Processes

1
Processes

• Chapter 3

2
Processes

• Topics discussed in this chapter
• Threads improve performance.
• In distributed systems threads allow clients and
  servers to be constructed such that communication
  and local processing can overlap.
• Clients various GUI systems.
• Servers object servers
• Code migration can help achieve scalability and
  dynamically configure clients and servers.
• Software agents are a type of process which
  attempt to reach a common goal.

3
Introduction to Threads

• Basic idea An operating system creates virtual
  processors in software on top of physical
  processors.
• A processor provides the capability of executing
  a series of instructions.
• A process is a program in execution.
• A software processor in whose context one or more
  threads may be executed. Executing a thread means
  executing a series of instructions in the context
  of that thread.
• A thread is the execution of a part of a program.

• A thread maintains the minimal information to
  allow a CPU to be shared by several threads.
• A thread context consists of the CPU context and
  the information for the thread.
• Saving a thread context implies stopping the
  current execution and saving all the data needed
  to continue the execution at a later stage.

4
Context Switching

• Processor context The minimal collection of
  values stored in the registers of a processor
  used for the execution of a series of
  instructions (e.g., stack pointer, addressing
  registers, program counter).
• Process context The minimal collection of values
  stored in registers and memory, used for the
  execution of a series of threads (i.e., thread
  context, but now also at least MMU register
  values).
• Thread context The minimal collection of values
  stored in registers and memory, used for the
  execution of a series of instructions (i.e.,
  processor context, state).

5
Thread Usage in Nondistributed Systems

• Context switching as the result of IPC

6
Context Switching

• Observation 1 Threads share the same address
  space. Thread context switching can be done
  entirely independent of the operating system.
• Observation 2 Process switching is generally
  more expensive as it involves getting the OS in
  the loop, i.e., trapping to the kernel.
• Observation 3 Creating and destroying threads is
  much cheaper than doing so for processes.

7
Threads and Operating Systems

• Main issue Should an OS kernel provide threads,
  or should they be implemented as user-level
  packages?
• User-space solution
• We'll have nothing to do with the kernel, so all
  operations can be completely handled within a
  single process. ?Implementations can be extremely
  efficient.
• All services provided by the kernel are done on
  behalf of the process in which a thread resides.
  ? If the kernel decides to block a thread, the
  entire process will be blocked. Requires messy
  solutions.
• In practice we want to use threads when there are
  lots of external events threads block on a
  per-event basis ? If the kernel can't distinguish
  threads, how can it support signaling events to
  them.

8
Threads and Operating Systems

• Kernel solution The whole idea is to have the
  kernel contain the implementation of a thread
  package. This does mean that all operations
  return as system calls.
• Operations that block a thread are no longer a
  problem the kernel schedules another available
  thread within the same process.
• Handling external events is simple the kernel
  (which catches all events) schedules the thread
  associated with the event.
• The big problem is the loss of efficiency due to
  the fact that each thread operation requires a
  trap to the kernel.
• Conclusion Try to mix user-level and
  kernel-level threads into a single concept.

9
Solaris Threads

• Basic idea Introduce a two-level threading
  approach user-level processes and light-weight
  processes (LWP) that can execute user-level
  threads in the kernel.
• When a user-level thread does a system call, the
  LWP that is executing that thread blocks. The
  thread remains bound to the LWP.
• The kernel can simply schedule another LWP having
  a runnable thread bound to it. Note that this
  thread can switch to any other runnable thread
  currently in user space.
• When a thread calls a blocking user-level
  operation, we can simply do a context switch to a
  runnable thread, which is then bound to the same
  LWP.
• When there are no threads to schedule, a LWP may
  remain idle, and may even be removed (destroyed)
  by the kernel.

10
Thread Implementation

• Combining kernel-level lightweight processes and
  user-level threads.

11
Threads and Distributed Systems

• Multithreaded clients To establish a high degree
  of distribution transparency, distributed systems
  need hiding network latencies (so that the user
  is not knowing there is a interprocess
  communication across a wide-area network).
• Example Multithreaded Web Client
• A Web browser scans an incoming HTML page, and
  finds that more files need to be fetched.
• Each file is fetched by a separate thread, each
  doing a (blocking) HTTP request.
• As files come in, the browser displays them.
• Example Multiple RPCs
• A client does several RPCs at the same time, each
  one by a different thread.
• It then waits until all results have been
  returned.
• Note If RPCs are to different servers, we may
  have a linear speed-up compared to doing RPCs one
  after the other.

