Overview

• Higher Consistencies for binary constraints
• Path Consistency, k-consistency, SAC, PIC, NIC,
  RPC
• Non-binary Constraints
• Search Algorithms Consistencies for non-binary
  constraints
• GAC, Bounds Consistency, PWC
• specialized filtering algorithms
• Encodings of non-binary constraints into binary
• decomposable constraints
• encodings of non-binary into binary constraints
• Alternative search methods
• Limited Discrepancy Search
• Optimization

3
Path Consistency (PC)

• A CSP is path consistent iff every pair of
  assignments (x,a) and (y,b) where a and b are
  compatible, can be extended to a consistent
  assignment of every third variable
• a PC algorithm adds binary no-goods
• The assignments (x,a) and (y,b) cannot be made
  simultaneously
• Plus/Minus
• detects more inconsistencies than AC
• - extensional representation of constraints
• - changes in graph connectivity
• Directional PC, Restricted PC

4
Path Consistency

• Path consistency will detect that there is no
  solution in this problem
• by adding new binary constraints
• Naturally PC is more expensive than AC
• O(n3d3) time complexity compared to O(n2d2)
• PC algorithms have high space complexity as well
• O(n3d2)

X
1 2
1 2
Y
Z
1 2
5
k-consistency

• k-consistency (k-1,1) consistency
• consistent assignment of (k-1) variables can be
  extended to k-th variable
• strong k-consistency ? j-consistency for each
  j?k
• NC ? strong 1-consistency
• AC ? strong 2-consistency
• PC ? strong 3-consistency
• What is 6-consistency?
• The cost of k-consistency is exponential in k
• impractical for large k

6
Consistency Completeness

• strongly N-consistent constraint graph with N
  nodes gt solution
• strongly K-consistent constraint graph with N
  nodes (KltN) gt ???
• path consistent but no solution
• Special graph structures
• tree structured graph gt (D)AC is enough
• cycle cutset, MACE

?
A
D
1,2,3
1,2,3
?
?
?
?
C
B
?
1,2,3
1,2,3
7
Domain Filtering Consistencies

• An important disadvantage of path consistency and
  k-consistency in general is that they alter the
  structure of the constraint graph and the
  constraints relations
• this implies an exponential (in k) space
  complexity
• Domain filtering consistencies are consistencies
  that only remove values from the domains of
  variables
• i.e. they only add unary constraints
• arc consistency is the most widely used such
  consistency
• many more have been proposed
• inverse and singleton consistencies

8
Singleton Arc Consistency (SAC)

• A value a of a variable x is singleton arc
  consistent (SAC) if after reducing the domain of
  x to a and applying AC, there is no domain
  wipe-out
• A CSP is SAC iff all values in the domains of all
  variables are SAC
• A SAC algorithm deletes all values that are not
  SAC
• Singleton consistency is a generic notion that
  can be combined with many consistencies
• singleton path consistency
• singleton k-consistency
• Singleton consistencies do not alter the
  constraints
• they only remove inconsistent values

9
Singleton Arc Consistency (SAC)

• Singleton arc consistency will detect that there
  is no solution in this problem
• without adding new binary constraints
• Naturally SAC is more expensive than AC
• O(end3) time complexity compared to O(ed2)
• The space complexity is
• O(end2)

X
1 2
1 2
Y
Z
1 2
10
Path Inverse Consistency (PIC)

• k-consistency is otherwise known as (k-1,1)
  consistency
• consistent assignment of (k-1) variables can be
  extended to k-th variable
• path consistency is (2,1) consistency
• What about the inverse k-consistency (1,k-1)
  consistency?
• consistent assignment of 1 variable can be
  extended to any (k-1) variables
• The cost of k-inverse-consistency is exponential
  in k
• impractical for large k
• Path inverse consistency is (1,2) consistency
• consistent assignment of 1 variable can be
  extended to any 2 variables

11
Path Inverse Consistency (PIC)

• Path inverse consistency will detect that there
  is no solution in this problem
• without adding new binary constraints
• Naturally PIC is more expensive than AC
• O(ed2cd3) time complexity, where c is the
  number of 3-cliques
• The space complexity is
• O(edcd)

X
1 2
1 2
Y
1 2
12
Neighborhood Inverse Consistency (NIC)

