Kabuki 2800

1
Kabuki 2800
team Big Country presents

• a real-time digital audio effects system for
  performance

ECEN4610 Preliminary Design Review 14 September
2006
2
Agenda

• Project overview
• Architecture
• Implementation
• Risk management
• Division of labor
• Schedule

3
OVERVIEWDesign goal

• Customizeable and extensible real-time digital
  audio effects system for live performance

4
Project overviewTarget consumer

• Live performance!
• Electronic composers
• Electronic musicians
• Miced acoustic musicians

5
Project overviewCurrent status

• Kabuki 1200
• Summer 06
• Some effects
• Slider input
• No custom effects
• Slow display

6
Project overviewKabuki 2800 baseline requirements

• Computer controldisplay interface
• Support for saved presets
• Custom effects
• Time-domain base effects
• Portable

7
Project overviewKabuki 2800 secondary
requirements

• Interchangeable human input board
• FFT coprocessor for performance
• Frequency-domain effects

8
Block Diagram
Summer Progress

Kabuki 2800
9
IMPLEMENTATION

• How is it all going to work?
• Effects
• I/O Card
• Touchscreen
• Performance Module
• DSP Co-Processing

S F H
X
X X
X
X X
X X X
10
Effects (on DSK)

• Filter and Equalizer
• FIR
  IIR
• Echo Reverb
• Buffering
• Flange
• Fancy Buffering
• Granulation
• Crazy Buffering
• Pitch Time Shifting
• -FFT and/or wavelet transform
• Etc..

11
I/O Card

EMIF
Computer
Interrupts
12
I/O Card

• FPGA Altera Cyclone I/II
• 3-8ns propogation
• low-cost
• FIFO MegaFunction
• Clock Source buffered clock from EMIF

13
I/O Card

• USB
• DLP Designs USB to parallel module
• (USB Control Cores for FPGAs)
• RS-232
• MAX3232
• 1Mbit/s
• 2Tx 2Rx
• EMIF bus (drive and voltage change)
• MAX3000E
• Converts voltage levels from 1.2 lt-gt 5.5 Volts
• Mostly PCB and some Wire-Wrap

14
Performance Module

• FPGA to handle communication and device polling.
• 4-5 foot buttons
• (Directly into logic device)
• 1-2 Pedals
• Pedals act as attenuators
• Feed 5V signal
• AD7861 (ADC with 11bit resolution)
• Low speed
• PLCC 44 package
• Clock Source Crystal Oscillator (1MHz)

15
DSP Co-processorTMS3206713B-200
HPI

• 200pin HLQFP
• Not BGA!!!
• Connection
• through Host Peripheral Interface on DSK
• 192K internal SRAM
• Maybe enough!
• Clock Source
• same as DSK, 50MHz Crystal Oscillator.

16
Touch ScreenMotion Computing M1300

• Slate style tablet large screen
• Linux
• Preset Programming
• Slider Display

17
Development Structure

• Primary
• Secondary

Kabuki 2800
18
Dans Tasks

• Secondary
• Layout design and fabrication.
• Firmware

• Primary
• Software Effects
• Software Devices
• Software simulation

Kabuki 2800
19
Justins Tasks
Secondary Does No have any.

• Primary
• I/O Layout Design and Fabrication
• Firmware
• USB design and Protocols

Kabuki 2800
20
Tims Tasks

• Primary
• Performance board firmware
• layout and design

• Secondary
• USB Design and Protocols
• Device Casing

Kabuki 2800
21
Yazan Tasks

• Secondary
• Module hardware design
• Module Firmware design
• Audio effect algorithm simulation
• Audio effect algorithm
• Final packaging and Software

• Primary
• Device Casing and Fabrication
• DSK and interface Card

Kabuki 2800
22
Schedule

• Phase 1 Milestone 1, Nov. 2
• Phase 2 Milestone 2, Nov. 30
• Phase 3 Expo, Dec. 14

23
Phases

• Phase 1 Development Prototyping
• Phase 2 Integration
• Phase 3 Testing and Production

24
Performance BoardPhase 1

• FPGA configured
• FPGA boots from EEPROM
• FLASH reads/writes properly
• DSK I/O Firmware Complete
• USB tested
• RS-232 interface tested

25
Performance BoardPhase 2

• FPGA configured and tested

26
I/O BoardPhase 3

• All interfaces fully functional (RS-232, USB)
• Flash storage able to load / store presets
• I/O functions with DSK and DSP co-processor
• USB firmware interfaces with FPGA and with host
  computer
• RS-232 interface fully functioning
• Firmware completed and under testing
• Communication established with DSP coprocessor.

27
Performance BoardPhase 1

• FPGA configured and tested
• FPGA boots from EEPROM
• A/D converter tested
• Firmware in testing

28
Performance BoardPhase 2

• FPGA interfaces with I/O board
• Foot pedals generate interrupts
• A/D converter samples fader pedal

29
Performance BoardPhase 3

• FPGA interfaces with Interface Card
• All user inputs are fully functional

30
DSP Coprocessor Phase 1

• Board Layout Complete

31
DSP Coprocessor Phase 2

• Board fabricated, populated and ready for testing
• JTAG ready

32
DSP Coprocessor Phase 3

• DSP Processor is able to implement FFT and
  Wavelet Transforms
• DSP is able to communicate with I/O board and and
  co-process transforms

33
Effect Algorithms Phase 1

• Time Domain Effects Simulated
• Phasing
• Filters
• Etc.

34
Effect Algorithms Phase 2

• Most time domain effects simulated
• Several more time domain effects implemented
• FFTs simulated in Matlab

35
Effect Algorithms Phase 3

• Time Domain effects implemented
• FFT and Wavelet Domain effects simulated and
  implemented

36
RISKS AND CONTINGENCY PLAN

• Sources of Risk
• USB interface
• RS-232 interface
• DSP co-processor
• Touch-screen interface

37
USB FIFO Interface

• RISKS
• Needs Windows DLLs to be recognized
• Must interface with FPGA
• Timing
• CONTINGENCY PLAN
• USE RS-232
• USE Preprogrammed Flash Memory

38
RS-232 Interface

• RISKS
• Communication is not fast enough
• Timing
• CONTINGENCY PLAN
• Make the performance board stackable on top of
  the existing DSK

39
DSP co-processor

• RISKS
• Timing
• Memory
• Interface
• CONTINGENCY PLAN
• Eliminate effects that need extensive FFT /
  wavelet processing
• Use the existing DSK to implement transforms

40
Touch-screen Interface

• RISKS
• USB must work
• We must be able to access the Windows dll files
  to monitor touches
• We must be able to monitor touches on the screen
  in real-time
• CONTINGENCY PLAN
• Use sliders / faders
