Recovery

1
Recovery
2
Recovery

• Lightweight Recoverable Virtual Memory
• Rio Vista

3
Introduction

• failure
• when a system does not perform in the manner
  defined
• erroneous state
• state that could lead the system to the failure
• fault
• anomalous physical condition
• causes
• design/manufacturing error
• damage/fatigue
• external disturbance
• faults lead the system to an erroneous state
  which may or may not results in a failure

4
Failures

• process failure
• deadlock, timeout, protection violation, ...
• OS should confine this failure to the process
• system failure
• software and hardware
• amnesia failure cannot recover the state just
  before the failure
• pause failure the state can be reinstated
• halting failure the system never restarts
• disk failure
• serious problem when it is the last backup
  storage
• usually backed up by tape OR
• mirrored (it will enhance read throughput anyway)
• communication medium failure
• does not cause total system failure

5
Error Recovery

• Forward Error Recovery
• allow the process to proceed after fixing errors
• difficult to remove all the errors (in software,
  procedures to cope with all kinds of error should
  be prepared, which is almost impossible)
• Backward Error Recovery
• the process should restart from the saved (or
  predefined) state
• roll-back mechanism is needed
• easy to cope with any kind of errors (it is not
  necessary to anticipate all kinds of errors)
• overhead to restore previous state
• checkpointing is needed
• same error may occur again

6
Backward Error Recovery

• Operation-based approach
• using a log, undo(roll-back) what has been done
  until an error-free state can be restored
• write ahead log (for a write to X)
• records in a log new value of X
• updates X
• State-based approach
• checkpoint
• a complete state of a process
• at crash, rollback to the most recent safe state
• needs many checkpoints
• shadow page
• copy of a page that is to be updated
• updates are done only on the original page
• at crash, goes back to the shadow page
• at commit, keep using the original page

7
Issues in Recovery(1)

• failure and recovery of a process affect other
  processes that exchange data with the failed
  process
• orphan message
• when a process rolls back to the point before
  sending out a message
• actions of other processes depending on the
  orphan message should be rolled back, too (domino
  effects)
• lost message
• node Y receives a message from X
• Y rolls back to the point before receiving the
  message
• effects are the same as when the message is lost

8
Issues in Recovery(2)

• livelocks

2. orphan message, roll back
x
X
n1
x
m1
Y
1. failure, and roll back

• Y sends out m1 and receives an orphan message n1,
  and rolls back
• m1 becomes an orphan message
• receiving m1, X rolls back

9
Checkpoints

• local checkpoint
• snapshot of a single node
• superscalar CPU and out-of-order memory
  operations made checkpointing difficult
• global checkpoint
• strongly consistent set of checkpoints
• all the checkpoints are inside a given interval
• no information is exchanged between any processes
  during this interval
• this is the last place any process should rolls
  back to

10
Checkpoints(2)

• consistent set of checkpoints
• a message recorder as received in a checkpoint
  should be recorded as sent in another
  checkpoint
• no orphan message
• recorded as sent may NOT be recorded as
  received in other checkpoint
• possible lost message
• simple to make this set
• take a checkpoint after sending every message
• or after sending N messages for better efficiency
  but at more chances of domino effect
• lost message can be dealt as in other network
  protocols

11
Synchronous Checkpointing

• Assumption
• FIFO delivery of messages
• no lost message
• Operations
• an initiating node P broadcasts a message
• all the other node
• take temporary checkpoints if necessary
• reply OK to the P
• do not send any message until they hear from P
• P broadcasts either
• GO if all the nodes reply OK to P
• Fail otherwise
• Nodes make the temporary checkpoint permanent or
  discard it
• start to send messages from this point

12
Synchronous Checkpointing

• advantages
• east recovery all processes restarts from the
  checkpoint
• disadvantages
• message overhead
• hinder normal progress (no computational messages
  are allowed during checkpointing)

13
Asynchronous Checkpointing

• checkpoint at each node is made independently
• no guarantee of consistent set
• recovery is complex to find the nearest
  consistent set
• optimization all incoming messages are logged
  after checkpoint
• recovery algorithm analyzes the log and find the
  most recent consistent set of checkpoints

14
Asynchronous Checkpointing(2)
X


x
Y


Z

• Y crashes
• Y restarts from the last checkpoint
• send ROLLBACK(Y,2) to X since the last checkpoint
  records that Y has sent 2 msgs to X
• ROLLBACK(Y,1) to Z (red lines)
• other nodes sends back ROLLBACK msgs similarly
  (blue lines)
• X sends out (X,2), (X,0) to Y and Z, respectively
• each node sets the chkpnt as to prevent orphan
  msgs (red brackets)
• number of received msg from i recorded in the
  chkpnt lt N, where ROLLBACK(i,N) msg has arrived
• loop until a consistent set of checkpoints comes
  up
• bounded by N (?)

