Title: Engineering Applications


1
Engineering Applications
  • Dr. Darrin Leleux
  • Lecture 2 MATLAB Introduction
  • Chapter 1

2
Introduction
  • Class MATLAB Experience
  • What is MATLAB
  • The MATLAB System
  • MATLAB Documentation

3
Typical Class MATLAB Experience
4
What is MATLAB?
  • MATLAB is an acronym for Matrix Laboratory
  • High-Performance Language for Technical Computing
  • Typical uses Include
  • Mathematics and computation
  • Algorithm development
  • Modeling, simulation, and prototyping
  • Data analysis, exploration, and visualization
  • Scientific and engineering graphics
  • Application development, including graphical user
    interface (GUI) building

5
The MATLAB System
  • Development Environment
  • The MATLAB Mathematical Function Library
  • The MATLAB Language
  • Handle Graphics
  • The MATLAB Application Program Interface (API)
  • Toolboxes
  • MATLAB Central
  • http//www.mathworks.com/matlabcentral/

6
MATLAB Development Environment
  • A set of tools and facilities that help use
    MATLAB functions and files
  • MATLAB desktop
  • Command Window
  • Command History
  • Browsers for viewing Help
  • The Workspace
  • Files (M-files, etc.)
  • Search Path

7
MATLAB Desktop
View or Change Current Directory
Enter MATLAB functions
Expand to view Documentation, demos, tools
Use tabs to go to Workspace browser
View or use previously run functions
8
MATLAB Structure
9
Example 1.1
maximum number of elements allowed in a matrix on
this version of MATLAB. My version 2.1475e009
Windows
10
Command Window
  • Enter variables and run functions and M-files in
    interactive mode
  • HINT use up-arrow to retrieve previously
    typed commands quickly

11
Command History
  • Lines entered in the Command Window are logged in
    this display
  • You can view, copy and execute previously used
    functions
  • Right Click on selection
  • Copy
  • Evaluate Selection
  • Create M-file

12
Workspace Browser
  • Consists of the set of variables built up during
    a MATLAB session
  • These can be saved off as a .mat file and loaded
    into MATLAB with the load command
  • Save off variables using save command

13
Array Editor
  • Double-click on a variable in the Workspace
    browser to see it in the Array editor

14
Launch Pad
  • Provides easy access to tools, demos, and
    documentation
  • Can also get to these via the Start menu

15
Help Browser
  • Search and view documentation
  • It is also a Web Browser that displays HTML
  • Consists of 2 panes, the Help Navigator (used to
    find information), and the display pane (for
    viewing information)

16
Current Directory Browser
  • View or change current directory
  • Search for, view, open, or make changes to
    MATLAB-related folders and files.

17
Search Path
  • To determine how to execute functions
  • Any file to run must reside in the search path
  • To change the search path, select Set Path from
    the File menu on the desktop

18
Editor/Debugger
  • Create and debug M-files
  • Provides a GUI for basic editing, as well as for
    M-file debugging

19
MATLAB Mathematical Function Library
  • Vast collection of computational algorithms
  • Elementary functions, such as
  • Sum
  • Sine
  • Cosine
  • Complex arithmetic
  • Advanced functions, such as
  • Matrix inverse
  • Matrix Eigenvalues
  • Bessel functions
  • Fast Fourier transforms

20
MATLAB Language
  • High-level matrix/array language
  • Control flow statements
  • Functions
  • Data structures
  • Input/output
  • Object-oriented programming features

21
Handle Graphics
  • High-level commands
  • 2-D 3-D data visualization
  • Image processing
  • Animation
  • Presentation graphics
  • Low-level graphics customization
  • GUI building in MATLAB applications

22
The MATLAB Application Program Interface (API)
  • Library that allows users to write C and Fortran
    programs that interact with MATLAB
  • Dynamic linking
  • Calling MATLAB as a computational engine
  • Reading/writing MAT-files

23
MATLAB General Commands
  • helpbrowser - Bring up the help browser.
  • doc - On-line help, displayed in the
    help browser.
  • help - M-file help, displayed at the
    command line.
  • helpwin - M-file help, displayed in the
    help browser.
  • lookfor - Search all M-files for keyword.
  • syntax - Help on MATLAB command syntax.
  • support - Open MathWorks Technical Support
    Web
  • demo - Run demonstrations.
  • ver - MATLAB, SIMULINK, and toolbox
    info.
  • version - MATLAB version information.
  • whatsnew - Access Release Notes.

