Title: Sheet Metal Forming Processes


1
Sheet Metal Forming Processes
  • Manufacturing Processes

2
Outline
  • Introduction
  • Shearing
  • Blanking
  • Bending
  • Deep Drawing
  • Stamping Dies
  • Progressive Dies
  • Transfer Dies
  • Spinning

3
Sheet Metal Working
  • Products
  • automotive fenders
  • washers
  • stamped parts
  • channels

4
Examples of Stamped Parts
5
Examples of Stamped Parts
6
Examples of Stamped Parts
This part was made from several stamped parts
plus a nut, which were stamped again to seal them
together
7
Examples of Stamped Parts
This part was made from a sheet that was stamped,
bent, and welded into a tube, plus a separate
stamped end piece
8
Examples of Stamped Parts
9
Shearing
  • A sheet-metal cutting operation along a straight
    line between two cutting edges

10
Shearing of Metal Between Cutting Edges
11
Shearing of Metal Between Cutting Edges
1/3 of material is cut and 2/3 of material
fractures
12
Blanking
  • Involves cutting the sheet metal along a closed
    outline

13
Piercing and Blanking
  • Shearing operations in which the shear blades are
    closed, curved lines along the edges of the punch
    and die
  • In blanking, the piece punched out is the
    workpiece in piercing, the remaining strip is
    the workpiece

14
Punch and Die
15
Bending
16
Bending
17
Bending Springback
18
Deep Drawing
  • A sheet metal forming operation used to make
    hollow-shaped parts

19
Deep Drawing
20
Redrawing
  • Additional drawing steps (redrawing) may be
    required if the shape change of the material is
    too severe

21
Example of a Drawn Part
22
Example of a Deep Drawing Press
23
Stamping Die
24
Stamping Die
25
Progressive Die
  • Performs multiple operations at different
    stations with every press stroke

26
Progressive Die
27
Example of Progressively Stamped Parts
This sheet has been stamped by a progressive die,
showing the series of operations from right to
left
28
Progressive Die
29
Progressive Die
30
Progressive Die
31
Progressive Die
32
Progressive Die
33
Progressive Die
34
Examples of Stamping Machines
35
Progressive Diein Stamping Press
36
Progressive Die
37
Material Coils
38
Material Feed
39
Material Feed
40
Transfer Line
41
Transfer Line
42
Transfer Line
43
Transfer Line
44
Transfer Press
45
Transfer Press
46
Transfer Die
47
Spinning
  • Uses a spinning mandrel and a roller to form
    sheet metal into a radially symmetrical part

48
Spinning
Courtesy Koch Metal Spinning
49
Tube Spinning
  • Uses a spinning mandrel and a roller to reduce
    the wall thickness and increase the length of a
    tube

50
Summary
  • Blanking, bending, and deep drawing are capable
    of producing an immense variety of thin metal
    parts
  • Progressive dies can produce parts at high
    production rates by performing multiple
    operations simultaneously

51
