Chlorobi

1
Chlorobi
2
Chlorobium tepidum

• thermophilic Gram-negative green sulfur bacterium

• isolated from a hot spring in New Zealand --
  forms a dense mat
• can fix atmospheric nitrogen
• relies on sulfur compounds for photosynthetic
  processes
• Possesses chlorosomes
• The C. tepidum TLS strain grows optimally at 48C
  with a doubling time of about 2.5 hours

3
(No Transcript)
4
Type 1 reaction centers

• The electron is transferred from the quinone on
  one side to a Fe4S4 cluster in the middle.
• It is then transferred to one of two Fe4S4
  clusters in an extrinsic protein attached to the
  dimeric reaction center.
• Note that the type 1 reaction centers of
  Chlorobium and Heliobacteria are homodimers.

5
(No Transcript)
6
Comparing type 1 and type 2 RCsthe polypeptides
Photosystem I RC proteobacterial RC
7
Comparing type 1 and type 2 RCs

8
Comparing type 1 and type 2 RCs

H2
9
Comparing type 1 and type 2 RCs

1-electron chemistry Quinone(s) are
intermediates Both branches converge at FX
acceptor
10
Bacterial photosynthesis

• Type 1 RC
• reduces ferredoxin (the quinone contained within
  the RC is not mobile)
• ferredoxin can be used by FdNAD oxidoreductase
  (FNR) to reduce NAD(P)
• An enzyme like complex I can be used to pass the
  electrons from NADH to the mobile quinone pool.
  (There is evidence for a Fdquinone
  oxidoreductase in some organisms.)
• Cyt bc transfers electrons from the quinone to
  cyt c, which re-reduces the primary donor of the
  RC.

11
Bacterial photosynthesis

• In order to reduce CO2 (and make carbohydrate),
  it is necessary to have an electron source.
• Anoxygenic photosynthetic bacteria can utilize
  several different electron sources, including H2S
  and Fe2, depending upon the species. (These are
  much easier to oxidize than H2O.)
• Quinone pool is the point of entry. For example,
  the enzyme sulfidequinone oxidoreductase (found
  in several species) catalyzes the reduction of
  quinones using H2S as a reductant H2S Q gt S0
  QH2
• The ways in which bacteria carry out net
  reduction of NADH also differ, depending upon
  their RC.

12
Bacterial photosynthesis

• Type 1 RC
• RC reduces ferredoxin
• FdNAD oxidoreductase (FNR) passes electrons to
  NAD
• Type 2 RC
• also contain a NADHquinone oxidoreductase
  (a.k.a. NADH dehydrogenase).
• Oxidation of quinones drives proton pumping.
• When the proton gradient gets large enough, the
  reverse reaction becomes favorable with
  dissipation of the proton gradient.

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
PS1 vs. other type 1 RCs

• Different antenna systems
• PS1 (plants algae) LHC1
• PS1 (cyanobacteria) phycobilisomes
• Chlorobi chlorosomes
• Heliobacteria nothing (?)

18
(No Transcript)
19
PS1 vs. other type 1 RCs

• The other RCs are simpler homodimeric fewer
  subunits
• PS1 PsaA/B/C/D/E/F/I/J/K/L/M/N (G,H)
• Chlorobi PscA2 PscB(2x Fe4S4) PscC2 PscD(2?)
  (FMO3)2
• PscA core
• PscB 2x Fe4S4 extrinsic protein
  (ferredoxin-like)
• PscC membrane-attached cytochrome
• PscD ? (may be involved with binding PscB,
  ferredoxin, and/or FMO protein)
• FMO link between chlorosome baseplate and RC
• Heliobacteria PshA2 PshB(2x Fe4S4) 1-2?

20
(No Transcript)
21
PS1 vs. other type 1 RCs

• Primary electron acceptor (A0)
• PS1 Chl a
• Chlorobi Chl a
• Heliobacteria 81-OH-Chl a

22
(No Transcript)
23
PS1 vs. other type 1 RCs

• Use of the quinone(s)
• PS1
• Phylloquinones are intermediates
• Not mobile (a benzoquinone is mobile quinone)
• Not normally doubly reduced
• Chlorobi Heliobacteria
• No evidence for use of quinones in electron
  transfer
• See P A0 ? P FX in 700 ps.
• In these bacteria, the menaquinones are the
  mobile quinone

24
Photovoltage effect
25
(No Transcript)
