Operating Jigsaw

1
Operating Jigsaw
2
Upper blade lifting part
New saw blade
Safe guard
Power
Hold down spring
Working table
Switch
3
Guide roller rod fixing screw
Upper blade chuck wing nut
Saw blade
Lower blade chuck wing nut
4
Replacing saw blade
5
Turn off the jigsaw
6
Release the lower blade chunk wing nut
7
Release the upper blade chuck wing nut
8
Insert a new saw blade
9
Ensure the teeth point downward!
10
Tighten the lower blade chuck wing nut
11
Push the upper blade lifting part downward. Tighte
n the upper blade chuck wing nut.
12
Cutting with jigsaw
13
Insert the material between the hold down spring
and table
14
Adjust the height of the hold down spring to just
on the material
15
Hold the material with both hands
16
Cut on the outer side. Dont cut along on the
line.
17
If you want to change the cutting direction, you
can rotate the material with your hands.
18
You can still see the lines after you cut it out.
