Drill

1
Drill Exercise Evaluation The Big Stuff
Matters Most

• Ben Blue
• Savannah River Site
• May 7

2
Background / Drivers

• During DOE Type I Assessment in January, 2007,
  the following finding was issued
• EM used checklists to evaluate emergency
  exercises that did not contain formal, objective
  evaluation and acceptance criteria.
• Grading process identified as an area for
  improvement in the 2007 Evaluated Exercise.
• Also noted by DNFSB as an area ofconcern.

3
Improvement Plan

• Developed and implemented improvement plan after
  07 Exercise
• Implemented plan as a project, subject to the
  same controls, management attention, and
  reporting
• Plan focused on
• Increasing management involvement focus
• Achieving consistent Incident Scene Command
  Control
• Improving Radcon emergency response performance
• Improving Drill and Exercise Conduct Evaluation
• Improving Emergency Management self assessment
  program
• Improving corrective action effectiveness

4
Corrective Action

• Initially, we identified those objectives we
  considered to be risk significant,
  specifically
• Safety
• Protective Actions
• Mitigation
• Emergency Classification
• Notifications Communications

5
Next Step

• The next step was to use those Risk Significant
  Objectives as critical performance items when
  grading drills and exercises.
• These objectives had to have more effect on the
  final grade than other objectives
• Simple numeric weighting was giving enough of an
  effect because of averaging.

6
Next Step, continued

• New Process developed
• Based on similar process used by military
• Objectives and supporting criteria are classified
  as
• Critical
• Major
• Minor
• Wording changed to make evaluation more objective
  (on-going effort)

7
How it Works

• Failure of a critical item immediately fails the
  next higher level
• Failing a critical criterion fails the objective
• Failing a critical objective fails the drill or
  exercise

8
How it Works, continued

• Failure of major items lowers the grade, but does
  not immediately fail the next higher level
• Failure of one major item results in next higher
  level being no better than Partially Met
• Failure of two or more major items results in
  failure of the next higher level

9
How it Works, continued

• Failure of minor items is used to drive the
  numeric grade down, but cannot cause automatic
  failure

10
Input

• Evaluators input grades at the Criteria level

11
Input, continued

• Critical and Major items are either Met or Not
  Met
• Input is based on wording of Objective or
  Criteria, supporting lines of inquiry, AND
  evaluators judgment

12
Input, continued

• Minor items are either Met, Not Met, or
  Partially Met

13
Input Converted to Numeric

• Evaluator input converted to numeric value
• Met 100
• Partially Met 75
• Not Met 50
• Numeric grades are averaged to determine an
  overall numeric grade

14
Numeric Values
15
Grading and Evaluation

• Numeric grades are applied to three tests to
  determine final rating
• Tests use the criteria grades first to determine
  the objective grades
• Objective grades are then applied to the same
  tests to determine the overall grade for the
  drill or exercise

16
Grading and Evaluation, continued

• First test is the Critical items
• Failure of one automatically fails the next level
• Second test is the Major items
• Failure of one means next level is Partially
  Met
• Failure of two or more automatically fails the
  next level

17
Grading and Evaluation, continued

• Third test is the numeric grade
• gt85 Met (Pass)
• 70 to 85 Partially Met
• lt70 Not Met (Fail)

18
Objective Grading
19
Overall Grading
20
Implementation

• Briefed evaluators and implemented process in
  January, 2008
• Beta testing evaluation tools (software) looking
  for bugs
• Getting a feel for how the process is received by
  management and players

21
Implementation, continued

• Also looking to make sure we didnt overcorrect
• Previous system (numeric only) made it very
  difficult to get the software to fail a drill
  when it should
• Wanted to be sure we didnt make it too hard to
  PASS a drill that should
• Did not see any indication of this

22
Implementation, continued

• After one month of testing, process fully
  implemented and used during remedial exercise in
  February, 2008

23
Feedback and Adjustment

• Early feedback from users (evaluators) was
  positive
• Some problems noted, but they were minor
• Took time to get used to new way of doing things
• Management is enthusiastic about logic and
  philosophy of new process

24
Benefits and Successes

• Process has provided more focus on the more
  important items relative to drill and exercise
  performance
• Previous system tended to hide problem areas by
  rolling them up into averages
• New system makes problem areas more prominent by
  directly tying poor performance in more important
  areas to lower grades

25
Mechanics and Software

• Evaluator input captured in Microsoft Access
  database
• Grades input via web browser interface
• Number crunching and evaluation performed in an
  Excel spreadsheet
• Draws data from Access, then performs
  calculations to apply three evaluation tests and
  produce evaluation report

26
Starting the Evaluation
27
Grading Report
28
Starting from Scratch

• If you have nothing in place, you will need some
  form of data collection and storage
• Off-the-shelf database programs will do this
• Most programs can also apply the three evaluation
  tests and produce the output
• We use Access and Excel because we had some
  pieces in place that we didnt want to abandon

29
Taking it Home

• The software packages are unimportant
• Almost any software can be modified to use this
  concept
• The process is the thing
• By applying the general idea, problems in the
  big ticket areas become more visible
• Fixing these areas first strengthens the
  foundation, making your entire program stronger

30
Summary

• Make the most important items have the most
  effect on the grade
• Fix these items first
• Then concentrate on smaller items
• Consider changing the process before your
  customers suggest that you do so
• Happy customers Happy EM staff
