Title: Signal Coordination: Chapter 22


1
Lecture 11
  • Signal Coordination Chapter 22

2
Objectives
  • Factors affecting coordination
  • Basic theory of signal coordination
  • Application to arterial progression

3
Factors Affecting Coordination
  • Benefits
  • Purpose of signal system
  • Factors lessening benefits
  • Exceptions to the coordinated scheme

4
Concept Maximize Progression By Adjusting
Offsets
t3
Distance (ft)
t2
t1
0 30 60 90 120 150 180
210
Time (sec)
Note Definitions of offset vary, but text
convention is offset is t2 t1 and t3 t2
5
Benefits of Signal Coordination
  • Stops and Delay
  • Performance index combining measures
  • Cost A X (total stops) B X (total delay)
  • What are some other benefits?

6
Engineering Options
  • What type of system is it?
  • Which movements will be progressed?
  • What is the objective?
  • What happens if you can not achieve the objective?

7
Factors Lessening Benefits
  • Inadequate roadway capacity
  • Side friction
  • Complicated intersection timing plans
  • Wide variability in traffic speeds
  • Short signal spacing
  • Heavy turn volumes see figure 22-3

8
Time Space Diagrams and Ideal Offsets
  • What is an offset?
  • What is an ideal offset?

9
t3
Distance (ft)
t2
t1
0 30 60 90 120 150 180
210
Time (sec)
10
One-Way Progression
  • For one-way progression, what do you need to know
    to estimate ideal offsets?
  • How do you construct a time-space diagram?
  • Can specify offsets relative to one (master)
    intersection

11
t3
Distance (ft)
t2
t1
0 30 60 90 120 150 180
210
Time (sec)
12
Effect of Queued Vehicles
How do you determine the offset with queuing?
  • Q number of vehicles queued per lane (veh/lane)
  • H discharge headway of queued vehicle (sec/veh)
  • Loss1 loss time associated with vehicles starting
    from rest at the first downstream signal (sec)

13
Different Types of Progression
  • What are the different types of progression?
  • Simple
  • Forward
  • Flexible
  • Reverse
  • Simultaneous

14
Two-Way Progression
  • Progression in one direction suffers
  • Segment offsets tSBtNB nC
  • Maximizing bandwidth
  • Popular
  • Limited

15
Two-Way Progression (Cont.)
  • Simultaneous progression
  • Closely spaced intersections
  • Queue management
  • Alternate progression
  • Uniform block length
  • 5050 split
  • N the number of blocks with simultaneous green
  • How do you determine N?

16
5th Signal
4th Signal
3rd Signal
Distance (ft)
2nd Signal
1st Signal
Working Line
0 30 60 90 120 150 180
210
Time (sec)
1000 ft intersection spacing 2 lanes in each
directions C 60 sec w/ 5050 split
What is the progression speed? What is the
nonstop volume?
17
Two-Way Progression (cont.)
  • What about arterials with non-uniform
    intersection spacing?

18
Distance (ft)
Working Line
0 ½ C C 1½ C 2C 2½ C 3C 3½ C
Time (sec)
19
Distance (ft)
Working Line
0 ½ C C 1½ C 2C 2½ C 3C 3½ C
Time (sec)
20
A Signal Coordination Study
  • Go to the field and ride through the system
  • Do you see unused green time at down stream
    signals?
  • Do you arrive at signals with standing queues?
  • Do you arrive on red?
  • Is the flow in the other direction significant?
  • Sketch out network with flow patterns
  • Which cycle length is most appropriate?

21
Oversaturated Conditions
  • Removal of intersection blockage
  • Address root causes
  • Update signalization
  • Use novel signalization to reduce extent of
    congestion
  • Provide more space
  • Prohibitions vs enforcement vs resulting problems
  • Consider other options

22
Oversaturated Conditions
  • Signal based remedies
  • Metering plans
  • Shorter cycle lengths
  • Equity offsets
  • Imbalanced split