12
Threads and Distributed Systems

• Multithreaded servers Main issues are improving
  performance and better programming structure.
• Improve performance
• Starting a thread to handle an incoming request
  is much cheaper than starting a new process.
• Having a single-threaded server prohibits simply
  scaling the server to a multiprocessor system.
• Servers hide network latency by reacting to next
  request while previous one is being replied.
• Better programming structure
• Most servers have high I/O demands. Using simple,
  well-understood blocking calls simplifies the
  overall structure.
• Multithreaded programs tend to be smaller and
  easier to understand due to simplified flow of
  control.

13
Multithreaded Servers

• A multithreaded server organized in a
  dispatcher/worker model.

14
Multithreaded Servers
Model Characteristics
Threads Parallelism, blocking system calls
Single-threaded process No parallelism, blocking system calls
Finite-state machine Parallelism, nonblocking system calls

• Three ways to construct a server.

15
Clients - User Interfaces

• Essence
• A major task of most clients is to interact with
  a human user and a remote server.
• A major part of client-side software is focused
  on (graphical) user interfaces.
• The X Window System is used to control bit-mapped
  terminals.

16
The X Window System

• The heart of the system is formed by the X
  kernel. It contains all the terminal-specific
  device drivers.
• The X kernel interface for controlling the screen
  is made available to applications in the Xlib
  library.
• There are two types of X applications ordinary
  applications and window managers.
• A window manager is an application that is given
  special permission to manipulate the entire
  screen.
• The X protocol is a network-oriented
  communication protocol by which an instance of
  Xlib can exchange data and events with the X
  kernel.
• The client which runs only the X kernel is called
  X terminals.

17
The X-Window System

• The basic organization of the X Window System

18
User Interfaces Compound Documents

• Modern user interfaces allow applications to
  share a single graphical window and use that
  window to exchange data through user actions.
• Compound documents are a collection of documents
  which are seamlessly integrated at the
  user-interface level. Make the user interface
  application-aware to allow inter-application
  communication
• drag-and-drop move objects to other positions on
  the screen, possibly invoking interaction with
  other applications. Drag a file to drop in a
  trash can.
• in-place editing integrate several applications
  at user-interface level (word processing
  drawing facilities). Edit an image in a text
  document.

19
Client-Side Software

• In many cases, a part of processing is executed
  on the client side.
• Essence Client software comprises components for
  achieving distribution transparency.
• Access transparency is handled through
  client-side stubs for RPCs and RMIs.
• Location/migration transparency can be handled by
  letting client-side software keep track of actual
  location.
• Replication transparency can be achieved by
  forwarding an invocation request to multiple
  replica.
• Failure transparency can often be placed only at
  client (we're trying to mask server and
  communication failures).
• Concurrency transparency can be handled through
  special intermediate servers (transaction
  monitors).

20
Client-Side Software for Distribution Transparency

• A possible approach to transparent replication of
  a remote object using a client-side solution.

21
Servers

• Basic model
• A server is a process implementing a specific
  service on behalf of a collection of clients.
• A server is a process that waits for incoming
  service requests at a specific transport address.

• In practice, there is a one-to-one mapping
  between a port (endpoint) and a service.
• How do clients know the endpoint of a service?
• Endpoints for well-known services are globally
  assigned by the Internet Assigned Numbers
  Authority (IANA).
• DCE uses a special daemon which listens to a
  known port and keeps track of the current
  endpoint of each service. A client contact the
  daemon, request the endpoint, and then contact
  the specific server.

22
Servers - General Organization

• Iterative vs. concurrent servers Iterative
  servers itself handles the request itself and can
  handle only one client at a time. A concurrent
  server does not handle the request itself but
  pass it to a separate thread or another process.
• Superservers Servers that listen to several
  ports, i.e., provide several independent
  services. In practice, when a service request
  comes in, they start a subprocess to handle the
  request (UNIX inetd)

23
Servers General Design Issues
3.7

1. Client-to-server binding using a daemon as in DCE
2. Client-to-server binding using a superserver as
   in UNIX

24
Out-of-Band Communication

• Issue Is it possible to interrupt a server once
  it has accepted (or is in the process of
  accepting) a service request?
• Non-Solution Exit the client application and
  restart it.
• Solution 1Use a separate port for urgent data
  (possibly per service request)
• The Server has a separate thread (or process)
  waiting for incoming urgent messages.
• When the urgent message comes in, the other
  request is put on hold.
• Note The OS is required to support high-priority
  scheduling of specific threads or processes.
• Solution 2Use out-of-band communication
  facilities of the transport layer.
• Example TCP allows to send urgent messages in
  the same connection.
• Urgent messages can be caught using OS signaling
  techniques.

