Advantages of SHDSL

• Reach more customers
• Increases the range of DSL services by 30
• Faster speeds over existing copper wire
• 2.3 Mbps over 2-wire
• 4.6 Mbps over 4-wire
• Converge multiple services
• Integrates voice, data, LAN, and Internet access
• Standards-based
• Complies with ITU and ETSI SHDSL standards
• Interoperable with third-party equipment
• RAD offers full range of compatible products with
  SHDSL interfaces

ASMi-52C
FCD-E1/IP
ASMi-52
DXC-D8SL
LRS-52
IMXi-4
3
The ASMi-52 SHDSL Modem
Maximize existing copper performance with RADs
ASMi-52 SHDSL modem! Main features
4
ASMi-52 Target Market

• RADs SHDSL solutions suit a variety of markets
• Railways, Highway operators
• Carriers with SDH/SONET networks
• Municipal, Utility and Corporate markets
• Cellular market - Mobile carriers
• Carriers with IP networks
• System integrators
• See how ASMi-52 maximizes the performance of
  copper wire in the following applications

5
Railway Application

• Business Objectives
• Connect Closed Circuit TV (CCTV) cameras for
  observation and security
• Connect advertisement and passenger information
  displays at stations
• Connect signaling and traffic control equipment

• Winning Features
• Simple and effective solution
• Very long range
• Built-in Ethernet port
• Solution for existing copper
• Meets EN 50121-4 industry standard

S-RPT Repeater
CCTV
ASMi-52
ASMi-52
Control
SHDSL
ETH
SHDSL
ASMi-52
ASMi-52
SHDSL
ETH
SHDSL
S-RPT Repeater
S-RPT can be locally powered via 2-wire
6
Highway/Expressway Application

• Business Objectives
• Connect electronic traffic information displays
• Connect traffic control cameras
• Central control
• Very long distances

• Winning Features
• LAN extension over SHDSL for electronic display
  panels
• SNMP/Telnet for remote/central management
• 2/4-wire operation
• Cost-effective for mass deployment

Traffic Information Panel
Traffic Information Panel
Traffic Information Panel
Highway
ETH
ETH
ETH
Control Room
SHDSL
ASMi-52
ASMi-52
ASMi-52
ASMi-52
ASMi-52
7
Bank Application

• Business Objectives
• Connect different branch offices (router network)
  in star/daisy-chain topology
• Provide maximum bandwidth and range over 2-wire
  copper
• Reduce spending on equipment

• Winning Features
• High performance and reliability
• X.21 interface
• Excellent price/performance ratio
• Master-master operation
• Wide range of interface options
• Optional 4-wire version for higher throughput

Bank
ASMi-52
ASMi-52
Branch Office
Branch Office
Branch Office
Router
ASMi-52
Router
Router
ASMi-52
X.21
X.21
X.21
X.21
ASMi-52
ASMi-52
8
Corporate Data Voice over Copper

• Business Objectivities
• Connect Voice and Data services between corporate
  sites over 2-wire lines

• Winning Features
• More cost-effective than HDSL alternative
• High reliability

Router
ASMi-52
ASMi-52
Router
V.35
Copper 2-wire
V.35
ASMi-52
ASMi-52
PBX
PBX
E1
E1
Copper 2-wire
9
Cost-effective Voice Extension over Analog Leased
Lines

• Type of business
• Voice over analog leased lines
• Corporative PBX interconnection

• Key Selling Points / Benefits
• Optimal bandwidth utilization working with RADs
  Vmux-110 voice compression gateways
• Fast and easy installation
• Quick return on investment (ROI)

Central Site
Remote Site
8 Phones
PBX
PBX
Vmux-110
ASMi-52
ASMi-52
Vmux-110
E1 CAS
E1 CAS
Analog Leased line
ETH
SHDSL
SHDSL
ETH
10
Provisioning of Leased Lines for Low Speed
Services

• Business Objectives
• Provisioning of SDH E1 leased lines for low speed
  services
• Central management
• Low-cost solution

• Winning features
• Flexible solution
• One stop solution works together with RADs
  DXC, Megaplex, FCD, and other ASMi devices
• Several user interfaces available for variety of
  services

ASMi-52/V.35
SHDSL
DXC-8R/30
FCD-E1M
E1s
SDH Network
N x V.35
E1
ASMi-31
MP-2104
V.35/G.703 (64 kbps)
E1
2-wire
E1s
ASMi-31
V.24/V.35/G.703 (64 kbps)
MP-2100
V.35/G.703 (64 kbps)
ASMi-31
V.35/G.703 (64 kbps)
2-wire
11
Last Mile SHDSL Access

• Business Objectives
• Offer low-cost 2 Mbps and V.35 services over
  copper to compete with competitors services over
  fiber

• Winning features
• Excellent product that fill the client
  requirements
• 0 fault-reliability and high performance
• Fast deployment

Fractional E1 (n x 64 kbps) service
Fractional E1 (n x 64 kbps) service
Branch Office
Branch Office
Router
Router
ASMi-52
ASMi-52
PBX
PBX
ASMi-52
ASMi-52
Backbone
SHDSL
SHDSL
SOHO
SOHO
CopperDeployment
ASMi-52
ASMi-52
SHDSL
SHDSL
ASMi-52
ASMi-52
PBX
PBX
12
Voice and Data Extension over Wireless

• Business Objectives
• Voice and data extension to remote locations
• Compatible with the V5.2 protocol

• Winning Combination
• Uniqueness
• Performance
• Flexibility
• One stop solution works together with RADs DXC
  and Megaplex Multiservice Access Nodes

Remote Site type A
MP-2100
Central Office
48 x FXS
VC-16/ FXS
ML-E1
Alcatel Switch
E1-V5.2
DXC-30
HS-U
64-128 kbps
E1-V5.2
ASMi-31
64-128 kbps
HS-U
64-128 kbps
ASMi-31
ASMi-52
64-128 kbps
ASMi-52
Remote Site type B
E1-V5.2
MP-2100
VC-16/ FXS
60 x FXS
E1-V5.2
13
Rail-Mount Installation for ASMi-52

• Metal case version for rail-mounting
• Features
• Tough metal box
• Attaches to standard cabinet rail mounts
• Can be mounted with all line and power cables
  connectors towards any side
• Withstands temperatures between -20 and 70C(-4
  to 158F)
• Several management options DTS, Ethernet
  out-of-band port, ConfiguRAD
• Also available for 24 VDC power operation
• Alarm relay port
• Answering market needs
• Meets Industrial/Utility application requirements

• Rugged design
• Cost-effective solution
• Easy installation in existing cabinets

Special size 150 x 160 x 70 mm
14
S-RPT Repeater

• RADs SHDSL Repeater for Longer Reach
• Doubles range of ASMi-52 transmission
• Maximum speed over 2-wire is 2.048 Mbps
• Maximum distance at 2.048 Mbps 15.6 km/9.5 miles
  (over 26 AWG)using 6 repeaters on the line
  tested noise-free
• Can be remotely powered over 2-wire line
• Diagnostic loopback can be remotely activated on
  each repeater from the Central side
• Available in indoor and outdoor (IP67 protected)
  version

S-RPT Repeater
ASMi-52
ASMi-52
LAN
SHDSL
SHDSL
Up to 8 Repeaters can be installed on the line
per the SHDSL standard
