The RadOn method and associated error analysis Delano

1
The RadOn method and associated error
analysisDelanoë J., Protat A., Bouniol D.,
Testud J. Centre détude des Environnements
Terrestre et PlanétairesCloudNET meeting Paris
Julien Delanoë
4/5th April 2005
2
Outline

• RadarOnly Algorithm
• Error analysis
• Retrieval

3
Radar Only AlgorithmRadOn Principle of the
radar retrieval method
4
Principle of the Radar Algorithm (1)
Vt retrieval
5

• First step Retrieval of VT from VD
  VdwVt
• Hypothesis () for a long enough time span

• 2 methods
• Vt-Z Statistical relationship between Vd and Z
• Assuming (), we obtain Vt from Z (VtaZb)
• New approach
• Running Window
• Every 30s we compute the mean Vd over 10 minutes
  (like Matrosov) for each radar gate.

6
Retrieval of terminal fall velocity with
different methods
04/14/03 Palaiseau
Vt from Vt-Z relationship
7
Principle of the Radar Algorithm (2)
8
Principle of the radar retrieval method (2)

• Second step estimate of the particle density
  r(D) and area A(D) from VT-Z relationship
• Vt-Z relationship obtained from radar is compared
  to microphysical
• Vt-Z relationships with different density and
  area laws.
• Microphysical Vt-Z relationships
• r(D)arDbr and v(D)f(m(D),A(D),ad,bd)
  (Mitchell 1996)
• Where m(D)(p/6) ar D3br , Ag Ds and ad, bd
  are the continuous drag coefficients
  (Khvorostianov and Curry 2002).
• From coefficients of Vt-Z radar relationship we
  estimate the best density diameter and area
  diameter relationships.

9
Example 04/14/2003 Palaiseau

• black Vt-Z obtained by the radar
• red The best density and Area relationships

10
Principle of the Radar Algorithm (3)
Step unchanged (see Delft presentation)
11
Principle of the Radar Algorithm (4)
Step unchanged (see Delft presentation) Direct
relationship
12
Principle of the Radar Algorithm (5)
13
Clouds parameters
Using Dm N0 and Gamma shape gt Clouds parameters
14
Evaluation of RadOn using the microphysical
database
15
Evaluation of RadOn using the microphysical
database

• Dataset CLARE 98, CARL 99, EUCREX, ARM SGP,
  FASTEX, CEPEX, CRYSTALFACE
• We impose a density law and area diameter
  relationships for a radar at 35 and 95GHz
• A(D)gDs with several couples of coefficients
• r(D)aDb with several couples of coefficients

We compute Vt, Z, IWC, a and re from the in-situ
measurements, assuming A(D) and r(D)
Entries of the algorithm Vt and Ze from in situ
data
RadOn Algorithm
IWC, a, re from RadOn
IWC, a, re microf
16
bias std
bias
bias - std
5 Area diameter relationships
4 Density diameter relationships b-1.4,
-1.1, -0.8, -0.5
17
bias std
bias
bias - std
18
bias std
bias
bias - std
19
RadOn Retrieval

• 14th April 2003 Palaiseau
• Deep ice cloud
• 15th April 2003 Palaiseau
• Cirrus case

20
Retrieval 14th April 2003
N0
IWC
r(D)0.022D-0.6 A(D)p/4D2
re
a
21
r(D)0.0005D-1.3 A(D)0.05D1.4
N0
IWC
Retrieval 15th April 2003
re
a
22
Future work

• Refine the error analysis
• Run Radon on all the CloudNET sites, for all
  frequencies
• Statistical study of density, IWC, a, re.
• Comparison with Radar/Lidar and other Radar
  algorithm

23
IWC retrieval from different method

1. RadOn with running window
2. RadOn with Vt-Z
3. IWC-Z-T R.J Hogan
4. IWC-Z Protat et al.

24
1
2
With running window
Vt-Z
3
4
IWC-Z-T RJH
IWC-Z Protat et al.
25