25
Servers and State

• Stateless servers never keep information on the
  state of a client.
• Don't record whether a file has been opened
  (simply close it again after access).
• Don't promise to invalidate a client's cache.
• Don't keep track of the clients.
• Example Web servers.
• Consequences
• Clients and servers are completely independent.
• State inconsistencies due to client or server
  crashes are reduced.
• Possible loss of performance because, e.g., a
  server cannot anticipate the client behavior
  (think of prefetching file blocks).
• Question Does connection-oriented communication
  fit into a stateless design?
• Stateful connections do not violate the
  statelessness of servers.

26
Servers and State

• Stateful servers keep track of the state of their
  clients.
• Record a file that has been opened, so that
  prefetching can be done.
• Know which data a client has cached, and allows
  clients to keep local copies of shared data.
• Observation The performance of stateful servers
  can be extremely high, provided clients are
  allowed to keep local copies.
• Consequence If the server crashes, a stateful
  server needs to recover its entire state before
  its crash. Enabling recovery introduces
  complexity.
• A stateless server can use a cookie. It is a
  small piece of data containing the client
  information which is stored on the client.
• Example Web browser.

27
Object Servers

• An object server is a server tailored to support
  distributed objects.
• An object server by itself does not really
  provide a specific service.
• Specific services are implemented by the objects
  that reside in the server.
• It is easy to change services by simply adding
  and removing objects.
• An object server acts as a place where objects
  live.
• An object consists of two parts data
  representing its state and code forming the
  implementation of its methods.

28
Object Servers

• Invoking objects
• Use a uniform way to invoke objects such as DCE.
  It is inflexible and constrains developers.
• Support different policies
• Object invocation
• Invoke a (transient) object one at a time
  (consuming time to invoke objects).
• Invoke all objects at a time (consuming
  resource).
• Data sharing
• Objects share neither data nor code. (e.g.
  separate security policies)
• share code (e.g. database object that access a
  database).
• Threading A thread per object (adv. concurrent
  control) or a thread per method.

29
Object Adapter

• Decisions on how to invoke an object are referred
  to as activation policies.
• A mechanism to group objects per policy is called
  an object adapter, or object wrapper.
• An object adapter can best be thought of as
  software implementing a specific activation
  policy.
• An object adapter has one or more objects under
  its control. Several object adapters (each
  adapter represent a different activation policy)
  may reside in the same server.

30
Object adapter

• Object adapter The manager of a set of
  objects
• Inspects (as first) incoming requests.
• Ensures referenced object is activated (requires
  identification of servant).
• Passes request to appropriate skeleton, following
  specific activation policy.
• Responsible for generating object references.
• Observation Object servers determine how their
  objects are constructed.

31
Object Servers

• Skeleton Server-side stub for handling network
  I/O
• Generated from interface specifications
• Unmarshall incoming requests, and call the
  appropriate servant code.
• Marshall results and send the reply message.
• Servant The actual implementation of an object,
  sometimes containing only method implementations
• Collection of C, Fortran, or COBOL functions,
  that act on structs, records, database tables,
  etc.
• Java or C classes

32
Object Adapter

• Organization of an object server supporting
  different activation policies.

33
Object Adapter Implementation

• Consider an object adapter that manages a number
  of objects. The adapter implements the policy
  that it has a single thread of control fro each
  of its objects.
• Object adapter implementation
• The header file of the adapter (e.g. header.h)
• The thread library (e.g. thread.h)
• The implementation code of a thread-per-object
• The request demultiplexer can be replaced by an
  object adapter. CORBA uses this approach.

34
Object Adapter
/ Definitions needed by caller of adapter and
adapter /define TRUEdefine MAX_DATA 65536 /
Definition of general message format /struct
message long source / senders identity
/ long object_id / identifier for the
requested object / long method_id /
identifier for the requested method /
unsigned size / total bytes in list of
parameters / char data / parameters as
sequence of bytes / / General definition of
operation to be called at skeleton of object
/typedef void (METHOD_CALL)(unsigned, char
unsigned, char) long register_object
(METHOD_CALL call) / register an object
/void unrigester_object (long object)id) /
unrigester an object /void invoke_adapter
(message request) / call the adapter /

• The header.h file used by the adapter and any
  program that calls an adapter.

