File Handling

1
File Handling

• CSE 203 Lecture 7
• Annatala Wolf

2
Static Data

• Most games make use of large amounts of static
  data! Examples
• A game map or screen
• Sprites of characters and enemies
• Dialogue in the form of text boxes
• Locations and amounts of treasure
• Generally, the only time static data isnt used
  is when the data is produced randomly, or from
  user inupt

3
Managing Static Data

• There are two ways to handle static data
• 1) Declare constants explicitly in your code.
  This is called hard-coding the data, because
  youre actually writing it into code.
• Constant mapData As Integer
• 3, 12, 9, 8, 7,
• 2) Store the data in files, and load up the data
  from files. This is more appropriate for
  handling large amounts of data.

4
Kinds of Files

• A file is just a bunch of data stored in
  permanent memory. Files are stored as binary
  numbers (strings of 0s and 1s), but files can
  appear in different formats.
• One of the most common formats is text (either as
  ASCII or Unicode), because its human
  readablebut it also wastes space (think about
  why this is).
• Anything that isnt in text format is referred to
  as being in binary format.

5
Using Text Files

• Text files are easy to work with because theyre
  human readable.
• As it turns out, text files are also the only
  files (other than images and sounds) that
  Phrogram lets you open and work with. So that
  settles that problem.
• So the big question is how can you best store
  your needed information in text format?

6
Text Conversions

• To save information as text, well need to be
  able to convert between various Phrogram types
  and String types. Specifically, we need to be
  able to turn Integer, Decimal, and Boolean into
  Strings, and then back again.
• Well store all kinds of data as Strings, but
  convert it back to Integer, Decimal, and Boolean
  when we read it.

7
Converting to String

• Converting to String is easy, because Phrogram
  does it for you automatically. (Technically this
  is a bad idea because it wont catch certain
  kinds of errors.)
• Define num As Decimal 3.1416
• Define line As String
• line num
• Print(line) // prints 3.1416

8
Converting from String

• To convert from Strings to other types, we use
  the following static functions from the Shell
  library
• ConvertToBoolean( thing-to-convert )
• ConvertToInteger( thing-to-convert )
• ConvertToDecimal( thing-to-convert )
• These operations arent smart enough to know if
  the thing youre converting is convertible until
  runtime, so they can cause errors if it cant be
  converted.

9
Conversion Examples

• Define line As String 3.14
• Define frac As Decimal
• frac ConvertToDecimal(line)
• Define bool As Boolean
• bool ConvertToBoolean(True)
• // This will produce an error!
• bool ConvertToBooloan(12)

10
FileIO Library

• To read and write text files, well use the
  FileIO Library. It includes
• TextInputFile a class that holds an input stream
  (used to read from a text file)
• TextOutputFile a class that holds an output file
  (used to write to a text file)
• Three static functions that produce TextInputFile
  and TextOutputFile objects
• FileExists( FileName As String) As Boolean a
  static method that tells you if a file exists

11
Using Text Files Directly

• Youre more likely to use text files for input
  than output. You can edit the text files
  directly, then load them into your program at the
  beginning of the game or level (whenever you need
  the data).
• To do this, you need to plan a format for your
  text file. Youll need to tell the program how
  to interpret the text it finds in the file.

12
Text File Formats

• There are two easy ways to separate data elements
  in a text file.
• Make each line a separate data element. (When
  you read from a text file, youre going to read
  in one line at a time.)
• Use a delimiting character, like a comma or a
  slash, to separate data elements. Be sure that
  the character doesnt appear elsewhere in your
  data, though!
• You can use both methods together.

13
Example Text File

• Different kinds of data can be mixed together as
  long as we know how to sort it out. For example,
  we might plan for every level of the game to take
  up three lines of text an array of Integer, a
  String, and a line with enemy info.
• We could ignore lines starting
• with , like theyre comments
• 3,4,10,-12,9,18,13,0
• Level 1 Training Mode
• 4.50,6.6,Armored Guy,3,True,True

14
Variable-Length Fields

• We may want to store a variable amount of
  information (different numbers of enemies per
  level, etc.). There are different ways to handle
  this.
• We could store the number of things at the top of
  the file or top of each section of the file, so
  well know how many things will follow.
• We could just store fields up until the end of
  the file, and look for the end of file to stop.
• We could store a bunch of data on one line,
  separated by commas or something, and then count
  the number of elements after we read it.

