Programming Language Issues for BTeV

1
Programming LanguageIssues for BTeV

• Marc PaternoCD/CPD/APS
• 1 October 2001

2
Why Use C?

• Abstractions
• OO programming classes
• generic programming templates
• Robustness
• strong type safety, catch errors at compile time
• well-defined management of object lifetimes
  necessary for resource allocation
• Speed
• comparable to C or Fortran

3
Outline

• I will assume that C is the primary language to
  be used by BTeV.
• this means I assume the Framework and EDM will be
  written in C
• Issues addressed
• C language features
• Interaction with Fortran
• Use of assembly language
• Other languages
• Java, Python, assembly language

4
Abstraction

• C provides two main mechanisms for abstraction
• classes, for object-oriented programming
• templates, for generic programming
• Placing arbitrary limits on the use of either
  weakens the ability to implement optimal designs
• The greatest strength of C lies in a correct
  combination of the two techniques

5
OO terminology

• Classes need little introduction all we need
  here is two definitions
• Class a data type, which combines a description
  of a state along with a set of functions
  associated with the manipulation of that state
• Object an instance of a class
• string is a class
• the string Hello is an object

6
Templates

• Function templates express an algorithm,
  parameterized on the type(s) of its argument(s)

sort(begin, end)

• Class templates generate a family of classes,
  parameterized on some feature

vectorltintgt bitsetlt32gt
7
Use the Standard Library

• The standard library provides a rich set of data
  structures and algorithms
• Prefer to use standard collections to third-party
  versions
• more portable
• more familiar
• Prefer to use standard algorithms to re-writing
  them yourself
• less work
• more efficiency

8
Standard Collections

• Sequences
• vector a dynamic array
• list a doubly-linked list
• deque a double-ended queue
• Sorted containers
• set, multiset ordered collections
• map, multimap associative array (dictionary)
• Designed to interoperate with the standard
  library algorithms

9
Standard Algorithms

• searching
• find, find_first_of, search,...
• manipulation of collections
• copy, erase, random_shuffle, sort, partial_sort,
  partition, ...
• operations on sets
• set_union, set_difference,...
• many others

10
Example of the simplest algorithm
vectorltThinggt v(...)// explicit loopfor (int i
0 i ! v.size() i) doWork(vi)//
standard algorithmstdfor_each(v.begin(),
v.end(), doWork)

• Even in this simple case, the standard algorithm
  has benefits
• less likely to have error in loop
  initialization/ending/advancement
• slight improvement in efficiency

11
Robustness

• Bad data happens
• A program must not crash because of it
• A program must not be left in an inconsistent
  state
• Almost any function can fail
• so every function must be checked
• What options are availablefor writing robust
  code?

12
Option 1 Pervasive tests

• Do as was done in C and Fortran
• Every function returns a status condition
• Every call must be checked

13
Example of option 1
int myfunc( ... ) int rc 0 if ((rc
f1(...) lt 0) return rc if ((rc f2(...) lt 0)
return rc // do other work, maybe resetting
rc ... return rc

• Work is obscured by the bulk of error-handling
  code
• Production-quality systems require still more
  (logging, error stack) further obscuration

14
Option 2 Exceptions

• Standard C provides a better mechanism
  exceptions
• An exception is thrown at the point where the
  exceptional condition is detected
• An exception is caught wherever that specific
  kind of exception can be dealt with
• C will clean up the call stack, releasing
  resources, during unwinding
• Beware of non-standard systems that do not
  provide strict lifetime management!

15
Example of option 2

• Using exceptions, the same functionality is
  achieved much more cleanly
• If f1( ) fails, then f2( ) is not called if f2(
  ) fails, the other work is not done

void myfunc( ... ) f1(...) f2(...) //
do other work ...
16
Use of Fortran

• Possible to support both legacy code and new
  development in Fortran
• Primary constraint do not severely compromise
  the infrastructure design to support Fortran
• otherwise, one loses the advantages for which C
  was chosen
• if full freedom for use of Fortran is required,
  Fortran should be the main language

17
Aside What is Fortran?

• Many people have experience with F77
• procedural code
• no dynamic memory allocation
• no user-defined data structures
• Fewer have experience with
• user-defined structures
• parallel programming
• dynamic memory
• F90, F95 are less widely known

18
Possible Plan for Use of Fortran

• Framework modules can be mostly Fortran, but
  require some C
• Fortran code will not be able to take advantage
  of the full power of the C infrastructure
• Fortran code will be required to follow many of
  the same policies as C code

19
Possible Plan ... continued

• Upper level of framework module must be C
• Extract data (objects) from the Event
• Fills in Fortran data structures (common blocks)
• Calls Fortran to do work
• reads from/writes to common blocks
• Wrap up again in C
• Reads from common blocks
• creates objects, puts then into the Event

20
Possible plan ... continued

• Some limitations
• C packages communicate only through the Event
• Fortran from different trigger/reconstruction
  packages communicate only through the Event
• no common blocks between packages
• common blocks can be used to share data between
  routines of the same package

21
Assembly Language

• Assembly language drawbacks
• difficult to write
• difficult to maintain
• Assembly language benefits
• fast
• allows use of special features of chips
• Use it only when the advantages are needed

22
Profile!

• Humans are notoriously poor at guessing where
  bottlenecks lie
• measure (profile) your code to identify the slow
  parts
• improve algorithms and data structures first
• implement limited assembly language where
  profiling indicates the necessity

23
Assembly guidelines

• Have a high-level (C, Fortran, C)
  implementation first
• if youve done profiling, you already have this
• use the high-level version to test correctness of
  the assembly code
• C includes mechanism for support of assembly
  code
• use your compilers support to make assembly code
  easier to use and maintain

24
Example of inline assembly code
typedef stdbitsetlt32gt flag_t inline flag_t
getCpuFeatures() flag_t result(0)_asm mov
eax, 1 cpuid mov result, edxreturn
result
25
Use of the example

• bool hasStreamingSIMD() return
  getCpuFeatures()25
• bool hasMMX() return getCpuFeatures()23

• Client code doesnt notice that getCpuFeatures(
  ) is implemented in assembly language

26
Other Languages

• Java
• Can be a great advantage where a widely-used Java
  library is available for some niche, e.g. JDBC
  for database servers
• Scripting languages
• Many are available and widely used
• Python, Ruby, Perl, Visual Basic, shells, ...
• Dont try to prevent personal use of personal
  preferences
• Choose an experiment standard only after needs
  have been assessed.
