Bridge Design Innovation: Materials

1
Bridge Design Innovation Materials
Construction
2006 Structures Congress St. Louis, MO May 18,
2006
By Brian J. Leshko, P.E.
For the benefit of business and people
2
Agenda

• Bridge Design Innovations
• Innovative Material
• Innovative Technology
• Innovative Construction
• FHWA Funding Programs
• OTIA III Program
• Grant Applications

3
1

• gt Bridge Design Innovations

4
Bridge Design Innovations
1

• To advance new technology and techniques
• Design of bridge structures
• Construction of bridge structures
• Contribute to goals of
• Cost Efficiency
• Traffic Mobility

5
Bridge Design Innovations
1

• Cost savings from improved or longer life
  materials
• Reduce Initial Structure Costs
• Reduce Life Cycle Costs
• Time savings from accelerated construction
• Reduce Construction Cost
• Reduce Congestion Delays
• Reduce Traveler Inconvenience

6
2

• gt Innovative Materials

7
Innovative Material
2

• High-Performance Steel (HPS)
• High-Performance Concrete (HPC)
• Fiber-Reinforced Polymer (FRP)
• Alternate Rebar with Corrosion Resistance
• Innovative Coatings
• Innovative Cathodic Protection

8
High-Performance Steel (HPS)12-Year Timeline
2
9
High-Performance Steel (HPS)Types
2

• HPS Grade 50W
• HPS Grade 70W
• HPS Grade 100W
• Hybrid Design
• Use HPS 70W in high stressed flange locations
• Use grade 50W in webs and low stressed flange
  locations

10
High-Performance Steel (HPS) Benefits
2

• Higher Strength
• 50-100 ksi
• Improved Weldability
• Higher Toughness
• Improve overall quality and fabrication
• Improved Weathering
• Atmospheric corrosion resistant

11
High-Performance Concrete (HPC)
2

• Concrete made with appropriate materials

• superplasticizer, retarder, fly ash, slag, silica
  fume
• Combined and mixed according to a selected mix
  design
• Transported, placed, consolidated and cured to
  yield excellent performance
• high compressive strength
• high density
• low permeability
• good resistance to environment

12
High-Performance Concrete (HPC)Types
2

• Very Early Strength (VES)
• Min. Strength 2,000 psi / 6 hours W-C lt 0.4
  80 Durability
• High Early Strength (HES)
• Min. Strength 5,000 psi / 24 hours W-C lt
  0.35 80 Durability
• Very High Strength (VHS)
• Min. Strength 10,000 psi / 28 days W-C lt
  0.35 80 Durability
• Fiber Reinforced
• HES (steel or poly) W-C lt 0.35 80
  Durability

13
High-Performance Concrete (HPC)Benefits
2

• Cost-effective to construct
• Easy to maintain
• Competitive in value
• Innovative aesthetics
• 100-year service life

14
Fiber-Reinforced Polymer (FRP)
2

• Composite materials made of fibers embedded in a
  polymeric resin exhibiting beneficial properties
• Impervious to chloride ion and chemical attack
• Tensile strength greater than steel
• 1/4th weight of steel reinforcement
• Electrically and thermally non-conductive

15
Fiber-Reinforced Polymer (FRP)Types
2

• Bonded Reinforcement
• Beams
• Cable-Stays
• Deck Forms
• Deck Panels Slabs
• Prestressing Tendons
• Reinforcement Bars

16
Fiber-Reinforced Polymer (FRP)
2

• Bonded Reinforcement Increased shear capacity
  of concrete beams using partial or complete
  wrapping (continuous jacket or spaced strips)
  with transversely oriented FRP.

