ipchains

1
ipchains

• A packet-filtering Firewalls supported by Linux
  distributions

2
Description

• A firewall is a basic and essential component of
  any network security system.
• ipchains is a packet-filtering firewall for Linux
  distribution.
• ipchains does not look at the content of the
  packet but the header.

3
Objective

• Knowing about the packet-filtering firewall
  working
• Teach basic firewall scripting and rule
  definitions

4
System Requirements install

• Linux distribution with kernel version 2.1.x or
  above.
• Linux kernel built-in
• If support ip_tables, its needs Linux
  distribution with kernel version 2.3.x or above

5
Challenge Procedure

1. Create shell variables for better scripting
2. Properly secure the firewall script
3. Establish a deny-all policy
4. Allow loopback traffic
5. Allow outbound web traffic
6. Create ingress and egress filters.
7. Restore the default firewall script.

6
Basic format of an ipchain rule

• ipchain AI chain i interface -p protocol
  -s source address portport -d destination
  address portport -j action -l
• -AI append or insert
• chain input, output, forward
• -p ICMP, UDP, TCP, all
• -j allow, deny, reject
• -l log

7
Step-by-Step (0)

• pre-scan the local status

8
Step-by-Step (1)

• Define variables in firewall.sh

9
Step-by-Step (2)

• vi firewall.sh
• sh firewall.sh

10
Step-by-Step (3)

• scan after the firewall open
• scan by nmap P0 sT 127.0.0.1

11
Step-by-Step (4)

• Enable the loopback interface

12
Step-by-Step (4)

• rescan the loopback interface

13
Step-by-Step (5)

• rescan the loopback interface by an external
  address

14
Step-by-Step (5)

• All for outbound web traffic

15
Step-by-Step (5)

• Block inbound packets from private address

16
Step-by-Step (5)

• Block outbound packets from private address

17
Step-by-Step (6)

• Show the ipchains rule

18
Step-by-Step (7)

• Flush the ipchains rule

19
ipchain log

• Apr 28 013828 time and date
• www machine name
• kernel record by kernel
• Packet log message from ipchain
• input the rule
• REJECT the rules target
• eth0 interface
• PROTO-1 protocol number (ICMP1) (TCP6)
• 192.168.0.38 source ip address and port
• 192.168.1.10 destination ip address and port
• L-60 packets length
• S-0x00 Type of service
• I-7476 IPs ID
• F-0x0000 IP fragement
• T-32 Time to Live

20
Summary what do you learn?

• Firewalls are one the basic component of network
  perimeter to determine what traffic should be
  allowed in or out of the network.
• A packet-filtering firewall make it blocking
  decisions based on the data contained in the
  packet header.
