layer Devices
• Fabric interface chips (FIC)
• Traffic managers
• Network processing element (NPEs)

5
SPI-5 Signals

• The SPI-5 interface uses clock forwarding between

• PHY
• Link Layer Devices
• Up to 3.125 Gbps
• 16 lanes
• 50 gigabits per sec
• OC-768 with
• 25 overspeed

6
SFI-5

• SERDES Framer Interface Level 5 (SFI-5)
  Implementation Agreement for 40Gb/s
• Interface for Physical Layer Devices

7
SPI-4.2

• System Packet Interface Level 4 (SPI-4) Phase 2
  OC-192 System Interface for Physical and Link
  Layer Devices

8
SPI-4.2 Interface for Physical and Link Layer
Devices

• Uses 16 lanes at 622 Mbps or faster

9
SPI-4.1

• System Physical Interface Level 4 (SPI-4) Phase
  1
• A System Interface for Interconnection Between
• Physical and Link Layer,
• Peer-to-Peer Entities Operating at 10 Gbps
  (OC-192).
• 64 Data Signals at
• 200 MHz

10
SPI-3

• System Packet Interface Level 3 (SPI-3) OC-48
  System Interface for Physical and Link Layer
  Devices

11
OIF Electrical Standards Benefits

• Enables Best-In-Class selection of devices that
  interoperate
• SERDES
• FEC
• Framers
• Traffic Management
• Fabric Interfaces
• System vendors can choose their favorite feature
  sets and mix and match components as needed

12
OIF Electrical Standards Benefits (continued)

• With interoperable standards, vendors can
• Mix and Match best of breed components
• Minimize the engineering to connect components
• Reduce time to market
• Enable customization using programmable logic for
  key components

13
System Design Example

• A systems vendor wanting to build an OC-768
  switch with OIF standards can select
• A customized traffic manager from FPGA Vendor X
• A framer from ASSP vendor Y
• A SERDES module from Optical Vendor Z

FPGA Vendor X
Optical Vendor Z
ASSP Vendor Y
14
OIF Electrical Standards Silicon Solutions

• A variety of Silicon implementation solutions are
  available, including
• ASSP FPGA
• ASIC
• System vendors do not get locked in to a
  proprietary solution
• OIF-compliant chips interoperate effectively to
  enable best of breed system solutions