17
Fiber-Reinforced Polymer (FRP)
2

• Reinforcement Bars Alternative to steel
  reinforcement in concrete (CIP and Prestressed)
  to avoid corrosion (nonmetallic and
  noncorrosive).
• Aramid Fiber Reinforced Polymer (AFRP)
• Carbon Fiber Reinforced Polymer (CFRP)
• Glass Fiber Reinforced Polymer (GFRP)

18
Alternate Rebar (non-FRP)with Corrosion
Resistance
2

• Clad Stainless Steel (75- to 100-year protection)
• Metallurgically bonded to inner carbon steel core
• Solid Stainless Steel (75- to 100-year
  protection)
• Lower strength need more compared to black bars

• Galvanized Steel
• Hot-dipped, Zinc-coated
• MMFX Rebar
• Microcomposite Multistructural Formable Steel

19
Innovative Coatings
2

• Galvanizing
• Zinc Plating or In-Line Galvanizing Coatings
• Metalizing
• Pure metal sprayed coatings
• Paint Systems
• Overcoatings
• Epoxy Mastic Coatings

20
Innovative Cathodic Protection (CP)
2

• Cathodic Protection a method for protecting
  reinforcing steel bars by using an anode system
  (either applied to the surface or embedded within
  the concrete) to maintain a non-corrosive
  state.

21
Innovative Cathodic Protection (CP)Methods
2

• Galvanic self-powered and rely on the corrosion
  of the less noble anode (i.e. Zinc) relative to
  the reinforcing steel bars.
• Impressed Current energized using low voltage
  DC current to overcome the natural tendency for
  the steel to corrode.

22
Innovative Cathodic Protection (CP)Types of
Systems
2

• Distributed CP Anodes
• Galvanic
• Impressed Current
• Discrete CP Anodes
• Galvanic
• Impressed Current

23
Distributed CP Anodes
2

• Impressed Current Galvanic

24
Discrete CP Anodes
2

• Impressed Current Galvanic

25
3

• gt Innovative Technology

26
Innovative Technology
3
Prefabrication Design and Construction
27
Prefabrication Advantages
3

• Minimized traffic disruptions
• Improved work-zone safety
• Minimized environmental impact
• Improved constructability
• Improved quality
• Lower life-cycle costs

28
Innovative Technology
3

• Prefabricated Bridge Elements and Systems
• Constructed at a location other than the bridges
  final location, then installed at the
  site
• Emphasis on innovative elements and systems
• FHWAs Framework for Prefabricated Bridge
  Elements and Systems
• (PBES) Decision-Making dated 12/07/05
• Flowchart for High-Level Decision One-Page
• Matrix One-Page
• Question-and-Discussion Format Detailed

29
Prefabricated Bridge Elements
3

• Superstructure
• Precast Deck Panels Full-depth and
  partial-depth
• Precast Barriers
• Precast Beams More efficient shapes
• Substructure
• Precast Bent Caps
• Precast Columns

30
Prefabricated Bridge Systems
3

• Superstructure
• Preconstructed Composite Units
• Prefabricated Truss Spans
• Substructure
• Precast Abutments
• Prefabricated Bent Cap supported by Precast
  Column(s)
• Precast Pier(s)
• Totally Prefabricated Bridges

31
4

• gt Innovative Construction

32
Innovative Construction
4

• Accelerated Construction Technology Transfer
  (ACTT)
• Highways for LIFE (HfL)

33
Accelerated Construction Technology Transfer
(ACTT)
4

• Minimizing the impact of ongoing highway
  construction on motorists and adjacent
  communities by streamlining project schedules and
  containing costs, while enhancing safety and
  improving quality.

34
Accelerated Construction Technology Transfer
(ACTT)
4

• Find better methods to
• get in, get it done right, get out, and stay
  out.
• 2-Day Workshop
• multidisciplinary team of national transportation
  experts works with local agency professionals to
  evaluate all aspects of the project from the
  perspective of various Skill Sets.