• A value a of a variable x is neighborhood inverse
  consistent (NIC) if it can be extended to a
  consistent instantiation of all the neighbors of
  x (i.e. all variables connected to x)
• NIC deletes values that cannot be part of a
  solution to the sub-problem defined by the
  neighbors of x
• The behavior of NIC is dependent on the structure
  of the constraint graph
• what happens if the graph is complete (i.e. each
  variable is constrained with all the others)?
• NIC is cost effective when used on problems with
  sparse graphs

13
Neighborhood Inverse Consistency (NIC)

• NIC will detect that there is no solution in this
  problem
• NIC can be very expensive
• Its time complexity depends on the maximum
  number of neighbors that a variable has
• this can be as much as n-1
• The only proposed algorithm has complexity of
  O(eg2dg1)
• g is the maximum degree

X
1 2
1 2
Y
1 2
14
Restricted Path Consistency (RPC)

• Restricted Path Consistency (RPC) is an
  intermediate level of consistency between AC and
  PC
• it removes all arc inconsistent values and it
  checks the path consistency of all pairs of
  values (x,a) , (y,b) such that (y,b) is the only
  support for (x,a) in the domain of y.
• if such as pair is path inconsistent, its
  deletion would lead to the arc inconsistency of
  value a of x
• RPC only removes a (it does not add the binary
  constraint)
• RPC performs few more checks than AC, while
  deleting more values without changing the
  structure of the constraint graph

15
Restricted Path Consistency (RPC)

• RPC will detect that there is no solution in this
  problem
• PRC is relatively cheap
• O(ed2 cd2 ) where c is the number of 3-cliques
• Preliminary experiments have shown that it is the
  most promising alternative to AC

X
1 2
1 2
Y
1 2
16
Relations between Local Consistencies
NIC
SRPC
SAC
PIC
RPC
AC
strong PC
stronger consistency incomparable consistencies
17
Non-binary Constraints Outline

• Definition of non-binary constraints
• Modeling with non-binary constraints
• Solving non-binary CSPs
• Search and constraint propagation with
  non-binary constraints
• Encodings of non-binary CSPs into binary
• Practical benefits case study
• Golomb rulers
• Crossword puzzles
• Sudoku
• A non-exhaustive list of specialized non-binary
  constraints

18
Definition

• Binary constraint
• Relation on 2 variables identifying those pairs
  of values disallowed (no-goods)
• E.g. not-equals constraint X1 ? X2.
• Non-binary constraint
• Relation on 3 or more variables identifying
  tuples of values disallowed
• E.g
• alldifferent(X1,X2,X3)
• X1X2X3gtX4

19
Some non-binary examples

• Timetabling
• Variables Lecture1, Lecture2,
• Values time1, time2,
• Constraint that lectures do not conflict
• alldifferent(Lecture1,Lecture2,).

• Scheduling
• Variables Job1, Job2,
• Values machine1, machine2,
• Constraint on number of jobs on each machine
• atmost(2,Job1,Job2,,machine1),
• atmost(1,Job1,Job2,,machine2).

20
Why use non-binary constraints?

• We know that any non-binary constraint can be
  represented using binary constraints
• E.g. alldifferent(X1,X2,X3) is equivalent to
• X1 ? X2, X1 ? X3, X2 ? X3
• In theory therefore theyre not needed
• But in practice, they are!
• most real problems are naturally represented
  using non-binary constraints

21
Modeling with non-binary constraints

• Benefits include
• Natural representation of real constraints
• Compact, declarative specifications
• Efficient constraint propagation
• However, non-binary constraints post some
  challenges
• Most algorithms and techniques have been
  developed for binary constraints
• can we adapt them to the nonbinary case ?

22
Modeling with non-binary constraints

• Consider the all-different constraint
• It can be represented using binary constraints
• This representation is not very compact
• alldifferent(X1,Xn) expands into n(n-1)/2
  binary not-equals constraints, Xi ? Xj
• one non-binary constraint or O(n2) binary
  constraints?

x1
x2
x3
x4
x5
x6
x1
x2
x6
x3
x4
x5
23
Solving non-binary CSPs

• There are two approaches we can follow
• Extend algorithms and heuristics for binary CSPs
  to deal with non-binary constraints
• Search algorithms, local consistencies,
  variable/value ordering heuristics, local search
  techniques, etc.
• Devise new algorithms if necessary
• Translate any given non-binary CSP into a binary
  one and solve it using standard techniques for
  binary constraints
• How can we do the translation?
• Is this efficient?

