TDM PWs

• Yaakov (J) Stein
• Chief Scientist
• RAD Data Communications

2
Outline

• 1) Pseudowires
• 2) Emulating TDM
• 3) TDMoIP encapsulation formats
• 4) TDM signaling transport
• 5) Timing recovery
• 6) Packet loss and mis-ordering

3
Pseudowires
Pseudowire (PW) A mechanism that emulates the
essential attributes of a native service while
transporting over a packet switched network (PSN)
4
The old model (X.200, OSI)

• Once upon a time networks were exclusively
  described by
• the OSI model
• However
• few networks actually work only that way
• highly inflexible (always need more layers!)
• some features only in one place (security, mux)
• missing features (OAM)
• doesnt help to design transport networks

5
Simple telephony counter-example
OSI application layer
?
OSI physical layer

• this type of scenario important to carriers, and
  thus to ITU-T
• not captured by ISO layering model
• there can be an arbitrary large number of
  intervening layers
• all intermediate layers fulfill the same function
  -- transport

6
The new model (G.805)

• A more general and applicable model for transport
  networks
• Layer network and trail
• Layering and partition
• Basic network modes
• Interworking
• Diagrammatic technique
• References
• G.805 generic G.705 PDH G.732 ATM
• G.806 CO networks G.781 timing G.8010
  Ethernet
• G.809 CL networks G.783 SDH G.8110 MPLS

7
Layer networks

• Layering
• Network may be decomposed (vertically) into layer
  networks
• Client-server relationship between adjacent layer
  networks
• Layer network
• Basic topological component for information
  transfer
• Link in layer network supported by network below
• Layer network provides link connection to layer
  above
• Layers are completely independent
• Trail
• Transport entity in layer network
• Contains client payload and OAM
• Partitioning
• Network may be decomposed (horizontally) into
  subnetworks connected by links
• Recursively, each subnetwork is similarly
  decomposed
• Peer-peer relationship between adjacent
  subnetworks

8
Network Modes
Circuit Switched (CS)
Packet Switched (PSN)
Connection Oriented (CO)
Connectionless (CL)

• Many native network types (technologies) for each
  mode
• CS TDM, PDH, SDH, OTN
• CO ATM, FR, MPLS, TCP/IP, SCTP/IP
• CL UDP/IP, IPX, Ethernet, CLNP
• Can layer any mode over any mode
• BUT some layerings may involve performance loss
• CL over CO over CS is EASY
• CO over CL, or CS over CO is harder
• CS over CL is very hard

9
Network interworking (tunneling)

• Network interworking may be provided by tunneling
  (edge to edge)
• Service Interworking requires more complex
  mechanisms

10
PseudoWire Emulation Edge to Edge PWE3
Pseudowire (PW) mechanism that emulates
essential attributes of a native service while
transporting over a PSN
Customer Edge (CE)
Customer Edge (CE)
Providers PSN
Customer Edge (CE)
Provider Edge (PE)
Provider Edge (PE)
Customer Edge (CE)
Customer Edge (CE)
native service
PseudoWires (PWs)
native service
11
Emulating TDMFrom PSTN to PSN
12
Classic Telephony
Access Network
Core (Backbone) Network
analog lines
SONET/SDH NETWORK
T1/E1
extensions
Synchronous Non-packet network
T1/E1 or AAL1/2

• Circuit switched ensures signal integrity
• Very High Reliability (five nines)
• Low Delay and no noticeable echo
• Timing information transported over the network
• Mature Signaling Protocols (over 3000 features)

13
A few G.XXX sayings

• G.114 (One-way transmission time)
• delay lt 150 ms acceptable
• 150 ms lt delay lt 400 ms conditionally
  acceptable
• delay gt 400 ms unacceptable
• G.126/G.131 echo control may be needed
• G.823/G.824 (timing)
• primary vs. secondary clocks
• jitter masks
• wander masks
• G.826 (error performance)
• BER better than 2 10-4
• strict limitation on errored seconds

14
TDM PWs
Access Network
analog lines
Packet Switched Network
T1/E1/T3/E3
extensions
Asynchronous network No timing information
transfer
T1/E1 or AAL1/2

• TDMoIP replaces CS core with a PSN
• The access networks and their protocols remain !
• TDM Pseudowire
• Can G.xxx compliance be maintained?