35
Accelerated Construction Technology Transfer
(ACTT)
4

• Skill Sets
• Innovative Financing / Contracting Long Life
  Pavements
• Right-of-Way / Utilities / Railroads Traffic /
  Safety / ITS
• Roadway / Geometric Design Environment
• Geotechnical / Materials Construction
• Structures Public Relations

36
Accelerated Construction Technology Transfer
(ACTT)
4

• Prefabrication
• Pre-Assembly
• Incremental Launching
• Superstructure Lift-In
• Superstructure Roll-In

37
Highways for LIFE (HfL)
4

• Long-Lasting
• Better (1)
• Innovative
• Fast Construction Faster (2)
• Efficient and Safe Less Cost (3)
• Must have all three!
• Innovation only occurs when empowerment
  encounters need.

38
5

• gt FHWA Funding Programs

39
Innovative Bridge Research Construction
Program (IBRC)
5

• Transportation Equity Act for the 21st Century
• Createdgt
• Section 503 of Title 23, Chapter V
  -Transportation Research

40
IBRCProgram Information Available _at_
5
http//ibrc.fhwa.dot.gov

• SAFETEA-LU Legislation Continues Program
• Annual Solicitation
• IBRC Program Guide
• Project Database
• FHWA Contacts

41
(No Transcript)
42
Innovative Bridge Research Construction
Program (IBRC)
5
Key Program Features

• Innovative materials for highway bridges
• Demonstration projects
• Performance monitoring
• RD Technology transfer

43
IBRC Program Primary Goal
5
Development and demonstration of
new, cost-effective,
highway bridge applications
of innovative materials
44
IBRC7 Program Goals
5

• New, cost-effective innovative material for
  highway bridge applications
• Reduction of maintenance costs and life-cycle
  costs of bridges, including the costs of new
  construction, replacement, or rehabilitation of
  deficient bridges

45
IBRC7 Program Goals
5

• New nondestructive bridge evaluation technologies
  and techniques
• Engineering design criteria for innovative
  products and materials for use in highway bridges
  and structures

46
IBRC7 Program Goals
5

• Construction techniques to increase safety and
  reduce construction time and traffic congestion
• Highway bridges and structures that will
  withstand natural disasters, including
  alternative processes for the seismic retrofit of
  bridges and
• Cost-effective and innovative techniques to
  separate vehicle and pedestrian traffic from
  railroad traffic.

47
IBRC Eligibility
5

• Funds are available for bridge projects that
  demonstrate an innovative material application
  and meet one or more of the seven program goals
  listed in Section 503(b)(2) of Title 23
• Location - the project may be on any public
  roadway
• State
• County
• City
• Road or Bridge Authority

48
IBRC Eligibility
5
Eligible Activities - funds available for

• preliminary engineering,
• costs of the innovative material portion of
  repair, rehabilitation or construction of bridges
  or other structures,
• costs of project performance evaluations
  including instrumentation and performance
  monitoring of the structure following
  construction

49
IBRC Eligibility
5

• Proprietary Products - As this is a research and
  experimental program, it is in the public
  interest that proprietary and sole source
  products may be included in the projects, but
  they must be clearly identified and described.

50
IBRCSelection Criteria Considerations
5

• Project demonstrates the application of an
  innovative material
• Project meets one or more of the 7 program goals
• Project incorporates materials or products which
  are readily available

51
IBRCSelection Criteria Considerations
5

• Design/application is repeatable and/or has
  widespread application
• Projects where Federal funds are leveraged with
  other significant public or private resources
• Projects which are ready/near ready to go to
  construction phase

52
IBRC Schedule for Obligation of Funds, FY 2005
5
Action FY 2005 Solicitation
4/18/2005 Submittal 7/15/2005 Fund
Allocations 11/30/2005 FY 2006 Fund
Obligations, NLT 9/30/2006 FY 2006 Letting
Dates, NLT 6/30/2007 FY 2007
53
TEA-21 IBRCProgram Funding
5

