Lecture 8 UDP Sockets

1
Lecture 8UDP Sockets I/O Multiplexing

• CPE 401 / 601Computer Network Systems

slides are modified from Dave Hollinger
2

• Lab 1 demo schedule
• Lab 1/2 Questions ???

3
UDP User Datagram Protocol RFC 768

• no frills, bare bones Internet transport
  protocol
• best effort service, UDP segments may be
• lost
• delivered out of order to app
• connectionless
• no handshaking between UDP sender, receiver
• each UDP segment handled independently of others

• Why is there a UDP?
• no connection establishment (which can add delay)
• simple no connection state at sender, receiver
• small segment header
• no congestion control UDP can blast away as fast
  as desired

4
UDP more

• often used for streaming multimedia apps
• loss tolerant
• rate sensitive
• other UDP uses
• DNS
• SNMP
• reliable transfer over UDP add reliability at
  application layer
• application-specific error recovery!

32 bits
source port
dest port
Length of UDP segment including header, in bytes,
checksum
length
Application data (message)
UDP segment format
5
UDP Sockets Programming

• Creating UDP sockets.
• Client
• Server
• Sending data.
• Receiving data.
• Connected Mode.

6
Creating a UDP socket

• int socket(int family, int type, int proto)
• int sock
• sock socket(PF_INET, SOCK_DGRAM, 0)
• if (socklt0) / ERROR /

7
Binding to well known address(typically done by
server only)

• int mysock
• struct sockaddr_in myaddr
• mysock socket(PF_INET,SOCK_DGRAM,0)
• myaddr.sin_family AF_INET
• myaddr.sin_port htons( 1234 )
• myaddr.sin_addr htonl( INADDR_ANY )
• bind(mysock, myaddr, sizeof(myaddr))

8
Sending UDP Datagrams

• ssize_t sendto( int sockfd,
• void buff,
• size_t nbytes,
• int flags,
• const struct sockaddr to,
• socklen_t addrlen)
• sockfd is a UDP socket
• buff is the address of the data (nbytes long)
• to is the address of a sockaddr containing the
  destination address.
• Return value is the number of bytes sent, or -1
  on error.

9
sendto()

• You can send 0 bytes of data!
• Some possible errors
• EBADF, ENOTSOCK bad socket descriptor
• EFAULT bad buffer address
• EMSGSIZE message too large
• ENOBUFS system buffers are full

10
More sendto()

• The return value of sendto() indicates how much
  data was accepted by the O.S. for sending as a
  datagram
• not how much data made it to the destination.
• There is no error condition that indicates that
  the destination did not get the data!!!

11
Receiving UDP Datagrams

• ssize_t recvfrom( int sockfd,
• void buff,
• size_t nbytes,
• int flags,
• struct sockaddr from,
• socklen_t fromaddrlen)
• sockfd is a UDP socket
• buff is the address of a buffer (nbytes long)
• from is the address of a sockaddr.
• Return value is the number of bytes received and
  put into buff, or -1 on error.

12
recvfrom()

• If buff is not large enough, any extra data is
  lost forever...
• You can receive 0 bytes of data!
• Same errors as sendto, but also
• EINTR System call interrupted by signal.

13
More recvfrom()

• recvfrom doesnt return until there is a datagram
  available,
• unless you do something special
• The sockaddr at from is filled in with the
  address of the sender.
• You should set fromaddrlen before calling.
• If from and fromaddrlen are NULL we dont find
  out who sent the data.

14
Typical UDP client code

• Create UDP socket.
• Create sockaddr with address of server.
• Call sendto(), sending request to the server.
• No call to bind() is necessary!
• Possibly call recvfrom() (if we need a reply).

15
Typical UDP Server code

• Create UDP socket and bind to well known address.
• Call recvfrom() to get a request, noting the
  address of the client.
• Process request and send reply back with sendto().

16
(No Transcript)
17
UDP Echo Server

• int mysock
• struct sockaddr_in myaddr, cliaddr
• char msgbufMAXLEN
• socklen_t clilen
• int msglen
• mysock socket(PF_INET,SOCK_DGRAM,0)
• myaddr.sin_family AF_INET
• myaddr.sin_port htons( S_PORT )
• myaddr.sin_addr htonl( INADDR_ANY )
• bind(mysock, myaddr, sizeof(myaddr))
• while (1)
• lensizeof(cliaddr)
• msglenrecvfrom(mysock,msgbuf,MAXLEN,0,cliaddr,
  clilen)
• sendto(mysock,msgbuf,msglen,0,cliaddr,clilen)

NEED TO CHECK FOR ERRORS!!!
18
Debugging

• Debugging UDP can be difficult.
• Write routines to print out sockaddrs.
• Use trace, strace, ptrace, truss, etc.
• Include code that can handle unexpected
  situations.