15
Network Comparison

• TDM
• Circuit switched
• Guaranteed BW
• Low overhead
• Minimal delay
• Constant arrival rate
• Timing transport
• No information loss

• PSN
• Connection oriented / connectionless
• Shared BW
• High overhead
• Delay (introduced by forwarding)
• Packet delay variation (and bursts)
• No physical layer clock
• Packet loss (congestion, errors)

16
TDMoIP Protocol Processing

• Steps in TDMoIP
• The synchronous bit stream is segmented
• The TDM segments are adapted
• TDMoIP control word is prepended
• PSN (IP/MPLS) headers are prepended
  (encapsulation)
• Packets are transported over PSN to destination
• PSN headers are utilized and stripped
• Control word is checked, utilized and stripped
• TDM stream is reconstituted (using adaptation)
  and played out

17
TDMoIP vs. VoIP

• Two ways to integrate TDM services into PSNs
• VoIP
• Revolution - complete (forklift) CPE replacement
• New signaling protocols (translation needed)
• New functionality (e.g. video-phone, presence)
• TDMoIP
• Evolution - CPE unchanged, IWF added at edge
• No change to signaling protocols (network IW)
• No new functionality
• Migration path

18
TDMoIP encapsulation formats
19
TDMoIP layering structure
PSN / multiplexing
Optional RTP header
TDMoIP Control Word
Adapted TDM payload
higher layers
20
PW Multiplexing

• to reduce resources in core network
• PWs are sent inside PSN tunnels
• we often wish to send several PWs in same tunnel
• to demux we use a PW label
• for application muxing, IANA has assigned to
  TDMoIP
• UDP port number 0x085E (2142)
• in IP networks we use UDP source port number as
  bundle ID
• in MPLS networks we use an inner label
• for L2TPv3 we could use L2TP multiplexing

21
Packet Components

• PSN headers
• ensure packet transported to destination
• RTP header
• contains timestamp that may help in timing
  recovery
• Control Word
• enables detection of out-of-order and lost
  packets
• indicates critical alarm conditions
• TDM payload may be adapted
• to assist in timing recovery and recovery from
  packet loss
• to ensure proper transfer of TDM signaling
• to provide an efficiency vs. latency trade-off

22
TDM over IP and MPLS
PSN label
control word
PW label
TDM payload
23
TDMoIP Control Word

• PID (4b) special uses
• flags (4 b)
• L bit (Local failure)
• R bit (Remote failure)
• FRG (2 bits) indicates fragmentation (only for
  special uses)
• Length (6 b) used when packet may be padded
• Sequence Number (16 b) used to detect packet loss
  / misordering

24
TDM Payload

• What needs to be transported from end to end?
• Voice (telephony quality, low delay, echo-less)
• Tones (for dialing, PIN, etc.)
• Fax and modem transmissions
• Signaling (there are 1000s of PSTN features!)
• Timing

timeslots
25
Why not N bytes?

• Why dont we simply encapsulate N bytes frame?

N TDM octets
UDP
IP
RTP?

• because a single lost packet would cause service
  interruption
• need constant N (else dont know how many TDM
  bytes were lost)
• need to conceal lost packet by proper amount of
  AIS all ones
• TDM synchronization would be lost
• SAToP is good for well-engineered networks
• essentially no packet loss
• very low PDV (see below)

26
Why not one frame?

• Why dont we simply encapsulate the T1/E1 frame?

• because it is inefficient - however N frames is
  reasonable (structure-locking)
• because a single lost packet could cause service
  interruption
• and for CAS, signaling uses a superframe (16/24
  frames)
• so superframe integrity must be respected too
• because we want to efficiently handle fractional
  T1/E1
• because we want a latency vs. efficiency trade-off

27
TDM Structure
handling of TDM depends on its structure unstructu
red TDM (TDM arbitrary stream of
bits) structured TDM
28
TDM transport types

• Structure-agnostic transport (SAToP)
• for unstructured TDM
• even if there is structure, we ignore it
• simplest way of making payload
• OK if network is well-engineered
• Structure-aware transport (TDMoIP, CESoPSN)
• take TDM structure into account
• must decide which level of structure (frame,
  multiframe, )
• can overcome PSN impairments (PDV, packet loss,
  etc)

29
Structure aware encapsulations

• Structure-locked encapsulation (CESoPSN)
• Structure-indicated encapsulation (TDMoIP AAL1
  mode)
• Structure-reassembled encapsulation (TDMoIP
  AAL2 mode)

headers
AAL1 subframe
AAL1 subframe
AAL1 subframe
AAL1 subframe
30
Structure indication - AAL1

• For robust emulation
• adding a packet sequence number
• adding a pointer to the next superframe boundary
• only sending timeslots in use
• allowing multiple frames per packet

ptr
seqnum (with CRC)
T1/E1 frames (only timeslots in use)
UDP/IP
for example
_at_
7
TS1 TS2 TS5 TS7 TS1 TS2 TS5 TS7
31
Structure reassembly - AAL2

• AAL1 is inefficient when timeslots are
  dynamically allocated
• each minicell consists of a header and buffered
  data
• minicell header contains
• CID (Channel IDentifier)
• LI (Length Indicator) length-1
• UUI (User-User Indication) counter payload type
  ID

32
TDM Signaling
33
Signaling?

• signaling is used for network control
• call setup/tear-down (including routing)
• OAM
• billing
• in TDM networks there may be different types
• Subscriber - CO
• CO - CO
• CO - CPE (e.g. PBX)
• there are four common PSTN signaling techniques
• Analog (EM, ground-start/loop-start,
  ring-voltage, etc)
• In-band (dial-tone, ring-back, DTMF,etc)
• CAS Channel Associated Signaling
• CCS Common Channel Signaling
• we neednt discuss the analog techniques

