Radial Compressor

1
Radial Compressor

• 11/21/2005
• Created By
• Group 5
• Caleb Moreno
• Charles Davis
• Jacob Nink

2
Table of Contents

• Abstract
• Design Criteria
• Specifications of Radial Compressor
• CAD Drawing
• Position Analysis
• Velocity Analysis
• Acceleration Analysis
• Working Model
• Results and Conclusions

3
Abstract

• Three piston radial compressor that can be broken
  down into three separate slider-cranks.
• Due to the circular arrangement only one piston
  will be compressing at a time.
• Due to similarity between all pistons, only one
  piston will be discussed for simplicity.

4
Design Criteria

• Large stroke length for increased air compression
• Piston is restricted to linear motion
• Reduced crank arm length for higher RPM operation

• Bearings and seals must be able to withstand long
  term high RPMs

5
Specifications

• Crank Arm Length 20mm
• Coupler 80mm
• Stroke Length 40mm
• Piston Size 40mm diameter x 20mm depth
• Operational RPM 1200 rpm

6
Radial Compressor Auto CAD
7
Slider Crank Diagram
8
Position, Velocity and Acceleration Data
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
Animation
(Must have Slider Program and Working Model
Installed to operate)
Link
13
Results and Conclusions

• Decided upon a short crank length of 20 mm to
  increase piston velocity. This lead to a shorter
  stroke length of 40mm for the piston but with a
  shorter crank, the piston can maintain a higher
  rpm.
• Three piston design for efficiency and heat
  reduction around each piston.
• High load bearings are required at all pins to
  withstand the high rpms of the crank arm.
• Seals must be able to take a vast amount of heat
  during operation.

14
Resources

• Video Clip http//www.tech.purdue.edu/at/Courses/A
  EML/
• Working Model of Radial Engine taken from Design
  of Machinery CD
