Chapter 21 Sound

1
Chapter 21 Sound
2
What is Sound

• All sounds are produced by something that
  vibrates
• A wave carries energy from one place to another
  and without transferring matter
• The vibrating object causes air molecules to move
  back and forth
• As these air molecules collide with those nearby
  , they cause other molecules to move back and
  forth
• A sound wave is a compressional wave, like a wave
  moving through a coiled spring
• In sound waves, air molecules move back and forth
  along the direction of the wave

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
Making Sound Waves

• When an object vibrates, it exerts a force on the
  surrounding air
• For example, as the end of the tuning fork moves
  outward into the air, it pushes the air molecules
  together
• As a result, a region where the air molecules are
  closer together, or more dense, is created
• This region of high density is called a
  compression
• When the tuning fork moves back it causes an area
  of low density called rarefaction
• The compression and rarefaction move away from
  the tuning fork as molecules collide with one
  another

8

• Sound waves can be described by its wavelengths
  and frequency
• Wavelength is the distance between two
  consecutive compressions or two consecutive
  rarefaction
• Frequency of a sound is the number of
  compressions or rarefactions that pass by a given
  point in one second
• The unit of frequency is the number of
  wavelengths per second, or Hertz (Hz)

9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
Speed of Sound

• Speed of sound varies because of temperature and
  material it is passing through
• Sound moves faster in solid then liquids or gases
  because the particles that makes solid up are
  closer together
• Sound is slowest in gases because molecules are
  farther apart
• As the temperature heats up its molecules move
  faster, so they collide more frequently
• More frequent the collision the faster sound
  travels
• 0 C sound travels a 331m/s, 20C 343m/s

15
(No Transcript)
16
(No Transcript)
17
Amplitude and Loudness

• Loudness is the human perception of how much
  energy a sound wave is carrying
• The amount of energy a wave carries depends on
  its amplitude
• Higher amplitude- more compressed the particles
  in a compression are and the farther they are
  spread out in a rarefaction
• Higher amplitude means more energy and louder

18
(No Transcript)
19
(No Transcript)
20
Decibel Scale

• Scale used to describe sound waves
• Increase in 10 decibels means that the energy
  carried by the wave has increased 10 times
• Increase in 20 decibels, energy increases 100
  times
• Increase in 30 decibels, energy incresed 1000x
• Hearing Damage begins to occur at 85 dB
• Jet Plane 150 dB
• Whisper 15dB
• Lawn Mower 110

21
(No Transcript)
22
(No Transcript)
23
Frequency and Pitch

• Pitch of a sound is how high or low it sounds
• Pitch corresponds with frequency of the sound
• High the pitch the higher the frequency
• Lower the pitch the lower the frequency
• Human ear can detect sound waves with frequencies
  between about 20Hz and 20,000Hz.
• Dogs can hear frequencies up to almost 50,000 Hz
• Dolphins and Bats can hear frequencies as high as
  150,000 Hz.
• Higher pitch - shorter wavelengths, Lower pitch
  Longer Wavelength
• Length and thickness of your vocal cords help
  determine your pitch
• Short thinner vocal cords vibrate at higher
  frequencies, results in higher voices
• Muscles in throat can stretch the vocal cords
  tighter, letting people vary their pitch

24
Wavelength, Frequency, and Pitch

25
(No Transcript)
26
posterior lateral


27
Echoes

• A echoes is a reflected sound wave
• Sound waves reflect off of hard surfaces
• Sonar systems use sound waves to map out objects
  underwater
• The amount of time it takes for echoes to return
  depends on how far away the reflecting surface is

• Echolocation the ability to emit high pitched
  squeaks and listen for echoes. Used to navigate
  and hunt
• Bats and dolphins use echolocation

28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34

         Dolphins produce high frequency clicks
that pass through the melon. These sound waves
bounce off objects in the water and return to the
dolphin in the form of an echo.
35
Doppler Effect

• The change in a frequency that occurs when the
  source of the sound is moving relative to a
  listener is the Doppler effect
• Occurs whether the sound source or the listener
  is moving
• As you move closer to the source you encounter
  each sound wave a little earlier
• The closer you get the higher the pitch
• When you move away , each sound wave takes longer
  to reach you, you hear fewer wavelength, which
  results in a lower pitch
• Radar guns used to determine speed of cars and
  baseballs use the Doppler Effect

36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
Diffraction

• Diffraction means that sound waves can bend
  around obstacles or spread out after passing
  through a narrow opening
• The amount of diffraction depends on the
  wavelength
• If Wavelength is much smaller than the obstacle,
  almost diffraction occurs
• If wavelength is closer or larger then the size
  of the obstacle, the amount of diffraction
  increases

40
(No Transcript)
41
(No Transcript)
42
Using Sound Waves

• Ultrasound using high frequency sound waves as
  an alternative to some surgeries
• Kidney stones and gall stone sometimes can be
  broken up using ultrasound
• Used to exam a developing fetus, and internal
  organs

43
(No Transcript)
44
(No Transcript)
45
The Ear

• The ear is a complex organ that is able to detect
  a wide range of sounds
• Has three parts
• Outer Ear
• Middle Ear
• Inner Ear

46
(No Transcript)
47

• The Outer Ear
• Collects sound waves and directs them into the
  ear canal
• Shaped like a funnel to collect sound waves
• Animals that rely on hearing to locate predators
  or pry often have large ears and can be adjusted
• Rabbits and Owls

48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
Ural Owl Ear





52
(No Transcript)
53

• The Middle Ear
• Sound waves vibrate the Eardrum
• Eardrum is a Thin membrane that stretches across
  the ear canal
• As the eardrum vibrates, it transmits vibrations
  to three small bones
• Hammer
• Anvil
• Stirrup

54

• The bones amplify (intensify) the vibrations
• Similar to how a lever can change a small
  movement at one end into a large movement at the
  other end

55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60

• Ruptured Eardrum

61

• Inner Ear
• The stirrup vibrates a second membrane called the
  oral window
• Inner ear is filled with fluid
• Vibrations are transferred to hair tipped cells
  in the cochlea
• Different sounds vibrate the hairs differently
• Cells generate signals containing information
  about the frequency, intensity, and duration of
  the sound

62

• The nerve impulse travels to the brain along the
  auditory nerve

63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
How does your ear work ?

69
(No Transcript)
70

71
Hearing Loss

• The ear can be damaged by disease, age, and
  exposure to loud sounds
• Constant exposure to loud sounds can damage the
  hair cells in the cochlea

72

• If hair cells die, hearing loss occurs because
  mammals can not produce new hair cells
• Higher frequency hearing is usually the first to
  be lost
• Soft consonants sounds such as s, f, h, sh, ch
  are hard to hear
• People with high frequency hearing loss have
  trouble distinguishing these sound during
  conversation