34
In-band signaling

• in-band signaling is transferred in the audio
  (200-3600Hz) band
• for example
• call progress tones (dial tone, ring back)
• DTMF tones,
• FSK for caller identification,
• MFR1 in North America or MFCR2 in Europe,
• audible tones in TDM time slot automatically
  forwarded
• this is not the case for VoIP!
• speech compression may not pass (need tone relay)
• VoIP protocols replace legacy signaling with its
  own
• SIP
• H.323
• Megaco

35
CAS

• CAS is carried in the same T1/E1 as payload
• but not in the audio
• T1 uses robbed bits
• E1 uses a dedicated time slot (usually TS16)
• Readily handled by TDMoIP (even for fractional
  T1/E1 links)
• VoIP systems need to
• detect the CAS bits,
• interpret them according to the appropriate
  protocol
• transport them through PSN using a relay protocol

• finally regenerate and recombine them at the far
  end

36
CCS

• Examples ISDN PRI signaling, SS7
• if occupy a TDM timeslot (trunk associated)
• then forwarded by TDMoIP (see HDLCoIP)
• if not trunk associated,
• then forwarded by signaling network
• or signaling gateway employed
• encapsulate (relay) the native signaling
• forward as additional traffic through the PSN

37
HDLCoIP

• HDLCoIP intended to operate in port mode
• Data / control messages transparently transported
• Assume messages shorter than the MTU (no
  fragmentation)
• Only use when has potential to significantly
  compress BW
• Transmission
• monitor flags until frame detected
• test FCS
• if incorrect - discarded
• if correct -
• perform unstuffing
• flags and FCS removed
• send frame

38
TDM Timing Recovery
39
TDM Jitter and Wander

• Jitter short term timing variation
• (i.e. fast jumps - frequency gt 10 Hz)
• Jitter amplitude in UIpp
• Unit Interval pk-pk
• E1 1 UIpp 1/2MHz 488 ns

• Wander long term timing variation
• (i.e. slow moving- frequency lt 10 Hz)
• Measure in MTIE(t) or TDEV(t)
• MTIE - max pk-pk error
• TDEV expected deviation
• Mask as function of t

compared to reference clock Note requirements
for E1 given in G.823
for T1 given in G.824
40
PSN - Delay and PDV

• PSNs do not carry timing
• clock recovery required for TDMoIP
• PSNs introduce delay and packet delay variation
  (PDV)
• Delay degrades perceived voice quality
• PDV makes clock recovery difficult

41
Jitter Buffer

• Arriving TDMoIP packets written into jitter
  buffer
• Once buffer filled 1/2 can start reading from
  buffer
• Packets read from jitter buffer at constant rate
• How do we know the right rate?
• How do we guard against buffer overflow/underflow?


42
Clock Recovery

• The packets are injected into network ingress at
  times Tn
• For TDM the source packet rate R is constant
• Tn n / R
• The network delay Dn can be considered to be the
  sum of
• typical delay d and random delay
  variation Vn
• The packets are received at network egress at
  times tn
• tn Tn Dn Tn d Vn
• By proper averaging/filtering
• lttn gt Tn d n / R d
• and the packet rate R has been recovered

43
What timing information ?

• We have three clues to the source clock rate
• TOA
• Jitter buffer level
• TOD (if in protocol)

44
FLL

• We can estimate the rate R
• by counting the number of arrivals N per unit
  time T
• the longer the averaging the better the estimate
• R N / T
• Open loop frequency setting
• Better method is closed loop
• Measure reception rate Fn 1 / (tn -
  tn-1)
• Correct present rate F according to filtered Fn
• F F a lt Fn - F gt

tn
F
45
PLL

• Phase difference between
• write (arrival) clock and read (present local)
  clock
• Number of packets written into the jitter buffer
• minus the number of packets read from the jitter
  buffer

write events
read events
counter
46
Packet Loss and Misordering
47
Reasons for packet loss

• In a perfect network all packets should reach
  their destination
• In real networks, some packets are lost
• Loss is caused by
• bit errors invalidating the data (detected by
  ECC)
• intentional dropping by forwarder because of
  congestion
• intentional dropping by forwarder due to policy
  (e.g. (W)RED)

48
Handling of packet loss

• In order to maintain timing SOMETHING must be
  output
• towards the TDM interface when a packet is lost
• Packet Loss Concealment methods
• fixed
• replay
• interpolation

49
Voice Quality Comparison

• See draft-stein-pwe3-tdm-packetloss-00.txt

50
Mis-ordering

• In a perfect network all packets should arrive in
  proper order
• In real networks, some packets are delayed (or
  even duplicated!)
• Misordering is caused by parallel paths
• aggravated by load balancing mechanisms
• Misordering can be handled by
• Reordering (from jitter buffer)
• Handling as packet loss and dropping later
