Control flow structures in Distributed programs
Philippe Demaecker
Programming Technology Lab (PROG)Departement
Informatica (DINF)Vrije Universiteit Brussel
(VUB)
2
About distributed programs

• Wide area networks ? programs on remote machines
  cant be altered
• Component wise (application consists of
  interconnected components)
• Components are active

3
About

• Examples
• metacrawler ? several searchengines
• dispatching within HTTPD daemons (to cgis)
• ...

these kind of control flow handlers are often
more needed than anticipated
4
Goal

• Event handlers are often needed
• control flow code hardcoded in program
• insert components that were written by other
  programmers
• Which control flow structures are needed to write
  distributed programs in an easier way?
• No AOP (You dont posses the remote code)
• Purpose is to go a level higher than concurrency
  primitives

5
Working method

• Study the control flow of some simple programs
  to extract primitives
• (e.g. pipeline).
• Programs written in Cborg

6
Cborg

• Asynchronous sends in Cborg syntax
• ltagentgt.ltcalleegt(ltparsgt)
• But no result is returned this way
• This can be solved using callbacks

7
Callbacks in Cborg
tecra/ses2
tecra/ses1
aremotedict(tecra/ses2) answer(b)display(b)
a.calcdet(1,8,5,6, agentself())
calcdet(matrx,cb) cb.answer(matrx)
8
Example

• SieveComp(next)
• prime 0
• Receive(aNumber)if (prime 0,
• SetPrime(aNumber)
• display(prime),
• if((not ((aNumber\\prime)0)),
• next.Receive(aNumber),void))
• agentclone(clone())

9
Example (ctd)

• c Collector()
• s3 Sievecomp(c)
• s2 Sievecomp(s3)
• s1 Sievecomp(s2)
• g Generator(s1)
• g.Start()

Problem what to do if we want to extend the
functionality (e.g display between components)?

• Write a component that understands Receive, with
  the same parameter structure.
• Creationstructure must be altered

10
Problems

• Components have to understand Receive(...)
• Building the structure is too explicit
• Collector should be a control flow component
• Parameter passing convention is hardcoded gt
  control flow too explicit

11
Example (with pipeline)

• Primecheck

PrimeCheck()prime 0 Receive(aNumber,primeTo,
nonPrimeTo) if(prime 0, SetLocalPrime(a
Number) primeTo.GetResult(prime), if((not
((aNumber\\prime)0)), nonPrimeTo.GetResult(a
Number), void)) agentclone(clone())
12
Example (ctd)

• Generator

NumberGenerator(from,to, name) next
0 SendInfo(target,info) target.GetResult(
info) Start(target) for(tfrom,
tt1, tltto, SendInfo(target,t)) agentclon
e(clone(), name)
13
Example (proposed solution)

• componentsg,s1,s2,s3
• pPipeline(components))
• componentsg,disp,s1,disp,s2,disp,s3,disp
• pPipeline(components)
• gtgt p.Start(console, Receive,GetResult)

14
Pipeline structure
15
FFT using same pipeline

• CalcFFT(name, stageNr)
• Calc(coeffs, displayTo, resultTo)
• ltcompute coefficientsgt
• resultto.SendToNext(info)
• agentclone(clone(), name)

• componentsg, FFT1, FFT2, ...
• pipeline(components,Calc,SendToNext)
• Same pipeline structure !

16
Addendum

• Good use of migration
• Assume components are in Zimbabwe
• 1. You can declare the pipeline locally and
• 2. send the pipes to Zimbabwe.
• gt more performant

17
Future Work Thesis (1)

• Study other applications and designs
• HTTPD
• MVC
• Distributed Namespaces
• Whiteboards
• Design Patterns
• Message Queues
• Event Dispatchers

18
Future Work Thesis (2)

• Checking out what happens when working with other
  natives.
• Synchronisation natives (sync, send, recv)
• Main goal is to detect appropriate control flow
  structures
• star structure (many to one)
• multi casting (one to many)
• others (many to many, ...)

19
Pipe (internals)

• Pipe(n, posPipe, nextAgent,nextNegPipe)
• SendResultToNext_at_args
• info args1
• mss read("rcv." n "()")
• mss1 nextAgent
• app mss2
• app2 info, posPipe, nextNegPipe
• eval(mss)
• cst make(16)
• cst1 read(callbackName"_at_args")
• cst2 SendResultToNext3
• eval(cst)
• agentclone(clone(), name)
