FACILITY AND SITE CONDITION ASSESSMENT

1
FACILITY AND SITE CONDITION ASSESSMENT

• Richard D. Carrithers, Jr.
• Steve A. Orsargos, CFM
• April 24th, 2006

2
DTE / MichCon Service Areas
3
Scope of Custodial Responsibility

• Customer Service
• Call Centers
• Credit Centers
• Distribution Operations
• Service Centers
• Regional Centers
• Energy Gas
• Service Centers
• Nuclear Operations
• Outside protected area
• Corporate Headquarters
• Administrative Offices
• Warehouses
• Computing/Data Centers

4
Where is Facility Operations Today?

• The Firefighter
• Reactive
• Little Structure, limited process
• No Formal Planning Scheduling
• Process Performance Measures under-utilized
• Questionable PM, un-engineered PM program
• Limited Condition Directed Activities
• Lack Budget Justification
• Lack Work Justification
• Inadequate Information for Capital Business Case
• Limited Standardization No SWI
• Limited data Are we doing the right work, at
  the right time for the right price?

5
Facility/Site Impacts

• Equipment breakdown maintenance
• Deterioration of facilities infrastructure
• Bow wave effect (backlog keeps growing)
• Deteriorating customer satisfaction
• OM spending is increasing due to capital
  spending constraints (budget over-run)
• Insufficient resources to pursue substantial
  process improvements (working the edges)

6
Site Assessment Characteristics

• Subjective (at best)
• Based on the classic 2x2 matrix
• Vertical axis Environmental, Health Safety
  (EHS), Compliance Code
• Horizontal axis functionality, appearance
• Four color scheme red, blue, yellow, green
• Workshop session
• Scope of sites assessed based on custodial budgets

7
Site Assessment Results

• List of facilities based on four color scheme
• Site assessment matrix
• Vertical axis comments (EHS, Compliance Code)
• Horizontal axis comments (functionality,
  appearance)
• Disposition

8
Site Assessment Matrix
Site Matrix
Yellow Poor Appearance Good Code Compliance
Green Good Appearance Good Code Compliance
Red Poor Appearance Poor Code Compliance
Blue Good Appearance Poor Code Compliance
9
Triggered by a request to determine the cost
required to bring all red, blue, and yellow
facilities to a green status in a time frame that
will support a request for budget funding in 2004
for 2005. Also receive tenant input and support.
FORMIDABLE
10
Facility Site Condition Assessment
Characteristics

• Utilize existing staff (contracting option not
  affordable)
• Consistent approach - training
• Comprehensive/uniform/efficient check list
• Accelerated schedule to meet budget submission
• Digital data base to capture information and make
  it useful
• Sufficient level of detail to estimate cost
• Cost estimates (capital, one-time OM, ongoing
  OM)
• Tenant input required (support)
• Site Assessment (subjective) established scope of
  work
• Achieve a consistent level of maintenance across
  like-facilities

11
DTE Energy Site Analysis
12
Facility and Site Condition Assessment Proposed
Checklist
13
Approach/Process/Methodology

• Facility and Site Condition Assessment workshop
  training session
• Facility supervisors
• Facility assistants
• Establish checklist within Tririga/Facility
  Center
• Establish grade definitions
• Establish assessment definitions
• Generate inspection forms from Tririga/Facility
  Center
• Establish a schedule (milestones)
• Conduct inspections
• Secure tenant input

14
Approach/Process/Methodology - Cont.

• Inspection and cost estimate review sessions
• Facility Operations
• Facilities Design Construction
• Corporate Security
• Inspection data and images are input into
  Tririga/Facility Center
• Analyze cost data for budget submission

15
Site Condition AssessmentGrade Definitions
16
Site Condition Assessment Audit Definitions
17
Inspection Form
18
Inspection Form Continued
19
Inspection Form Continued
20
Inspection Forms Continued
21
Inspection Forms - Continued
22
Inspection Forms - Continued
23
Objectives of AssetManagement Program

• Achieve the appropriate balance of Preventative
  Maintenance and Condition Directed Maintenance
  activities with Corrective Maintenance
• Reduce critical equipment failure rates to
  achieve high reliability as low as economically
  feasible, considering the net total cost to DTE
• Achieve a high utilization of limited resources
  by planning and optimizing the scheduling of work
  activities
• Develop retain a committed and disciplined
  workforce necessary to meet the Core Operating
  and Maintenance Function.
• Be proactive in our operating and maintenance
  approach. Critical failures will be analyzed,
  tracked, and predicted and maintenance tasks
  will be executed so that equipment performance
  and condition effectively support a safe and
  reliable facility
• Develop best practices for implementation, and
  continuously review them for how they can be
  improved

24
What is the future state for Facility Operations?

• Best Practice Competitor
• Highly Planned less Reactive
• Work Week Mgmt / Planning Scheduling
• Maintenance Effectiveness Metrics
• System / Component Cost Tracking
• High compliance to engineered PM Basis
• Effective CMMS
• Highly Competitive
• OM and Capital Budgets tracked against assets
• Able to identify problem equipment and correct
  promptly
• Standardized with SWIs
• Know we are doing the right work, at the right
  time , for the right price !

25
Questions