24
Example 1.2
25
Managing the Workspace
  • who - List current variables.
  • whos - List current variables, long form.
  • workspace - Display Workspace Browser, a GUI for
    managing
  • the workspace.
  • clear - Clear variables and functions from
    memory.
  • All or just some of the variables
  • pack - Consolidate workspace memory.
  • load - Load workspace variables from
    disk.
  • save - Save workspace variables to disk.
  • quit - Quit MATLAB session.
  • clc - Clear command window

26
Example 1.3
MATLAB Script Example 1.3   gtgt Use of Strings
and eval gtgtf1exp(x) Define a string
function f1 exp(x) gtgtx1 2 3 x
27
Managing commands and functions
  • what - List MATLAB-specific files in
    directory.
  • dir - List all files in current directory
  • type - List M-file.
  • edit - Edit M-file.
  • open - Open files by extension. Does
    different tasks
  • depending on extension type.
  • which - Locate functions and files by path
  • inmem - List functions in memory.
  • mex - Compile MEX-function.

28
Whats In An M-File
29
Differences between Script M-files and Functions
30
Block Comments
31
Example 1.4
32
Controlling the command window
  • echo - Echo commands in M-files.
  • more - Control paged output in command
    window.
  • diary - Save text of MATLAB session.
  • format - Set output format.
  • beep - Produce beep sound.

33
Operating System Commands
  • cd - Change current working directory.
  • copyfile - Copy a file or directory.
  • movefile - Move a file or directory.
  • delete - Delete file.
  • pwd - Show (print) current working
    directory.
  • dir - List directory.
  • fileattrib - Get or set attributes of files and
    directories.
  • isdir - True if argument is a directory.
  • mkdir - Make directory.
  • rmdir - Remove directory.
  • getenv - Get environment variable.
  • ! - Execute operating system command
  • dos - Execute DOS command and return
    result.

34
Operating System Commands(continued)
  • unix - Execute UNIX command and return
    result.
  • system - Execute system command and return
    result.
  • perl - Execute Perl command and return
    result.
  • web - Open Web browser on site or files.
  • computer - Computer type.
  • isunix - True for the UNIX version of
    MATLAB.
  • ispc - True for the PC (Windows) version
    of MATLAB.

35
Example 1.5 from Text
  • M-file (EX1_5.M) to evaluate the function
  • y aexp(-1.2t) - 3.0exp(-2t)
  • INPUT Coefficient a and time t
  • OUTPUT y(t) displayed
  • fprintf('Compute y aexp(-1.2t) - 3.0exp(-2t)
    \n')
  • ainput('Coefficient a, a ')
  • tinput('Variable t, t ')
  • Display results
  • fprintf('\n Function ygexp(-1.2g)-3.0exp(-2
    g) \n',a,t,t)
  • yaexp(-1.2t) - 3.0exp(-2t)
  • End M-file

36
Output of Example 1.5
37
Debugging M-files
  • debug - List debugging commands.
  • dbstop - Set breakpoint.
  • dbclear - Remove breakpoint.
  • dbcont - Continue execution.
  • dbdown - Change local workspace
    context.
  • dbstack - Display function call stack.
  • dbstatus - List all breakpoints.
  • dbstep - Execute one or more lines.
  • dbtype - List M-file with line numbers.
  • dbup - Change local workspace
    context.
  • dbquit - Quit debug mode.
  • dbmex - Debug MEX-files (UNIX only).

38
Control Flow
  • if - Conditionally execute statements.
  • else - IF statement condition.
  • elseif - IF statement condition.
  • end - Terminate scope of FOR, WHILE,
    SWITCH, TRY
  • and IF statements.
  • for - Repeat statements a specific
    number of times.
  • while - Repeat statements an indefinite
    number of times.
  • break - Terminate execution of WHILE or
    FOR loop.
  • continue - Pass control to the next iteration
    of FOR or WHILE
  • loop.
  • switch - Switch among several cases based
    on expression.
  • case - SWITCH statement case.
  • return - Return to invoking function.

39
For loop syntax
  • for variable expression
  • statement
  • ...
  • statement
  • end
  • EXAMPLE
  • a zeros(k,k) Preallocate matrix
  • for m 1k
  • for n 1k
  • a(m,n) 1/(mn -1)
  • end
  • end

40
If syntax
  • if expression1
  • statements1
  • elseif expression2
  • statements2
  • else
  • statements3
  • end

41
While loop syntax
42
Switch syntax
43
Special variables and constants
  • ans - Most recent answer.
  • eps - Floating point relative
    accuracy.
  • realmax - Largest positive floating point
    number.
  • realmin - Smallest positive floating point
    number.
  • pi - 3.1415926535897....
  • i, j - Imaginary unit.
  • inf - Infinity.
  • NaN - Not-a-Number.
  • isnan - True for Not-a-Number.
  • isinf - True for infinite elements.
  • isfinite - True for finite elements.
  • why - Succinct answer.