35
Object Adapter
typedef struct thread THREAD / hidden
definition of a thread / thread CREATE_THREAD
(void (body)(long tid), long thread_id)/
Create a thread by giving a pointer to a function
that defines the actual // behavior of the
thread, along with a thread identifier / void
get_msg (unsigned size, char data)void
put_msg(THREAD receiver, unsigned size, char
data)/ Calling get_msg blocks the thread
until of a message has been put into its //
associated buffer. Putting a message in a
thread's buffer is a nonblocking // operation.
/

• The thread.h file used by the adapter for using
  threads.

36
Object Adapter

• The main part of an adapter that implements a
  thread-per-object policy.

37
Code Migration

• Reasons for migrating code
• Overall system performance can be improved if
  processes are moved from heavily-loaded to
  lightly-loaded machines.
• Code migration makes sense to process data close
  to where those data reside.
• Code migration exploits parallelism.
• Flexibility dynamically configuring distributed
  systems.

38
Code Migration

• Dynamically configuring distributed systems
• The code is available to the client at the time
  the client application is being developed.
• The code is downloaded when required.
• Advantages
• Clients need not have all the software
  preinstalled.
• The client-server protocol and its implementation
  can be changed as requested.
• Disadvantages It is not secure to blindly trust
  the downloaded code.

39
Reasons for Migrating Code

• The principle of dynamically configuring a client
  to communicate to a server. The client first
  fetches the necessary software, and then invokes
  the server.

40
Models for Code Migration

• Object components Fugetta et al., 1998
• Code segment contains the set of instructions.
• Data segment contains the data references such as
  files, printers, devices, other processes, and
  more.
• Execution segment contains current execution
  state of a process, consisting of private data,
  the stack, and the programming counter.
• Weak mobility Move only code and data segment
  and start execution from the beginning after
  migration
• Relatively simple, especially if code is portable
• Example Java applets.

41
Models for Code Migration

• Strong mobility The execution segment can be
  transferred as well.
• Migration move the entire object from one
  machine to the other.
• Cloning simply start a clone, and set it in the
  same execution state.
• Example DAgents
• In sender-initiated migration, the migration is
  initiated at the machine where the code currently
  resides or is being executed. Examples
• Uploading code to the sever The clients need to
  be registered and authenticated at the server.
• Sending a search program across the Internet to a
  Web database server to perform the queries at
  that server.

42
Models for Code Migration

• In receiver-initiated migration, the initiative
  for code migration is taken by the target
  machine. Examples
• Java applets
• Downloading code can often be done anonymously.
• The migrated code can be executed
• At the target process
• For example, Java applets are downloaded and
  executed in the browsers address space.
• The advantage is no separate process is required.
  The drawback is the target process needs to
  protect against malicious code.
• In a new separate process
• It has the resource-access problems.

43
Models for Code Migration

• Alternatives for code migration.

44
Managing Local Resources

• Problem The resource segment cannot be simply
  transferred without change. An object uses local
  resources that may or may not be available at the
  target site. Examples
• Port The migrated code gives up the port and
  requests a new one at the destination.
• URL remains valid irrespective of the code
  migration.
• Object-to-resource binding Fuggetta et al.
• By identifier The object requires a specific
  instance of a resource (e.g. a URL, FTP servers
  Internet address).
• By value The object requires the value of a
  resource (e.g. standard libraries).
• By type The object requires that only a type of
  resource is available (e.g. a local device such a
  color monitor, a printer).
• Resource types
• Unattached The resource can easily be moved
  along with the object (e.g. a data file).
• Fastened The resource can, in principle, be
  migrated but only at high cost (e.g. local
  databases and Web site).
• Fixed The resource cannot be migrated, such as
  local devices or communication endpoint.

45
Migration and Local Resources
Resource-to machine binding
Unattached Fastened Fixed
By identifier By value By type MV (or GR) CP ( or MV, GR) RB (or GR, CP) GR (or MV) GR (or CP) RB (or GR, CP) GR GR RB (or GR)
Process-to-resource binding

• Actions to be taken with respect to the
  references to local resources when migrating code
  to another machine.
• MV Move the resource
• GR establish a Global system-wide Reference
• CP Copy the value of the resource
• RB Rebind process to locally available resource

46
Managing Local Resources

• Scenario of binding by identifier with unattached
  resource
• When a process is bound to a resource by
  identifier and the resource is unattached, it is
  best to move it along with the migrating code.
• If the resource is shared by other processes, a
  global reference can be established. But the cost
  of the global reference might be high (Consider
  the situation if the resource is a video stream).