24
Local Consistencies for Non-binary Constraints

• Generalized arc-consistency (GAC) for non-binary
  constraints
• A non-binary constraint is GAC iff for every
  value a for a variable x there is a consistent
  and valid tuple including (x,a) and values for
  all other variables in the constraint
• A tuple is consistent if it is allowed by the
  constraint
• A tuple is valid if none of the values in the
  tuple has been removed from the corresponding
  domain
• Supports are not single values, but tuples of
  values
• We can prune values that are not supported
• GAC AC on binary constraints

value 5 of X4 has the support lt2,2,2gt value 6
of X4 has no support
0,1,2
0,1,2
0,1,2
0,..,6
x1
x3
x4
x2
X1X2X3gtX4
25
GAC is stronger than AC

• Non-binary model
• alldifferent(X1,X2,X3) is not GAC
• Binary model
• X1 ? X2, X1 ? X3, X2 ? X3 are all AC
• But GAC is, in general, much more expensive
• O(ekdk) optimal time complexity where k is the
  maximum arity of the constraints

2,3
X1
?
?
2,3
2,3
?
X3
X2
26
GAC-3 An Algorithm for GAC
procedure GAC-3(G) Let Q be the set of
(undirected) constraints of G while Q not empty
do select and remove any constraint c from
Q for each variable x participating in c
REVISE(x,c) if REVISE(x,c) changed the
domain of x then add to Q the set of all
constraints that include x (except c)

• procedure REVISE (x,c)
• for each value a in domain of x do
• if there is no tuple in the relation of c that
  includes (x,a) and is consistent and valid
• then delete a from the domain of x

27
Algorithms for GAC

• The time complexity of GAC-3 is O(ek2dk1)
• this can be reduced to O(ek2dk) using a similar
  data structure as in AC-2001 (algorithm
  GAC-2001/3.1)
• Other binary AC algorithms have been extended to
  the non-binary case
• GAC-4
• GAC-Schema (a generalization of AC-7)
• achieves multi-directionality and has optimal
  worst-case complexity O(ekdk)
• but uses complicated data structures and is
  difficult to implement

procedure REVISE-2001/3.1 (x,c) for each value a
in domain of x do if there is no consistent and
valid tuple t in the domain of y such that tgt
Lastx,a,c then delete a from the domain of
x else Lastx,a,y first such tuple
28
Achieving GAC

• By exploiting semantics of certain constraints,
  we can often enforce GAC much more efficiently
  than with a generic algorithm
• Consider alldifferent(X1,Xn) with each Xi
  having domain of size d
• Generic GAC algorithm runs in O(ndn)
• A specialized GAC algorithm for the alldifferent
  constraint runs in O(dn?n) based on network flow
• Designing such algorithms is a hot topic in
  constraint programming research
• more on this later

29
Alldifferent GAC pruning

• How to make an all-different constraint GAC?
  Given domains, create domain/variable bipartite
  graph

x1
1
x2
2
3
x3
4
x4
5
x5
30
Alldifferent GAC pruning

• Pruning? Which edges are in no matching? Find
  them and prune the corresponding values from the
  domains

x1
1
Domain is sharply reduced
x2
2
3
x3
4
x4
5
x5
31
Bounds Consistency

• Local consistencies for non-binary constraints
  are expensive in the general case
• GAC exponential in the arity of the constraints
• Bounds consistency (BC) is a restricted (and
  cheap) form of (G)AC that applies (G)AC only on
  the values at the bounds of the variables
  domains
• e.g. BC will only check if values 0 and 9 are AC
  for a variable with domain 0,9
• BC can be very cost effective for certain types
  of constraints
• can you think of such a constraint?

