Patching Potholes

1
Patching Potholes

• Warm Springs Indian Reservation
• Road Maintenance Presentation
• 50 Bag Cold Patch vs
• Stockpiled Cold Mix Hauled From Batch Plant Near
  Redmond Oregon

2
Pothole Route 53
3
Second Pothole on Route 53
4
Traffic Control For Pothole Patching Operation
Three Warning Signs on Approaches Flagger
Controlling Traffic in Workzone Cones Protecting
Workers from Traffic
5
Third Warning Sign North Approach
6
Second Warning Sign North Approach
7
First Warning Sign North Approach
8
Three Warning Signs On South Approach
9
Workzone (Flaggers and Equipment)
10
Workzone Layout (Flagger and Traffic)
11
Normal Method of Patching

• Cold Patch Ordered in Summer From Batch Plant
  Near Redmond, Oregon
• Truckloads Of Cold Patch Hauled to Stockpile at
  Road Maintenance Yard
• Material Loaded Onto Patching Trailer
• Material Hand Placed in Cleaned Holes
• Patch Compacted Prior To Opening for Use
• Cost 40/ton at plant 150 Haul Costs
  50.71/ton for 14 ton Truckload Lots

12
Material in Stockpile
13
Patching Trailer in Shop Warming First Batch of
Patching Material For Morning Shift
14
Cleaning and Drying Potholes
15
Applying Emulsion (Tack)
16
Placing Cold Mix
17
Breaking Large Lumps
18
Heating Mix and Breaking Large Lumps
19
Raking Patch and Cleaning Next Area to be Patched
20
Compacting Outside Edge of Patch
21
Compacting Outside Edge of Patch and Drying Next
Patch Area
22
Compacting Center of Patch and Cleaning Next Area
to be Patched
23
Patched Pothole Route 53
24
2 Pallets of Patching Compound
25
QPR Patching Compound 50 Bag
26
Delivered Cost of 50 Bag QPR Patching Compound
QPR 50 Bags x 112 bags x 9.60/bag 1075.20

Freight 498.00
Total 1573.20
/ 2.8
tons 561.86/ton Advantages less
preparation of pothole (cleaning drying and
applying tack emulsion). Traffic will compact
mix. Less Equipment needed to place
patch. Permanent Repair of Pothole.
27
End of Presentation
Thank You