15
ArrayLength()

• ArrayLength() is a static function in the Shell
  library that you should be aware of. It allows
  you to determine the length of an array.
• This is important because some functions will
  return an array of variable length, and you wont
  know how long the array is unless you check.
• Define items As String
• items Split(bigText, ,)
• Define size As Integer
• size ArrayLength(items)

16
Reading Text Files

• First, we need to open the file. We can use the
  static function OpenTextFile to do this.
• Constant inFile As String L1.txt
• Define in As TextInputFile
• in OpenTextFile(inFile)
• While (Not in.EndOfFile)
• // Run some procedure we wrote
• ReadEnemy(in)
• End While
• in.Close() // always close your files

17
Closing Files

• An important note on file operations always
  remember to close your files.
• Since a file can be opened in one operation and
  closed in another, you can end up with errors
  when passing files around.
• The solution to this is to make sure the method
  that opens the file is the same one that closes
  it. Thus, responsibility for closing a file lies
  with the code that opened it.

18
TextInputFile

• (The important properties ops are in bold.)
• Created by using the static function
  OpenTextFile( Filename As String )
• Property Filename a String
• Property IsOpen a Boolean
• Property EndOfFile a Boolean
• Close() closes an open input file
• ReadLine() As String reads in next line
• ReadToEnd() As String reads in the whole
  remainder of file (not recommended)

19
Large Example

• Well use a text file which holds information
  about the starting positions of five enemies on
  the screen.
• The file format will be one line with the number
  of enemies, followed by that many enemies. Each
  enemy will consist of the following three lines
• Filename of the enemy
• Animation timeline
• Starting x, starting y, x-speed, y-speed

20
Level1.txt

• 3
• UFO.gif
• 100,100,100,100,50,50,50,50
• 0,0,100,30
• ball.jpg
• 1
• 100,120,-20,3.5
• player.gif
• 20,20,20,10,20,10
• 50,210,0,0

21
Wheres the format?

• Its important to remember that theres nothing
  magical about selecting a file format.
• In order for you to read or write files in a
  predictable way, the programmer needs to ensure
  that the format you chose is read in correctly,
  and that your data files correctly follow the
  format.
• If you do this right it can be a valuable
  time-saver. You can assume that the data is in
  the right format when you read a file, and you
  wont have to check it first.

22
GetOneSprite

• // This procedure makes one new sprite according
  to the text file.
• // Its only supposed to work if the next three
  lines in the file
• // hold data in the correct format, so we can
  assume this is true.
• Method GetOneSprite(spr As MySprite, in As
  TextInputFile)
• Define filename As String in.ReadLine()
• Define line As String in.ReadLine()
• Define words As String Split(line,,)
• Define anim As IntegerArrayLength(words)
• Define i As Integer
• For i 1 To ArrayLength(words)
• animi ConvertToInteger(wordsi)
• Next
• line in.ReadLine()
• words Split(line, ,)
• Define xPos As Decimal ConvertToDecimal(word
  s1)
• Define yPos As Decimal ConvertToDecimal(word
  s2)
• Define xSpd As Decimal ConvertToDecimal(word
  s3)
• Define ySpd As Decimal ConvertToDecimal(word
  s4)
• spr New MySprite(filename, anim, xPos,
  yPos, xSpd, ySpd)

23
First Part

• The first part of the procedure reads in two
  lines of text. We can do this without checking
  for the end of the file, because the procedure
  description requires that the next three lines of
  the input stream contain data in the right
  format. (This means its the clients
  responsibility to check the one who calls the
  op.)
• Then we split the second line into an array using
  the static Split function. Split removes the
  commas and returns an array of Strings, one for
  each space between the commas.
• Define filename As String in.ReadLine()
• Define line As String in.ReadLine()
• Define words As String Split(line,,)

24
Second Part

• We use the static ArrayLength function to get the
  length of the words array, and then we set an
  Integer array to the same length.
• Then we use a For loop to convert each String in
  words to an Integer, to create our animation
  timeline, anim.
• Define anim As IntegerArrayLength(words)
• Define i As Integer
• For i 1 To ArrayLength(words)
• animi ConvertToInteger(wordsi)
• Next