32
Other Local Consistencies for Non-binary CSPs

• Local consistencies for non-binary constraints
  are not as studied as in the binary case
• because they are expensive in general
• Some strong consistencies have been proposed
• relational consistencies
• pairwise consistency
• will say more about it later
• hyper k-consistencies
• In all these cases, the primary entities where
  the consistencies operate are the constraint
  relations, not the variables

33
Search Algorithms for Non-binary CSPs

• Some search algorithms are easily generalized to
  the non-binary case
• MAC gt MGAC
• while for others it is less obvious
• FC gt ?
• Lets start with the simplest algorithm. How can
  we generalize chronological backtracking to
  handle non-binary problems?
• perform a constraint check only when the current
  variable is the last variable in a constraint
• e.g. constraint x1x2x3gtx4 will be checked when
  the algorithm reaches x4 (assuming a static
  variable ordering)

34
FC for non-binary constraints

• Forward checking has been generalized to
  non-binary CSPs in many ways
• nFC0
• check a constraint when there is exactly one
  variable unassigned
• e.g. constraint x1x2x3gtx4 will be checked when
  the algorithm reaches x3
• nFC1
• apply one pass of AC to each constraint and
  projection involving current variable and one
  future variable
• nFC2
• apply one pass of AC to the set of constraints
  involving the current variable and at least one
  future variable
• nFC3
• apply AC to the set of constraints involving the
  current variable and at least one future variable

35
FC for non-binary constraints

• Forward checking has been generalized to
  non-binary CSPs in many ways
• nFC4
• apply one pass of AC to the set of constraints
  involving at least one past variable (or the
  current variable) and at least one future
  variable
• nFC5
• apply AC to the set of constraints involving at
  least one past variable (or the current variable)
  and at least one future variable

36
nFC - Example
c1
c2
c3

• Assume the assignments (x,a) and (u,a) are made.
• What pruning do algorithms nFC0-nFC5 achieve?

37
Constraint Programming Solvers

• CP Solvers offer
• A rich constraint language
• Arithmetic, higher-order, logical constraints
• Global constraints for natural substructures
• Easy specification of a search procedure
• Definition of search tree to explore through
  modeling decisions
• Specification of search strategy
• Choice of branching heuristics
• The user
• Models the problem as a CSP by specifying
  variables, domains, and constraints
• Selects the search strategy to be used
• Feeds the problem to the solver

38
Illustrative artificial example

• Color a map of (part of) Europe Belgium,
  Denmark, France, Germany, Netherlands, Luxembourg
• No two adjacent countries same color
• Are four colors enough?

enum Country Belgium,Denmark,France,Germany,Nethe
rlands,Luxembourg enum Colors
blue,red,yellow,gray var Colors
colorCountry solve colorFrance ltgt
colorBelgium colorFrance ltgt
colorLuxembourg colorFrance ltgt
colorGermany colorLuxembourg ltgt
colorGermany colorLuxembourg ltgt
colorBelgium colorBelgium ltgt
colorNetherlands colorBelgium ltgt
colorGermany colorGermany ltgt
colorNetherlands colorGermany ltgt
colorDenmark

• Variables non-numeric
• Constraints are non-linear

39
Constraint Programming
CP solvers consist of

• Domain store
• For each variable what is the set of possible
  values?
• If empty for any variable, then infeasible
• If singleton for any variable, then solution

• Constraint store
• Capture interesting and well studied
  substructures called global constraints
• Need to
• Determine if constraint is feasible WRT the
  domain store
• Prune impossible values from the domains
• This is done using specialized or generic
• GAC algorithms
• Bounds consistency algorithms

40
Turning non-binary constraints into binary

• Two methods
• Encodings
• Replace with binary constraints by introducing
  new variables
• Decompositions
• (For restricted classes of non-binary
  constraints)
• Replace with binary constraints on same variables
• Theoretical results are informative
• Comparing non-binary constraint propagation with
  binary
• Suggests where non-binary constraints are
  valuable

41
Lets start with the easy case!

• Decomposable constraints
• Non-binary constraints that can be represented by
  binary constraints with introducing new variables
• Its a special case that sometimes occurs about
  which we can be (theoretically) quite precise
• Certain non-binary constraints decompose into
  binary constraints on same variables
• Sometimes called network decomposable

42
Binary decompositions

• Two examples
• all-different(x1,x2,x3) is x1?x2, x1?x3, x2?x3
• monotone(x1,x2,x3) is x1 lt x2, x2 lt x3
• One non-example
• even(x1x2x3)
• Can you see why not?
• Can you think of any other decomposable
  constraints?

