pGLO

1
pGLO GFP
2
Central Framework of Molecular Biology
3
Links to Real-world

• GFP is a visual marker
• Study of biological processes (example
  synthesis of proteins)
• Localization and regulation of gene expression
• Cell movement
• Cell fate during development
• Formation of different organs
• Screenable marker to identify transgenic
  organisms

4
Transformation Procedure
Day 1

• Day 2

5
What is Transformation?

• Uptake of foreign DNA, often a circular plasmid

6
What is a plasmid?

• A circular piece of autonomously replicating DNA
• Originally evolved by bacteria
• May express antibiotic resistance gene
• or be modified to express proteins of interest

7
Protein Size

• Beta Lactamase
• Ampicillin resistance
• Green Fluorescent Protein (GFP)
• Aequorea victoria jellyfish gene
• araC regulator protein
• Regulates GFP transcription

8
(No Transcript)
9
Bacterial DNA
Bacterial cell
Plasmid DNA
Genomic DNA
10
Prokaryotes

• Gene expression can be either
• Constitutive- Gene always expressed.
• Induced- Expressed in response to
• environmental signal.
• Repressed- Expression shut off when
• environmental signal present.

11
Lactose Operon

• Inducer -- lactose
• Absence
• Active repressor
• No expression

• Presence
• Inactivation of repressor
• Expression

• Negative control

12
Repressor binds tooperator andprevents
structural geneexpessionunless inducer
ispresent.
13
Transcriptional Regulation

• Lactose operon
• Arabinose operon
• pGLO plasmid

14
Transcriptional Regulation
15
Gene Regulation
16
Some animations to illustrate the lac operon.

• Operon animation

17
Methods of Transformation

• Electroporation
• Electrical shock makes cell membranes permeable
  to DNA
• Calcium Chloride/Heat-Shock
• Chemically-competent cells uptake DNA after heat
  shock

18
Bacterial Transformation
Cell wall
GFP
Bacterial chromosomal DNA
Beta lactamase (ampicillin resistance)
pGLO plasmids
19
Transformation Procedure

• Suspend bacterial colonies in Transformation
  solution
• Add pGLO plasmid DNA
• Place tubes in ice
• Heat-shock at 42C and place on ice
• Incubate with nutrient broth
• Streak plates

20
Reasons for Performing Each Transformation Step?
Ca
O
Ca
P
O
O
Base
O
O
CH2
Sugar

• Transformation solution CaCI2
• Positive charge of Ca ions shields negative
• charge of DNA phosphates

O
Ca
P
O
O
Base
O
O
CH2
Sugar
OH
21
Why Perform Each Transformation Step?
Cell wall
GFP
2. Incubate on ice slows fluid cell membrane 3.
Heat-shock Increases permeability of
membranes 4. Nutrient broth incubation Allows
beta-lactamase expression
Beta-lactamase (ampicillin resistance)
22
What is Nutrient Broth?

• Luria-Bertani (LB) broth
• Medium that contains nutrients for bacterial
  growth and gene expression
• Carbohydrates
• Amino acids
• Nucleotides
• Salts
• Vitamins

23
Grow? Glow?

• Follow protocol
• On which plates will colonies grow?
• Which colonies will glow?

24
Skin, Eyes and Organs give off an eerie
lightOnly fur does not glow
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
Column Chromatography

• Chromatography used for protein purification
• Size exclusion
• Ion exchange
• Hydrophobic interaction

30
GFP Purification Procedures
Day 1
Day 3

• Day 2

31
Why Use Chromatography?

• To purify a single recombinant protein of
  interest from over 4,000 naturally occuring E.
  coli gene products.

32
HydrophobicInteractions
Hydrophobic bead

• Aqueous solution hydrophobic
• High salt hydrophobic

H
O
-
-
H

O
O
S
N
H
H
O
O
-
O
S
O
-
O
33
Green FluorescentProtein
34
Hydrophobic Interaction ChromatographySteps 13

• Add bacterial lysate to column matrix in
• high salt buffer
• 2. Wash less hydrophobic proteins from column in
  low salt buffer
• 3. Elute GFP from column with no salt buffer

35
Step 1 Hydrophobic Interaction Chromatography

• Add bacterial lysate to column matrix in high
  salt buffer
• Hydrophobic proteins interact with column

36
Step 2 Hydrophobic Interaction Chromatography

• Wash less hydrophobic from column with low salt
  buffer
• Less hydrophobic E. coli proteins fall from
  column
• GFP remains bound to the column

37
Step 3 Hydrophobic Interaction Chromatography

• Elute GFP from column by adding no salt buffer
• GFP
• Released from column matrix
• Flows through the column

38
Helpful Hints Hydrophobic Interaction
Chromatography

• Add a small piece of paper to collection tube
  where column seats to insure column flow

• Rest pipette tip on side of column to avoid
  column bed disturbance when adding solutions

• Drain until the meniscus is just above the matrix
  for best separation
