Title: Module 14 UDP and TCP Frames


1
Module 14UDP and TCP Frames
2
  • Textbook sections
  • LG Section 8.5 Transmission Control Protocol
  • BF Chapter 11 UDP Section 11.1 11.4
  • BF Chapter 12 TCP Sections 12.1 12.12
  • Topics
  • User Datagram Protocol (UDP)
  • Transmission Control Protocol (TCP)
  • TCP Timers
  • TCP Operation Scenarios

3
BF Figure 12-1 TCP/IP Protocol Suite
4
1. User Datagram Protocol (UDP)
  • User Datagram Protocol (UDP)
  • UDP is an unreliable, connectionless transport
    layer protocol
  • Provides only two additional services beyond IP
  • Demultiplexing
  • IP knows how to deliver packets to a host, but
    does not know how to deliver them to the specific
    application in the host. UDP adds a mechanism
    that distinguishes among multiple applications in
    the host (port address)
  • Error checking on data
  • IP checks only the integrity of its header. UDP
    can optionally check the integrity of the entire
    user datagram (header and data).
  • For IPv6, the header checksum of IPv4 is
    eliminated because the checksum is/can be
    provided by upper layer protocols.

5
LG Figure 8.16 UDP format
31
16
0
Source Port
Destination Port
UDP Length
UDP Checksum
Data
6
1. User Datagram Protocol (UDP)
  • UDP checksum
  • The usage of UDP checksum is an option.
  • Checksum field contains all 0s, if a source host
    does not want to compute the checksum.
  • If a host computers the checksum whose result is
    0, it will set the checksum to all 1s.
  • Checksum includes
  • Pseudo header from the IP header
  • The pseudoheader is part of the header of the IP
    packet in which the user datagram is to be
    encapsulated for transmission with some fields
    filled with 0s.
  • Routers recalculate the value in the IP checksum
    field
  • UDP header
  • Data, padded with zero octets at the end (if
    necessary) to make a multiple of two octets.

7
BF Figure 11.8 Pseudoheader added to the UDP
datagram
8
1. User Datagram Protocol (UDP)
  • Use of UDP
  • Trivial File Transfer Protocol (TFTP)
  • TFTP includes flow and error control. It can
    easily use UDP.
  • Simple Network Management Protocol (SNMP)
  • Routing Information Protocol (RIP)
  • Real-Time Protocol (RTP)
  • Domain Name System (DNS)
  • Multicasting and broadcasting
  • UDP is a suitable transport protocol for
    multicasting and broadcasting. Multicasting and
    broadcasting capabilities are embedded in the UDP
    software but not in the TCP software
  • In general UDP is suitable for a process that
    requires simple request-response communication
    and with little concern for flow and error
    control. It is not usually used for a process
    that needs to send bulk data, such as FTP.

9
BF Figure 12-4 TCP segment format
10
2. Transmission Control Protocol (TCP)
  • TCP segment format
  • Sequence number field
  • 32-bit field defines the number assigned to the
    first byte of data contained in this segment
  • Acknowledge number filed
  • 32-bit field defines the byte number that the
    source of the segment is expecting to receive
    from the other party
  • Data offset field
  • 4 bits field indicate the number of 32 bits
    words(in units of 4-bytes word) in the TCP
    header. It indicates where the data begins. The
    TCP header (even one including options) is an
    integral number of 32 bits long.
  • Window size field
  • 16-bit field defines the size of the window, in
    bytes, that the other party must maintain
  • Used for flow control
  • The sequence number field, the acknowledge number
    field, and the window size field are all involved
    in TCPs sliding window algorithms.

11
2. Transmission Control Protocol (TCP)
  • Control field
  • BF Figure 12.5 Control field
  • Option field
  • Figure 12.9 Maximum segment size option
  • Figure 12.10 Window scale factor option
  • Figure 12.11 Timestamp option

12
2. Transmission Control Protocol (TCP)
  • Checksum field
  • The TCP checksum field is used in exactly the
    same way as for UDP.
  • TCP checksum is computed over
  • Pseudoheader
  • TCP header
  • TCP data
  • The checksum computation procedure is similar to
    IP checksum calculation
  • Additional features of TCP checksum calculation
  • Padding If the length of the segment is not a
    multiple of 16 bits, the segment will be padded
    with zeros to make it a multiple of 16 bits.
    Note, however, the TCP length field is not
    modified.

13
2. Transmission Control Protocol (TCP)
  • Pseudoheader
  • Pseudoheader is added to the beginning of the
    segment when performing the checksum computation
  • Pseudoheader is created by the source and
    destination hosts during the checksum computation
    and is not transmitted.
  • Pseudoheader ensures the receiver that the
    segment has indeed reached the correct
    destination host and port and that the protocol
    type is TCP (which is assigned the value of 6).
    At the receiver the IP address information in the
    IP packet that contained the segment is used in
    the checksum calculation.
  • The TCP Length field in the Pseudoheader is the
    TCP header length plus the data length in bytes.
    It does not count the 12 bytes of the
    Pseudoheader.