43
Binary decompositions

• Theoretical comparison direct
• compare pruning of variables in binary
  decomposition with that in non-binary
• Empirical experiments reinforce theory
• decomposing non-binary constraints can add
  orders of magnitude to solution cost

44
Binary decompositions

• Upper and lower bound on FC
• nFC1 on non-binary gt FC on decomposition gt nFC0
  on non-binary
• Gaps can be exponential
• Consider n-ary all-different with n-1 values
• nFC1 takes (n-1) branches
• FC on decomposition takes (n-1)! branches

• GAC lower bound
• GAC on non-binary gt AC on decomposition
• Gap again can be exponential
• But if we decompose too much, GACAC!
• GAC upper bound
• In general, GAC NIC, GAC PIC ..
• BUT if decomposition to clique, NIC gt GAC

45
Binary decompositions

• Tighter results provable for stricter classes
• Tree decomposable constraints
• constraint graph is tree
• Triangle preserving constraints
• non-binary constraints on all triangles

46
Binary decompositions

• Tree decomposable constraints
• e.g. monotone(x1,x2,x3)
• GACAC
• not surprising as AC is enough to solve the
  problem!
• Decomposition here doesnt lose us anything
• but even one cycle is enough for GACgtAC

47
Binary decompositions

• Triangle preserving decomposition
• e.g. all-different(x1,x2,x3), quasigroups, ...
• GAC gt PIC, gap can again be exponential
• GAC SAC, strongPC
• PIC is very strong consistency to be achieving at
  each node
• GAC can do even better than this!
• decomposition carries a very large price

48
Binary decompositions

• Experimental results
• quasigroup completion
• quasigroup existence
• Quasigroup is a Latin square
• completion is completing partially filled square
• existence is finding one with additional
  properties

49
Binary decompositions

• Modelling the quasigroup problem
• n2 vars, each with domain of size n
• Non-binary model
• 2n all-different constraints (one for each row
  and column)
• Binary decomposition
• 2n cliques of not-equals constraints

50
Binary decompositions

• Quasigroup completion
• Gomes Selman report heavy-tailed
  distributions
• Maintaining AC on binary decomposition
• problems often take long time to solve
• Maintaining GAC on all-different
• almost all problems trivial
• Quasigroup existence
• of interest to design theory
• Open results first proved by computer
• in some cases, only ever proved by computer
• Maintaining GAC very competitive
• compared to specialized model finders like
  FINDER, SEM

51
Binary encodings

• Every non-binary constraint can be encoded into
  binary constraints
• using polynomial number of additional (dual)
  variables
• Two well-known encodings
• hidden variable encoding
• add a dual variable for each non-binary
  constraint
• add constraints between original and dual
  variables
• dual encoding
• add a dual variable for each non-binary
  constraint
• throw away original variables
• add constraints between dual variables

52
Binary encodings

• Dual encoding
• consider c1even(x1x2x3), c2odd(x2x3x4)

000,011,101,110
c1
R21
R21 lt000,001gt or lt011,111gt or
lt101,010gt or lt110,100gt
001,010,100,111
c2
53
Binary encodings

• Hidden variable encoding
• consider c1even(x1x2), c2odd(x2x3)

000,011,101,110
c1
r11lt0,0gt or lt1,1gt r21lt0,0gt or
lt1,1gt r21lt0,)gt or lt1,1gt etc.
r11
r31
r21
0,1
0,1
0,1
x1
x2
x3
r22
r12
r32
001,010,100,111
c2
54
Double Encoding

• The double encoding combines the dual and the
  hidden
• consider c1even(x1x2), c2odd(x2x3)

000,011,101,110
c1
r11
r31
r21
R21
0,1
0,1
0,1
x1
x2
x3
r22
r12
r32
001,010,100,111
c2
55
Binary encodings

• Hidden variable encoding
• FC on hidden nFC0 on original
• each can be exponentially better than the other
• FC propagates through hidden variables
• FC on hidden nFC1 on original
• Hidden variable encoding
• AC on hidden GAC on original
• Before looking for efficient (specialized) GAC
  algorithm
• try AC on hidden variable encoding

56
Binary encodings

• Dual encoding
• FC on dual nFC0 on original
• each can be exponentially better than the other
• Dual better for tight constraints
• domains for hidden vars then small
• Dual encoding
• AC on dual gt GAC on original
• But domains of hidden variables are very large
  when the non-binary constraints are loose
• AC on dual prohibitively expensive
• Or is it???