47
Managing Local Resources

• Scenario of binding by identifier with fixed
  resource
• When migrating a process that is making use of a
  local communication endpoint.
• Two possible solution
• Set up a connection to the source machine after
  it has migrated and has a proxy process at the
  target machine. What happens if the source
  machine malfunctions?
• Change their global reference, and send messages
  to the new communication endpoint at the target
  machine.

48
Managing Local Resources

• Scenario of binding by value
• Unattached resource copying the resource to the
  new destination is better than a global
  reference.
• Fasten resource Establishing a global reference
  is better than copying runtime libraries.
• Fixed resource A process assumes that memory can
  be shared between processes. Establishing a
  global reference needs to implement distributed
  shared memory.
• Scenario of binding by type
• The obvious solution is to rebind the process to
  a locally available resource of the same type.

49
Migration in Heterogeneous Systems

• Main problem
• The target machine may not be suitable to execute
  the migrated code.
• The definition of processor/process/thread
  context is highly dependent on local hardware,
  operating system, and runtime system (e.g.
  platform-specific data).
• For weak mobility it suffices to recompile the
  source. For strong mobility the execution segment
  is also migrated. The recompilation is not enough.

50
Migration in Heterogeneous Systems

• Solution (migration stack)
• The migration stack is the copy of the program
  stack maintained on the runtime system.
• Existing languages allow migration at specific
  transferable points, such as just before a
  function call.
• Solution (virtual machine) Make use of an
  abstract machine that is implemented on different
  platforms.
• Interpreted languages running on a virtual
  machine (Java/JVM scripting languages)

51
Migration in Heterogeneous Systems
3-15

• The principle of maintaining a migration stack to
  support migration of an execution segment in a
  heterogeneous environment

52
Example D'Agents

• DAgents formerly called Agent Tcl (Tool Command
  Language), is a system that is built around the
  concept of an agent. Refer to http//agent.cs.dart
  mouth.edu/
• An agent in DAgents is a program that can
  migrate between different machines. Programs can
  be written in an interpretable language such as
  Tcl, Java, or Scheme.

53
D'Agents

• D'Agents provides support for
• Sender-initiated weak mobility (agent_submit
  command)
• Strong mobility by process migration (agent_jump
  command)
• Strong mobility by process cloning (agent_fork
  command)

54
Overview of Code Migration in D'Agents
proc factorial n if (n ? 1) return 1
fac(1) 1 expr n factorial expr n
1 fac(n) n fac(n 1) set number
tells which factorial to compute set machine
identify the target machine agent_submit
machine procs factorial vars number script
factorial number agent_receive receive
the results (left unspecified for simplicity)

• A simple example (send-initiated weak mobility)
  of a Tcl agent in D'Agents submitting a script to
  a remote machine (adapted from gray.r95)
• agent_receive is blocked until the result is
  received.

55
Overview of Code Migration in D'Agents
all_users machines proc all_users machines
set list "" Create an initially empty list
foreach m machines Consider all hosts in
the set of given machines agent_jump
m Jump to each host set users exec
who Execute the who command append
list users Append the results to the list
return list Return the complete list
when done set machines Initialize the set
of machines to jump toset this_machine Set to
the host that starts the agent Create a
migrating agent by submitting the script to this
machine, from where it will jump to all the
others in machines. agent_submit this_machine
procs all_users -vars machines -script
all_users machines agent_receive receive
the results (left unspecified for simplicity)

• An example (send-initiated strong mobility) of a
  Tcl agent in D'Agents migrating to different
  machines where it executes the UNIX who command
  (adapted from gray.r95)
• agent_jump allows the process to move to other
  machine.

56
D'Agents

• Organization Each machine is built as a
  five-layered system
• TCP/IP and E-mail layer implements a common
  interface to the communication facilities of the
  underlying network.
• Server layer is responsible for agent management,
  authentication, and communication management
  between agents.
• Agent Run Time System (Core) layer consists of a
  language-independent core that supports the basic
  model of agents such as starting and ending an
  agent.
• Language interpreter layer consists of the
  language interpreter, a security module, an
  interface to the core layer, a module to capture
  the state of a running agent.
• Agent layer Each agent is executed by a separate
  process.

57
Implementation Issues

• The architecture of the D'Agents system.