14
2. Transmission Control Protocol (TCP)
  • Pseudoheader A subset of fields from the IP
    header that are passed up to transport protocols
    TCP and UDP for use in their checksum
    calculations.
  • Part of both TCPs and UDPs checksum calculation
  • Not transmitted
  • Consists of three fields from IP header protocol
    number, source IP address, and destination IP
    address, plus TCPs or UDPs total length.
  • Purpose is to ensure the contents of pseudoheader
    fields are transmitted correctly.

15
BF Figure 12-12 Pseudoheader Added to the TCP
Datagram
16
2. Transmission Control Protocol (TCP)
  • Urgent pointer field
  • A 16-bit field is valid only if the urgent flag
    in the control field is set.
  • Used when the segment contains urgent data.
  • Defines the number that must be added to the
    sequence number to obtain the number of the last
    urgent byte in the data section of the segment.
  • This facility is a bare bones way of allowing the
    sender to signal the receiver without getting TCP
    itself involved in the reason for the interrupt
  • The urgent flag in the control field indicates
    that this segment contains urgent data. When
    this flag is set, the urgent point field
    indicates where the non-urgent data contained in
    this segment begins.

17
2. Transmission Control Protocol (TCP)
BF Figure 12-5 Control Field
18
2. Transmission Control Protocol (TCP)
  • Control field
  • URG flag
  • Out of sequence number
  • TCP is a stream-oriented protocol
  • However, if the sending program wants a piece of
    data to be read out of order by the receiving
    application program, it can do so by setting the
    urgent flag and provide value in the urgent
    pointer field.
  • When the receiving TCP receives a segment with
    urgent flag set, it extracts the urgent data from
    the segment using the value in the urgent
    pointer.
  • The extracted data will be delivered to the
    receiving application program as soon as it
    arrives, even if it means delivering it before
    data with a earlier sequence number.

19
2. Transmission Control Protocol (TCP)
  • Control field
  • PSH flag
  • Do not wait
  • The application program on the sending site can
    request a push operation. This means that the
    sending TCP should not wait for the window to be
    filled. It should create a segment and send it
    immediately. The sending TCP should also set the
    push bit (PSH).
  • At the receiving TCP, when the PSH bit is set,
    it tells the receiver to pass the data to the
    application immediately and do not wait for more
    data to come.Otherwise, receiver may choose to
    buffer the segment until enough data accumulates
    init buffer.

20
2. Transmission Control Protocol (TCP) Option
Field
BF Figure 12-6 Options
21
2. Transmission Control Protocol (TCP) Option
Field
BF Figure 12-7 End of Option
22
2. Transmission Control Protocol (TCP) Option
Field
BF Figure 12-8 No Operation Option
23
2. Transmission Control Protocol (TCP) Option
Field
BF Figure 12-9 Maximum segment size (MSS) option
  • Note It communicates the maximum receive segment
    size at the TCP which sends this segment.
  • This option is used only in the segments that
    make the connections. It cannot be used in
    segments during data transfer.
  • The size is determined by the destination of the
    segment, not the source. So party 1 defines what
    should be the MSS sent by party 2. Party 2
    defines what should be the MSS sent by party 1.
  • It defines the maximum size of the data, not the
    maximum size of the segment.
  • The default value is 536.

24
2. Transmission Control Protocol (TCP) Option
Field
BF Figure 12-10 Window scale factor option
Note 1. New window size window size defined
in the header 2window scale factor 2. The size
of the window cannot be greater than the maximum
for the sequence number. The largest value of
window scale factor allowed is 16.
25
2. Transmission Control Protocol (TCP) Option
Field
BF Figure 12-11Timestamp option
  • Note
  • TCP -gt connection-oriented -gt acknowledgement -gt
    necessary retransmission based on round-trip-time
    (RTT) -gt one approach is to use TCP time stamp
    option to estimate RTT dynamically
  • Usage of TCP timestamp option
  • Source fills timestamp value in the timestamp
    field when the segment leaves the source
  • Destination stores the timestamp value after it
    received the segment.
  • When the destination sends an acknowledgement
    for the bytes in the segment received,
    destination enters the stored timestamp value in
    the timestamp echo reply field.
  • The source, after received the acknowledgement,
    calculates the round-trip-time (RTT) by taking
    the difference between the current time and the
    value in the timestamp echo reply field.

