Blood Glucose Sensor System

1
Blood Glucose Sensor System

• -Yashwanth Prakash

2
Application

• Establish a wireless communication link between
  an implantable glucose-sensor and a
  phone/computer for emergency/records purposes.

3
Motivation/Problem Definition

• Extreme cases of blood glucose level
• Hyperglycemia (gt110 mg/dl)
• Hypoglycemia (lt70 mg/dl)
• Sudden fluctuations of glucose level
• Unconsciousness, Permanent organ failure,
  Paralysis
• Fatality within few minutes
• Patient not able to react to the warning message
  by the glucose sensor monitor.

4
Architecture
5
Design
Sensor
Human interface
Tx
PC
Rx
DTMF
Phone
6
Conclusion

• Very useful system for saving lives.
• Simple and easy to implement with the existing
  technology.

7
Future work

• Can be extended to mobile phones to make it more
  flexible.
• Computers can be made to communicate (via
  internet) with the doctors database for records
  purpose and remote consulting.

8
Thank You !!