58
D'Agents

• The more difficult part in the implementation of
  DAgents, is capturing the state of a running
  agent and shipping that state to another machine.
• There are four tables containing global
  definitions of variables and scripts, and two
  stacks for keeping track of the execution status.
• When an agent calls agent_jump, by which the
  agent migrates to another machine.
• The complete state of the agent as just described
  is marshaled into a series of bytes.
• The DAgents server on the target machine
  subsequently creates a new process to handle the
  marshaled data, which is then unmarshals into the
  state when the agent called agent_jump.

59
Implementation Issues
Status Description
Global interpreter variables Variables needed by the interpreter of an agent
Global system variables Return codes, error codes, error strings, etc.
Global program variables User-defined global variables in a program
Procedure definitions Definitions of scripts to be executed by an agent
Stack of commands Stack of commands currently being executed
Stack of call frames Stack of activation records, one for each running command

• The parts comprising the state of an agent in
  D'Agents.

60
What is a Software Agent?

• Definition An autonomous process capable of
  reacting to and initiating changes in its
  environment, and of performing a task in
  collaboration with users and other (remote)
  agents.
• The feature that makes an agent more than just a
  process is its capability to
• act on its own and take initiative where
  appropriate
• cooperate with other agents

61
Taxonomy of Agents

• It seems hard for researchers to reach agreement
  on a single taxonomy
• collaborative agent collaborate with others in a
  multiagent system.
• A multiagent system is a system in which agents
  seek to achieve some common goal through
  collaboration.
• Example Agents collaborate in setting up a
  meeting
• mobile agent can move between machines
• Example Agents which retrieve information
  distributed on the Internet
• interface agent assist users in the use of one
  or more applications (usually with learning
  ability).
• Example agents which seek to bring buyers an
  sellers together.
• information agent manage information from
  physically different sources
• Example e-mail agent, mobile information agent.

62
Software Agents in Distributed Systems
Property Common to all agents? Description
Autonomous Yes Can act on its own
Reactive Yes Responds timely to changes in its environment
Proactive Yes Initiates actions that affects its environment
Communicative Yes Can exchange information with users and other agents
Continuous No Has a relatively long lifespan
Mobile No Can migrate from one site to another
Adaptive No Capable of learning

• Some important properties by which different
  types of agents can be distinguished.

63
Agent Technology

• The Foundation for Intelligent Physical Agent
  (FIPA) is developing a general model for software
  agents FIPA, 1998b (http//www.fipa.org/)
• In this model, agents are registered at, and
  operate under the management of an agent
  platform
• Management Keeps track of where the agents on
  this platform are.
• creating and deleting agents.
• mapping globally unique agent ID to a local
  communication endpoint (port)
• Directory Mapping of agent names and attributes
  to agent IDs
• ACC Agent Communication Channel, used to
  communicate with other platforms
• Communication between ACCs on different platforms
  follows Internet Inter-ORB Protocol (IIOP).
• Example server in D'Agents

64
Agent Technology

• The general model of an agent platform (adapted
  from fipa98-mgt).

65
Agent Language

• Communication between agents takes place by means
  of an application-level communication protocol,
  which is referred to as an agent communication
  language (ACL).
• ACL makes distinction between purpose and content
  of a message.

66
Agent Language

• An ACL message can have a limited number of
  purposes.
• A message consists of
• a header
• Identifier of the purpose of message,
• Fields for identifying the sender and receiver,
• A field to identify the language or encoding
  scheme,
• A field to identify a standardized mapping of
  symbols to their meaning. Such a mapping is
  called ontology.
• the actual content.

67
Agent Communication Languages
Message purpose Description Message Content
INFORM Inform that a given proposition is true Proposition
QUERY-IF Query whether a given proposition is true Proposition
QUERY-REF Query for a give object Expression
CFP Ask for a proposal Proposal specifics
PROPOSE Provide a proposal Proposal
ACCEPT-PROPOSAL Tell that a given proposal is accepted Proposal ID
REJECT-PROPOSAL Tell that a given proposal is rejected Proposal ID
REQUEST Request that an action be performed Action specification
SUBSCRIBE Subscribe to an information source Reference to source

• Examples of different message types in the FIPA
  ACL fipa98-acl, giving the purpose of a
  message, along with the description of the actual
  message content.

68
Agent Communication Languages
Field Value
Purpose INFORM
Sender max_at_http//fanclub-beatrix.royalty-spotters.nl7239
Receiver elke_at_iiop//royalty-watcher.uk5623
Language Prolog
Ontology genealogy
Content female(beatrix),parent(beatrix,juliana,bernhard)

• A simple example of a FIPA ACL message sent
  between two agents using Prolog to express
  genealogy information.
