Help with Traffic Engineering

1
Help with Traffic Engineering

• Dr. Roger G. Clery
• Roosevelt University
• January 2006 (CC)

2
What A Switch Does

• Routes calls / messages to and from senders /
  receivers.
• Concentrates circuits. More Inputs than outputs.
  Saves .
• Causes blockage and delays.
• May collects statistics and billing information.


3
What An Automatic Call Distributor Does

• Queues customers in line. Makes em wait!
• Distributes calls more evenly to agents.
• May keep statistics on agents
• May be connected to computer system CTI
  Computer Telephone Integration for Screen pops
  to agents

4
What Types of Problems Can be Solved

• PBX Private Branch Exchange number of trunks
  required to the CO of the telephone company
• Cellular telephone circuits/ frequencies required
  at cell site.
• Agents required at a call center.
• Circuits/ trunks required between telephone
  switches.
• Trunks/ circuits required for emergency service
  fire, police, security services

5
Which Table to Use?

• Calls Queued Agents required Help desk, Call
  center then Erlang C table.
• Emergency services, final routing for telephone
  company or Cell sites Poisson table
• All other use the Erlang B table.

6
Components of the Tables

• Lines trunks circuits agents always in
  whole numbers 1,2,3,4 etc.
• Traffic measured in units called Erlangs. One
  Erlang is 3600 seconds of traffic. One Erlang is
  60 minutes of traffic. 3600 seconds 60
  minutes.
• Can also be measured in CCS. One CCS 100
  seconds. 36 CCS 1 Erlang.
• Grade of service. Probability that a call will be
  blocked. Smaller is better! P.01 1 1 out
  of a 100. P 0.1 10 1 out of 10 blocked.

7
B Table
Percent Blocked
N Trunks
Traffic in Erlangs
8
Poisson Table
Probability of Blockage
Trunks
Traffic in Erlangs
9
C Table

• The C table adds some additional information.
• The average length of a call must be known
  usually in minutes
• The probability of blockage is replaced by
  probability of being queued.
• Number of agents replaces number of trunks.
• Average Delay of all calls can be estimated
• Average Delay of Delayed calls can be estimated.
• Probability that a customer will wait a given
  time can be estimated.

10
C Table

• Select the correct group based on Erlangs of
  Traffic.For A 0.1 use 1st group.
• Using the Pd, the probability of delay select the
  correct N, for level of service 50.1000 is to
  high0.0048 is best choice available0.0002 is
  too good.

11
C Table

• 3. Multiply D1 by Talk time. If Talk time is 12
  minutes then 0.0025 X 12 .03 minutes.03 x 60
  1.8 seconds
• 4. Multiply D2 by Talk time.
• 0.526 x 12 6.312 minutes

12
C Table

• 5. Convert all t times to minutes
• .2 x 12 2.4 minutes
• .4 x 12 4.8 minutes
• .6 x 12 7.2 minutes
• .8 x 12 9.6 minutes
• 1 x 12 12 minutes
• 2 x 12 24 minutes
• 3 x 12 36 minutes
• 6. What is the probability of a delay of 9.6
  minutes? .001

13
Using a table

• Some judgment is required. If traffic is 2.2
  Erlangs and there is an entry for 2.018 This is
  close enough.
• If you are required to select the grade of
  service consider the consequence. If this is a
  Pizza take out place and an order is lost no big
  deal If you are in cardiac arrest and you are
  calling 911 then this call is very important.

14
Solving a problem

• Sam Samarian is opening up an insurance sales
  office. 6 agents will be selling insurance and
  at peek times the will spend 20 minutes per hour
  on the phone. Each agent will have her/his own
  phone on their desk. Each phone is connected to
  the PBX. How many trunks required? Grade of
  service is to be 7 .07
• Solution Minutes of talk 6 x 20 120Erlangs
  120/60 2 ErlangsWhich table PBX no queue
  PBX NO emergency B table

15
Solving a problem

• Find .07 Column
• Find 2 Erlangs or better 2.504
• Using this row read to left find N5
• 5 trunks are required.
• Question? What happens if one more trunks is
  added?
• Answer Service improves! Probability of blockage
  goes down to about 0.01

16
Solving Another problem

• Butter and Fat Turkey company has a turkey hot
  line for Thanksgiving day. Up to 40 customers
  call in the busy hour and each call takes about 4
  minutes to complete. If the level of service is
  to be lt 8 then how many turkey helpers are
  required? What is the average delay? What is the
  delay of delayed calls?
• Does anybody needing assistance wait 12 minutes?

17
Solving Another problem

• How much traffic is generated? 40 X 4 160
  minutes 160/60 2.66 Erlangs
• Which table calls will wait callers will be
  queued C table

18
C Table

• 2.66 Closest group is 2.7
• 8 .08 Closest but smaller is 0.0652
• 6 Turkey helpers required
• D1 0.0197
• Delay of all calls is 0.0197 x 4
• 0.0788 minutes 4.728 seconds
• D2 0.303
• Delay of delayed calls is 0.303 x4
• 1.212 minutes
• Delay of 12 minutes?
• t1 4 minutes
• t2 8 minutes
• t3 12 minutes
• There is no value under 3 because the value is
  too small so NO Chance of waiting 12 minutes

19
Solving Yet Another Problem

• Cell site on remote mountain is to be connected
  to the MTSO by a microwave link. How many
  channels are required for the voice traffic if
  the max busy hour traffic is 2.5 Erlangs and
  Grade of service is .001

20
Solution

• Which table? Poison because of final routing
• Required .001 9 channels 2.453 10 2.961
• I would recommend 10 channels and better service,
  but 9 could squeeze by.
• (note a B table would say 9 is fine handling
  2.56 Erlangs)

21
Try this one

• PBX will handle 21 Erlangs and grade of service
  is P 0.05

22
Answer

• B Table
• 20.943 close enough to 21
• 26 trunks

23
Try this one

• Call Center 45 calls per hour, 8 minutes per
  call, service level 10

24
Answer use C table

• 45 x 8 360 minutes
• 360 minutes / 60 6 Erlangs
• A N Pd D1
  D2 PROBABILITY OF DELAY OF TIME t

  .2 .4 .6
  .8 1 2 3 4
  6.0 7 0.6138 0.6138 1.000 .503
  .411 .337 .276 .226 .083 .031 .011
  6.0 8 0.3570 0.1785 0.500 .239
  .160 .108 .072 .048 .007 .001 6.0
  9 0.1960 0.0653 0.333 .108 .059
  .032 .018 .010 6.0 10 0.1013 0.0253
  0.250 .046 .020 .009 .004 .002
  6.0 11 0.0492 0.0098 0.200 .018
  .007 .002 .001
• 10 agents 0.1013 ? 10
• .0253 x 8 .2026 minutes 12.14 seconds
• 0.250 x 8 2 minutes
• .002 .2 chance of 6.4 minute delay

25
The END

• Clerys Law 82 of any job is understanding the
  problem!
