Title: F14 Tomcat


1
F-14 Tomcat
2
History
3
F-14s Roles
  • Fighter Escort
  • Combat Air Patrol/ Deck Launched Intercept
    Operations
  • Secondary Attack of Tactical Ground Targets

4
Specifications
  • Wingspan 64.1
  • Length 68.7
  • Height 16
  • Max Gross 74,349 lbs
  • Empty Weight 40,104
  • Mach 2.34
  • Range 1,735
  • Ceiling 50,000

5
F-110-GE-400
  • Thrust 14,000
  • Thrust (afterburner) 27,080
  • Bypass Ratio 0.87
  • Length 232
  • Weight 4,400 lbs
  • Fan Diameter 46.5
  • Fan 3 stages
  • HPC 9 stages
  • HPT 1 stage
  • LPT 2 stages
  • no thrust reverser

6
Variable Area Nozzle
7
Armament
  • Vulcan 20 mm gun
  • AIM-9 Sidewinders
  • AIM-7 AMRAAMs
  • AIM-54 Phoenix
  • Rockeye Bomb
  • CBU Cluster Bomb

8
The EndBack to My Homepage