15
Free Transactions with Rio Vista

• crash taxonomy
• hardware not frequent
• software frequent due to bugs in OS
• power UPS
• motivations
• transactions are useful but high overhead (disk
  accesses)
• file cache is useful, but vulnerable to system
  crashes

16
Traditional Approach RVM

• at the beginning of a transaction, RVM copies the
  page to undo log(shadow page)
• user abort is serviced by the undo log
• at commit, RVM reclaims undo space, and writes
  updated pages to redo log on disk
• system/process failure is serviced by the redo
  log
• at leisure time, database is updated from the
  redo log

17
Rio file cache

• protect cached data from system crashes
• cache is as reliable as a disk
• then, write ahead log for recovery is not needed
• writes to disk can be delayed infinitely
• OS errors can corrupt any part of the system
• the issue is how to reduce the chances
• at a crash
• warm reboot process writes the cache to disk

18
file cache vs disk

• why people view memory more vulnerable than disk?
• memory access is a simple write
• an error in the address bits will overwrite the
  file cache
• interface to access disk is complex and explicit
• hardware controller is accessed only through
  device driver
• calls to device drivers are checked for their
  arguments
• it is extremely unlikely that accidental errors
  can forge the logic of device driver

19
How to protect from system crashes?

• prevent OS from accidentally overwriting the file
  cache
• virtual memory mapping
• turn off the write-permission bits in the page
  table for the pages in the file cache
• unauthorized accesses will encounter protection
  violation
• file cache module enables the bit before writing
  and disables the bit afterwards
• the file cache is vulnerable to crashes while
  being written
• disk has the same problem
• solutions
• verify after writes
• use shadow copy for atomic writes

20
How to protect from system crashes?

• some kernels bypass the address translations
  (TLB)
• many systems can disable such bypasses
• otherwise, code insertion (sandboxing)
• check for every kernel write using physical
  address
• 20-50 slower
• memory-mapped file
• kernel procedures that modify the memory-mapped
  file should be changed as above
• faulty user program can still corrupt files to
  which it has write access

21
Warm Reboot

• Recovery needs to access many data structures
• internal file cache lists
• page tables (memory-mapped files)
• all these data must be protected from crash but
  they are scattered inside the kernel
• Registry
• a separate physical memory region
• contains all the information to recover the file
  cache
• it is updated only when a buffer is replaced
  (reloaded)

22
File System Modifications

• writes to disk can be saved
• most disk writes are reliability-induced
• writes to disk are needed only when the file
  cache overflows
• writing back dirty copies when the system is idle

• reduces the time when a buffer is replaced

23
Vista Recoverable Memory
24
Recovery

• operations
• prepare undo log
• writes directly to DBs mapped image in Rio
• these updates are persistent
• at commit, discard the undo log
• at abort, restore the undo log to the mapped DB
• at recovery
• Rio writes back Vista segments that were mapped
  at the time of crash
• Visa examines the segment if there is any
  uncommitted transactions
• roll back (restore undo log)
• recovery process should be idempotent
• crash can happen while recovering

25
Persistent Heap

• only transactions can use
• when they aborts, all the used heaps are returned
• undo records mentioned above are stored here
• programs can store their original data structures
• usually convert them to record style when stored
  in a file
• meta data for the heap is in user space
• why?
• need a protection from corruption
• reduce the risk by using isolated range of
  addresses
• software fault isolation
• virtual memory protection

26
Fault Tolerance with DSM

• DSM maintains multiple copies of a page
• if a copy is lost, it can be recovered from
  another copy
• maintain at least two copies for each page
• cope with a single failure
• can be extend to cope with n-failures
• what about state information?
• can be rebuilt