25
Third Part

• The last line of data for a sprite contains four
  values. We use Split again, and just set the
  values directly. This time we need
  ConvertToDecimal to help us.
• line in.ReadLine()
• words Split(line,,)
• Define xPos As Decimal ConvertToDecimal(words1
  )
• Define yPos As Decimal ConvertToDecimal(words2
  )
• Define xSpd As Decimal ConvertToDecimal(words3
  )
• Define ySpd As Decimal ConvertToDecimal(words4
  )

26
Final Part

• Finally, we call the constructor for our MySprite
  class. This will create a new MySprite object
  and overwrite whatever was in spr before.
• spr New MySprite(filename, anim,
• xPos, yPos, xSpd, ySpd)

27
Using Our Procedure

• Heres an example of how we might use the
  procedure to load sprites, given the data format
  we described.
• Define in As InputTextFile
• in OpenTextFile(filename)
• Define numSprites As Integer
• // Get number of enemies for this level
• numSprites ConvertToInteger(in.ReadLine())
• Define enemies As MySpritenumSprites
• // Build all enemies from input file
• Define i As Integer
• For i 1 To numSprites
• GetOneSprite(enemiesi, in)
• Next
• in.Close() // remember to close your files!

28
File Output

• You may find it valuable to be able to handle
  text file output, too
• To create save-files for a long game
• To create a logfile
• If you want to write a separate program that you
  use to build your levels (a game level editor,
  for example)
• Text file output is less likely to be useful but
  it is just as simple to do.

29
TextOutputFile

• (The important properties ops are in bold.)
• Created by using the static function
  CreateTextFile( Filename As String)
• Add new text to end of file by using the static
  function AppendTextFile(Filename As String)
• Property Filename a String
• Property IsOpen a Boolean
• Property AppendMode Boolean
• Close() closes an open input file
• Write( text As String ) writes text to file
• WriteLine( text As String ) writes, a newline

30
Output Example

• // This method of MySprite outputs the MySprite
• // data to file. It assumes the file is open.
• Method PutToFile( out TextOutputFile )
• out.WriteLine(fileName)
• Define i As Integer
• For i 1 To ArrayLength(anim)
• out.Write(animi)
• If (i lt ArrayLength(anim)) Then
• out.Write(,)
• End If
• Next
• out.WriteLine()
• out.Write(spr.X , spr.Y ,)
• out.WriteLine(xSpeed , ySpeed)
• End Method

31
First Line

• The procedure were writing assumes that the
  TextOutputFile is already open to a file and in
  the right spot to have text added, so we dont
  have to check.
• Here, fileName is a private data member of
  MySprite.
• out.WriteLine(fileName)

32
Second Line

• To output the animation timeline (which is stored
  in the private data member anim), we use Write()
  to write to the same line. (Note we avoid a
  comma at the very end, and call WriteLine() to
  end the line.)
• Define i As Integer
• For i 1 To ArrayLength(anim)
• out.Write(animi)
• If (i lt ArrayLength(anim)) Then
• out.Write(,)
• End If
• Next
• out.WriteLine()

33
Third Line

• We can use the operator to concatenate Strings
  together, to make it easier to assemble the third
  line. Here, spr, xSpeed, and ySpeed are private
  data members.
• Again, we call Write() first, then WriteLine()
  only when were ready to end the line.
• out.Write(spr.X , spr.Y ,)
• out.WriteLine(xSpeed , ySpeed)

34
Using PutToFile

• A client might use PutToFile() like so
• Define out As TextOutputFile
• out CreateFile(outputFilename)
• out.WriteLine(ArraySize(enemies))
• Define i As Integer
• For i 1 To ArraySize(enemies)
• enemiesi.PutToFile(out)
• Next
• out.Close() // remember to close

35
Your Project

• You will probably want to use one or more files
  to hold static data for your game.
• Youll probably want to edit the text files by
  hand, and load them in at the beginning of the
  game (or the beginning of each level).
• You dont need to use a complicated data format
  if a simple one will do. If its easier for you
  to use multiple lines than to use a
  comma-separated list, use multiple lines.
