• Cube Surveys Limited are subsurface utility
  detection and mapping experts.
• Working throughout the UK providing clients with
  up-to-date 'as built' records of all buried
  services and utilities.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
3

• Utilising the very latest technology including
  Electromagnetic and Ground Penetrating Radar, as
  recommended in HSG47 (Safe digging practice).
• Our fully trained NRSWA/CSCS engineers can
  precisely locate, trace and then map all buried
  services including Plastics and Fibre Optics.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
4
THE BENEFITS

• The benefits of obtaining this information when
  project planning are several-fold. Having this
  information at a very early stage, more often
  than not,ultimately saves money on the overall
  project as it allows you to plan and design
  around any expensive diversion costs and prepares
  you for any un-wanted, expensive and unexpected
  surprises when excavation starts.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
5
HEALTH SAFETY

• More importantly our service gives you and or /
  your client the peace of mind that you have
  fulfilled your Health Safety responsibilities
  as detailed in HSG47 (Safe digging practices).
• Take NO Chances.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
6
OUR EQUIPMENT

• Radio Detection RD4000
• A cable location tool as oppose to a cable
  avoidance tool (CAT), the RD4000 allows our
  engineers to follow and plot the route of any
  given electric cable.
• Used in conjunction with a Genny signal
  transmitter, we can also plot the route and depth
  of any metallic utilities, such as Cast Iron
  Water/Gas Pipes.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
7
OUR EQUIPMENT
Mala Geoscience Easy Locator GPR. The Easy
Locator, Ground Penetrating Radar systems allows
our engineers to locate, depth and trace the
route of all non-metallic utilities such as
Plastic Pipes, Fibre Optic cables, Clay pipes,
Ducts etc. To a depth of up to 4.5 metres.

Used in conjunction with the RD4000 This allows
our engineers to build the overall picture of
what utilities lie buried.
WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
8
OUR EQUIPMENT
IDS Detector GPR System. The Detector, Ground
Penetrating Radar machine is the latest addition
to our equipment. By adding an alternative radar
system to compliment the Mala machine gives our
engineers the best possible chance of a positive
location. As both systems work on different
frequencies, with the Detector transmitting at
700Mhz it produces more clarity at shallower
depths than the 500Mhz Mala, that offers better
results at deeper depths. Using both machines in
tandem, therefore produces optimum results.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
9
OUR EQUIPMENT
RIDGID SR20 Cable Pipe Locator. The Ridgid SR20
is the very latest technology in Cable Pipe
location. The main advantage of this equipment,
is that it allows us to virtually map the utility
in real time from the display screen. This in
turn Increases productivity by showing depth
changes in real time including the ability to
accurately depth electric cables.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
10
OUR EQUIPMENT

• Topcon GTS 825A Robotic Total Station
• Once confirmed, the routes and depths of the
  buried utilities will be collected by use of a
  Topcon robotic total station and overlaid onto
  your supplied Topographic drawing as separate
  layers in AutoCAD format. If no topographic
  information is available we can undertake this
  element for you, alternatively our results can be
  overlaid onto an Ordnance Survey base plan.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
11
OUR EQUIPMENT

• H S Equipment.
• All Cube engineers are equipped with all
  necessary Health Safety work wear, cones,
  safety barriers and safety signs to satisfy site
  / NRSWA policies.
• In order to provide all levels of service,
  regardless of project size, all Cube engineers
  are provided with Proteus Heavy Cover Lifting
  Equipment.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
12
LEVELS OF SERVICE

• Instant Site Mark-Out
• When time is of the essence and immediate
  knowledge of the underground is required. CUBE
  will literally mark out our findings on the
  ground before you. Each utility is colour coded
  and marked in biodegradable paint. Marking the
  route of each utility and noting the depth and
  depth changes along the course of the utility. No
  drawings are provided using this method

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
13
LEVELS OF SERVICE

• Instant Site Mark-Out

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
14
LEVELS OF SERVICE

• Electronic Trial Pits / Slit Trenches
• Replace traditional hand dug investigation with
  CUBE non-invasive trial pits or electronic slit
  trenches. Typical trial pits are a 3m x 3m x 3 m
  cube. The slit trenches tend to be full road
  width x 3m x 3m. The area is marked out on site
  and a Plan View and Cross Sectional Drawing is
  provided.
• A Digital photograph can be added if desired.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
15
LEVELS OF SERVICE

• Electronic Trial Pits / Slit Trenches

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
16
LEVELS OF SERVICE

• Full Utility Mapping
• Provided in Auto cad format. CUBE will supply an
  As Built underground utility map of your site.
• Data will be added in layers to your original
  Topographic Survey or Ordnance Survey base plan.
  Alternatively, we can undertake the whole project
  and provide the topographic survey, along with
  the utility information. The client receives this
  information electronically, on CD Rom and in hard
  copy.If requested this can also be provided on
  acetate.

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
17
LEVELS OF SERVICE
Full Utility Mapping

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
18
SOME APPLICATIONS

• Utility maintenance and repairs
• Project planning
• Route planning
• Clear ground proving
• Resurfacing schemes
• Road and footway widening
• Long distance pipe / cable tracing
• Updating site utility plans
• Record-less brown field sites

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
19
INSURANCE

• For your peace of mind, Cube Surveys carry the
  following insurance
• Public Liability - 2,000,000
• Employers Liability - 10,000,000
• Products Liability - 2,000,000
• Professional Indemnity - 2,000,000

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
20
CUBE CLIENTS

• CUBE SURVEYS are delighted to have completed
  projects for
• George Wimpey Bovis Homes
• Manchester City Council Alfred McAlpine
• Kings Oak (Barratt Homes) Transco
• London Borough of Camden Premier Energy Services
• Scottish Southern Electric Allenbuild
• AMEC Telford Homes
• Gleeson Homes Bellway Homes
• Halcrow Charles Church Homes
• Royal Borough of Kensington Chelsea

WINNERS Best New Business Start-Up 2005/06
NON GROUND BREAKING TECHNOLOGY
21
NEXT ..

• Should you require any further information, or
  would like a quotation for any projects you
  currently have in progress
• Please E-Mail us at sales_at_cubesurveys.co.uk
• Or contact us on T 0870 755 0093
• F 01270 270033
• Richard Lee M 07951 435123
• Paul Fagan M 07951 424192
• Rob Yates M 07951 424235