26
3. TCP Timers
BF Figure 12-21 TCP Timers
27
3. TCP Timers
  • TCP timer
  • Retransmission timer
  • If the retransmission timer goes off before the
    acknowledgement arrives, the segment is
    retransmitted and the timer is reset.
  • The most common formula used to calculate
    retransmission time
  • Retransmission time 2 round-trip time (RTT)
  • Calculation or RTT
  • First method Use timestamp option
  • Second method TCP sends a segment, starts a
    timer, wait for an acknowledgement, and measure
    the round-trip time.
  • RTT alpha previous RTT (1 alpha)
    current RTT
  • where alpha is between 0 and 1, and is usually
    set at 0.9
  • Karn algorithm
  • Do not update the value of RTT until you send a
    segment and receive an acknowledgement without
    the need for retransmission

28
3. TCP Timers
  • Persistence timer
  • Used to correct deadlock caused by the announce
    of a window size of zero by the receiving
    followed by an acknowledgment lost from the
    receiver.
  • Probe usage
  • When the sending TCP receive an acknowledgement
    with a window size of zero, it starts a
    persistence timer.
  • When the persistence timer goes off, the sending
    TCP sends a special segment called probe.
  • Keepalive timer
  • Used to prevent a long idle connection between
    two TCPs
  • Time-waited timer
  • Used during connection termination

29
4. TCP Operation Scenarios
  • Operation scenarios
  • Connection establishment
  • Three-way handshake - to establish a connection
  • Four-way handshake - to terminate a connection
  • Data transfer
  • Typical
  • Pushing data
  • Urgent data
  • Connection termination
  • State transition diagram representation

30
4. TCP Operation Scenarios
  • Three-way handshake
  • An algorithm used by TCP to establish a
    connection
  • Involves the exchange of three messages between
    the sender and the receiver
  • Purpose is for two parties to agree on the
    starting sequence numbers the two sides plan to
    use for their respective byte streams
  • Algorithm
  • Step 1 the sender sends a segment to the
    receiver stating the initial sequence number it
    plan to use (Flags SYN, sequence number x)
  • Step 2 the receiver responds with a single
    segment that both acknowledges the senders
    sequence number (Flag ACK, ack x1) and
    states its own beginning sequence (Flag SYN,
    sequence number y). Both SYN and ACK bits are
    set in the Flags field of the second message.
  • Step3 the sender responds with a third message
    that acknowledges the receivers sequence number
    (Flags ACK, acknowledge number y1).

31
4. TCP Operation Scenarios
BF Figure 12-22 Three-way Handshaking
32
4. TCP Operation Scenarios
  • Four-way handshake
  • An algorithm used by TCP to terminate a
    connection
  • Algorithm
  • Step 1 First, the sender sends a FIN segment to
    the receiver (Flags FIN, sequence number x)
  • Step 2 the receiver sends the second segment, an
    ACK segment, to confirm the receipt of the FIN
    segment from the sender. In this segment it uses
    the acknowledgement number, which is one plus the
    sequence number. (Flags ACK, sequence number
    y, acknowledge number x1)
  • Step 3 The receiver can continue sending data in
    the receiver-sender direction. When it does not
    have any more data to send, it sends the third
    segment. This segment is a FIN segment. (Flags
    FIN, sequence number y m, acknowledge number
    x1)
  • Step 4 The sender sends the fourth segment, an
    ACK segment, to confirm the receipt of the FIN
    segment from the receiver. This segment contains
    the acknowledgement number , which is one plus
    the sequence number received in the FIN from the
    server. (Flags ACK, sequence number x 1,
    acknowledge number ym1)

33
4. TCP Operation Scenarios
BF Figure 12-23 Four-way Handshaking
34
4. TCP Operation Scenarios
BF Figure 12-24 State Transition Diagram
35
4. TCP Operation Scenarios
  • Notations of Figure 12.24
  • Lines
  • Dotted lines of the figure represent the server
  • Solid lines represent the client
  • Thin lines represent unusual situations
  • Event/action
  • Event can take the machine to a new state
  • Event can also make the machine perform some
    actions

36
4. TCP Operation Scenarios - States for TCP
BF Table 12.3 States for TCP
37
4. TCP Operation Scenarios
  • Reading assignments
  • BF Chapter 12 TCP Sections 12.9 Connection
  • BF Chapter 12 TCP Sections 12.10 State Transition
    Diagram

38
4. TCP Operation Scenarios
39
4. TCP Operation Scenarios
40
4. TCP Operation Scenarios
  • TIME-WAIT state
  • The value of the timer is set to double the
    lifetime estimate of a segment of maximum size
  • Reason for using the timer
  • While the client TCP of the connection has sent
    an ACK in response to the server TCPs FIN
    segment, it does not know that the ACK was
    successfully delivered.
  • As a consequence, the server TCP might retransmit
    its FIN segment.
  • The second FIN segment might by delayed in the
    network.
  • If the connection were allowed to move directly
    from the FIN-Wait-2 state to the CLOSED state,
    then another pair of application processes might
    come along and open the same connection (i.e.,
    use the same pair of port numbers), and the
    delayed FIN segment from the earlier incarnation
    of the connection would immediately initiate the
    termination of the later incarnation of that
    connection.
Write a Comment
User Comments (0)
About PowerShow.com