• Repair, Rehabilitation New Construction
• Year Authorized Available
• FY 1998-99 25 M 22 M
• FY 2000 17 M 15 M
• FY 2001-04 20 M / year 17 M / year
• FY 2005 20 M / year 17 M / year
• Research, Development, Technical Deployment
• FY 1998-03 1 M / year .87 M / year

54
TEA-21 IBRCProgram Funding
5

• TEA-21 funded for six years,
• FY 1998 FY 2003
• TEA-21 extended for 20 months, through May 31,
  2005
• Full funding for FY 2004,
• partial funding (8/12ths) for FY 2005

55
(No Transcript)
56
IBRCProgram Funding
5

• Secretary Determines Federal Share - may be less
  than 100 on projects with estimated cost gt 500K

• Funds are 100 Federal - No Matching Funds
  Required

57
Number of IBRC Funded Projects by Type of
Material (FY 1998-01)
5
58
6

• gt OTIA III Program

59
Bridge Background InformationBaseline Reports
6

• Bridge Strategy Report
• Bridge Options Report (BOR)
• Revised Bridge Options Report (2005)

60
Bridge Background InformationBaseline Reports
6

• Environmental Baseline Reports
• Engineering Baseline Reports
• Cost Estimate
• Crack Mapping
• Drawings
• Foundation Report
• Geology Report
• Inspection Report
• Site Photos
• Video Clips
• Existing Engineering Data
• Scoping Report

61
(No Transcript)
62
Bridge Scoping Report
6

• Review of Baseline Reports
• Bridge Recommendations
• Replace
• Repair
• Incorporate Design Innovation

63
OTIA III Program Design InnovationInnovative
Materials Rapid Reconstruction
6

• Innovative Bridge Research Construction (IBRC)
• High-Performance Steel (HPS)
• High-Performance Concrete (HPC)
• Precast members
• Bridge deployment
• Accelerated Construction Technology Transfer
  (ACTT)
• Get in, get out, stay out

64
Approach to the Work
6

• Scope of Work Definitions
• Replacement Structures
• The removal of an existing structure and
  construction of a replacement structure on a new
  alignment or using staged construction.

65
Approach to the Work
6

• Program Purpose Structures capable of carrying
  permit loads without
  restriction
• Repair Structures
• Perform work required to strengthen girders
  and/or cap beams -
  potential use of Innovative Materials
• Load rating ratios for all ODOT permit vehicles
  exceed 1.0
• LRFR Load Rating Method with modifications by
  ODOT

66
TSL Narrative
6

• Replacement Bridge Outline
• Alternatives analysis for all types not selected
• Structure type
• Span configuration
• Foundation type
• Construction staging
• Programming level structure cost
• Maintenance
• Detailed analysis of most viable alternatives
  with designation of preferred alternative
• Construction cost estimate for two alternatives

67
TSL Narrative
6

• Repair Structures
• Identify preferred alternative techniques after
  all repair types are considered
• Choice of repair type must consider traffic
  control mobility during construction
• Repair alternative must consider aesthetics in
  areas of high visibility
• Narrative must discuss ALL possible repair types
• Girders - internal stirrups, external
  post-tensioning, etc.
• Crossbeams (bent caps) internal stirrups,
  external post-tensioning, cap widening, infill,
  etc.

68
7

• gt Grant Applications

69
Grant Application Process
7

• Identify potential technology
• Identify possible projects
• Determine costs of technology and design
• Propose grant application to State DOT
• Acceptance by State DOT
• Approval by State DOT
• Submit grant application

70
(No Transcript)
71
Timeline for Innovation
7

• January Identify technology projects,
• including
  costs
• February Meet with Technical Services
• March Begin approval process
• July Send in grant applications
• October FHWA notification of grant awards
• Following year Project construction

72
(No Transcript)
73
Questions ????
74
End
Bridge Design Innovation Materials
Construction
2006 Structures Congress St. Louis, MO May 18,
2006

• By Brian Leshko, P.E.