19
Timeout when calling recvfrom()

• It might be nice to have each call to recvfrom()
  return after a specified period of time even if
  there is no incoming datagram.
• We can do this by using SIGALRM and wrapping each
  call to recvfrom() with a call to alarm()

20
recvfrom()and alarm()

• signal(SIGALRM, sig_alrm)
• alarm(max_time_to_wait)
• if (recvfrom()lt0)
• if (errnoEINTR)
• / timed out /
• else
• / some other error /
• else
• / no error or time out
• - turn off alarm /
• alarm(0)

There are some other (better) ways to do this -
check out section 13.2
21
Connected mode

• A UDP socket can be used in a call to connect()
• This simply tells the O.S. the address of the
  peer.
• No handshake is made to establish that the peer
  exists.
• No data of any kind is sent on the network as a
  result of calling connect() on a UDP socket.

22
Connected UDP

• Once a UDP socket is connected
• can use sendto() with a null dest. address
• can use write() and send()
• can use read() and recv()
• only datagrams from the peer will be returned.
• Asynchronous errors will be returned to the
  process.

OS Specific, some wont do this!
23
Asynchronous Errors

• What happens if a client sends data to a server
  that is not running?
• ICMP port unreachable error is generated by
  receiving host and sent to sending host.
• The ICMP error may reach the sending host after
  sendto() has already returned!
• The next call dealing with the socket could
  return the error.

24
Back to UDP connect()

• Connect() is typically used with UDP when
  communication is with a single peer only.
• It is possible to disconnect and connect the same
  socket to a new peer
• More efficient to send multiple datagrams to the
  same user
• Many UDP clients use connect().
• Some servers (TFTP).

25
(No Transcript)
26
I/O Multiplexing

• We often need to be able to monitor multiple
  descriptors
• a generic TCP client (like telnet)
• a server that handles both TCP and UDP
• Client that can make multiple concurrent requests

• browser

27
Example - generic TCP client

• Input from standard input should be sent to a TCP
  socket.
• Input from a TCP socket should be sent to
  standard output.
• How do we know when to check for input from each
  source?

28
Options

• Use multiple processes/threads.
• Use nonblocking I/O.
• use fcntl() to set O_NONBLOCK
• Use alarm and signal handler to interrupt slow
  system calls.
• Use functions that support checking of multiple
  input sources at the same time.

29
Non blocking I/O

• Tell kernel not to block a process if I/O
  requests can not be completed.
• use fcntl() to set O_NONBLOCK
• int flags
• flags fcntl(sock,F_GETFL,0)
• fcntl(sock,F_SETFL,flags O_NONBLOCK)
• Now calls to read() (and other system calls) will
  return an error and set errno to EWOULDBLOCK.

30

• while (! done)
• if ( (nread(STDIN_FILENO,)lt0))
• if (errno ! EWOULDBLOCK)
• / ERROR /
• else write(tcpsock,)
• if ( (nread(tcpsock,)lt0))
• if (errno ! EWOULDBLOCK)
• / ERROR /
• else write(STDOUT_FILENO,)

31
The problem with nonblocking I/O

• Using blocking I/O allows the OS to put your
  process to sleep when nothing is happening (no
  input).
• Once input arrives, the OS will wake up your
  process and read() (or whatever) will return.
• With nonblocking I/O, the process will chew up
  all available processor time!!!

32
Using alarms

• signal(SIGALRM, sig_alrm)
• alarm(MAX_TIME)
• read(STDIN_FILENO,)
• ...
• signal(SIGALRM, sig_alrm)
• alarm(MAX_TIME)
• read(tcpsock,)
• ...

A function you write
33
Alarming Problem

• What will happen to the response time ?
• What is the right value for MAX_TIME?

34
Select()

• The select() system call allows us to use
  blocking I/O on a set of descriptors (file,
  socket, ).
• We can ask select to notify us when data is
  available for reading on either STDIN or a
  socket.

35
select()

• int select( int maxfd,
• fd_set readset,
• fd_set writeset,
• fd_set excepset,
• const struct timeval timeout)
• maxfd highest number assigned to a
  descriptor.
• readset set of descriptors we want to read
  from.
• writeset set of descriptors we want to write to.
• excepset set of descriptors to watch for
  exceptions.
• timeout maximum time select should wait

36
struct timeval

• struct timeval
• long tv_sec / seconds /
• long tv_usec / microseconds /
• struct timeval max 1,0
• To return immediately after checking descriptors
• set timeout as 0, 0.
• To wait until I/O is ready
• set timeout as a NULL pointer.

37
fd_set

• Operations you can use with an fd_set
• Clear all bits in fd_set
• void FD_ZERO( fd_set fdset)
• Turn on the bit for fd in fd_set
• void FD_SET( int fd, fd_set fdset)
• Turn off the bit for fd in fd_set
• void FD_CLR( int fd, fd_set fdset)
• Check whether the bit for fd in fd_set is on
• int FD_ISSET( int fd, fd_set fdset)

38
Using select()

• Create fd_set
• Clear the whole thing with FD_ZERO
• Add each descriptor you want to watch using
  FD_SET.
• Call select
• when select returns, use FD_ISSET to see if I/O
  is possible on each descriptor.
