Nature of Light

1
Not-For-Profit Public Foundation
Nature of Light
2
Light is a form of energy. Energy can be
transported by waves. Use waves as a tool to
understand light.
3
WAVE PARAMETERS

• Wavelength (l) is the length from crest to crest
  or trough to trough.
• Frequency (f) is the number of waves passing a
  point per second.
• Higher Frequency ? Shorter Wavelength
• Lower Frequency ? Longer Wavelength
• Speed of a wave (v) Wavelength x Frequency

4
Light as a WAVE
As a wave, Light can be described as having
a Frequency Wavelength Speed
Wave Speed Wavelength x Frequency
5

• What does a light wave look like?
• To answer this, must first know how light is
  produced.
• Start with an electron ? has an electric field
  (example is static cling or battery)

• Also a moving electron produces a magnetic field.

6

• Accelerate an electron and both electric and
  magnetic fields are produced ? called an
  electromagnetic wave

7
The Nature of Light

• Light is an electromagnetic wave that travels at
  the speed of light
• The speed of light is related to the waves
  frequency and wavelength
• c ?f 300,000 km/sec
• (or 186,000 mi/sec)

8

• As a wave, light may have any wavelength (and
  frequency), but its speed remains constant.
• An electromagnetic wave with a long wavelength
  has a low frequency and one with a short
  wavelength has a high frequency.
• Visible light is an electromagnetic wave that has
  wavelengths between 400 and 700 nanometers!
  (That is, 300 billionths to 700 billionths of a
  meter!)

9

• When you have your teeth x-rayed, the dentist is
  shining an electromagnetic wave with a wavelength
  more than 1,000 times shorter than visible light
• When you listen to the radio, your radio is
  picking up electromagnetic waves almost a million
  times longer than visible light, or about 0.1
  meters.
• The range wavelengths (or frequencies) of
  electromagnetic waves is called the
  electromagnetic spectrum.

10
Courtesy Lawrence Berkeley National Laboratory
11
The Spectrometer
12
(No Transcript)
13
Why does each element have its own fingerprint?
Interaction between light and atoms
What are atoms?
14
Elementary Particles Mass and Charge
Particle Mass Charge
Proton 1.67 x 10-27 Kg 1.6 x 10-19 Coulomb
Neutron 1.67 x 10-27 Kg Neutral
Electron 9.11 x 10-31 Kg -1.6 x 10-19 Coulomb
15
Build a Model of the Hydrogen Atom
Electron
Electron
Proton
16
Bohr Model of the Atom and Energy Levels
17
Bohr Model of the Hydrogen Atom

• Electrons Orbit a Proton
• Electrons exist only in discrete orbits and
  nowhere in between
• When electrons absorb a photon of the correct
  energy, the electron jumps to a higher energy
  level
• When the electron falls to a lower energy level,
  a photon of only one certain energy is emitted
• The emitted photons have a discrete energy,
  frequency or wavelength that we observe in the
  spectrum

18
Sir William Herschel

• More to Light than Meets the eye
• Discovery of Infra-red (1800)
• (Also discovered Uranus in 1787)

19
Herschel Experiment
20
Herschel Exp
13.4oC
14.6 o C
IR MOVIE
21
Spectra

• Continuous Spectrum
• Thermal Radiation
• (black body radiation)
• Atomic collisions result excitation of atoms and
  in emission of energy at multiple frequencies.
• Emission Spectrum
• Excitation of electrons
• High energy level
• Return to ground state produces emission of
  energy
• Energy produced proportional to drop

22
Atomic and Molecular Mechanisms
23
Interpretation of Spectra
24
Atomic and Molecular Mechanisms
25
Jupiter
Infrared
Visible
Radio
26
Formation of 21cm Radio waves(1420 MHz)
27
Visible
Radio at 21 cm
28
Milky Way Galaxy as Seen in Different Parts of
the Spectrum
29
Multi-spectral Astronomy
30
w w w . p a r i . e d u
31
Infrared Movie