57
Binary Encodings

• Binary encodings offer a way to use all known
  algorithms and heuristics developed for binary
  constraints in non-binary CSPs
• However there are serious drawbacks
• the space cost can be unmanageable
• exponential in the arity of the constraints
• the special structure of the encodings makes it
  difficult to apply generic methods efficiently
• consider the cost of AC in the dual encoding
• specialized algorithms must be developed
• On a brighter note
• strong propagation can be achieved in the dual
  and double encodings
• heuristics can be utilized in the double encoding

58
Translating non-binary CSPs into binary

• Non-binary v binary decompositions
• GAC on non-binary can be stronger than PIC on
  decomposition
• Non-binary v binary encodings
• GAC on non-binary AC on hidden
• AC on dual gt GAC on non-binary
• Non-binary v binary decompositions
• decomposition can add significantly to search
  cost
• Non-binary v binary encodings
• encoding pays in practice on tight constraints

59
Case Studies

• Let us examine how some problems can be modeled
  as non-binary CSPs
• Do the (theoretical) results affect constraint
  solving in practice?
• Case studies
• Golomb rulers
• Crossword puzzle generation
• Sudoku

60
Golomb rulers

• Mark ticks on a ruler
• Distance between any two (not necessarily
  consecutive) ticks is distinct
• Very hard combinatorial problem with applications
  in radio-astronomy

61
Golomb rulers

• There is a simple solution
• Build an exponentially long ruler
• Ticks at 0,1,3,7,15,31,63,
• The challenging goal is to find minimal length
  rulers
• We can turn the optimization problem into a
  sequence of satisfaction problems
• Start with a large m
• Is there a ruler of length m?
• Is there a ruler of length m-1?
• .

62
Optimal Golomb rulers

• Known for up to 23 ticks
• Large distributed internet project to find large
  rulers
• 0,1
• 0,1,3
• 0,1,4,6
• 0,1,4,9,11
• 0,1,4,10,12,17
• 0,1,4,10,18,23,25

63
Modeling the Golomb ruler problem

• There is a variable Xi for each tick
• The values are the possible positions on the
  ruler
• What is the domain size?
• Naïve model with quaternary constraints
• For all i,j,k,l Xi-Xj ? Xk-Xl

• Large number of quaternary constraints
• O(n4) constraints
• Looseness of quaternary constraints
• Many values satisfy Xi-Xj ? Xk-Xl
• Limited pruning

Problems with this model
64
A better non-binary model

• Introduce auxiliary variables for inter-tick
  distances
• Dij Xi-Xj
• O(n2) ternary constraints
• Post a single large non-binary constraint
• alldifferent(D11,D12,).
• relatively tight!
• Alternatively post a binary ? constraint for
  every pair of auxiliary variables
• limited pruning compared to alldifferent

65
Other modeling issues

• Symmetry
• A ruler can always be reversed!
• Break this symmetry by adding constraint
• D12 lt Dn-1,n
• Also break symmetry on Xi
• X1 lt X2 lt Xn
• Such tricks important in many problems
• Additional (implied) constraints
• Dont change set of solutions
• But may reduce search significantly
• E.g. D12 lt D13, D23 lt D24,

66
Experimental results
67
Crossword Puzzle Generation Binary model
Xi
Each word to be filled is a variable Domains? Con
straints?
X1
68
Crossword Puzzle Generation Non-binary model
X1
X2
X3
X4
X13
Each blank square is a variable Domains? Constrai
nts?
X20
X32
X43
69
Binary encodings - Experimental results

• crossword puzzles
• Original model
• vars for letters, domains A-Z
• Dual model
• vars for words, domains dictionary
• Dual sometimes 1,000 faster on larger problems
• It depends!
• Golomb rulers
• encoded using hidden var/double encoding
• Competitive with non-binary model

70
Sudoku

• Sudoku is a logic-based placement puzzle. It
  consists in placing numbers from 1 to 9 in a
  9-by-9 grid made up of nine 3-by-3 subgrids,
  called regions or boxes or blocks, starting with
  various numerals given in some cells, the givens
  or clues. It can be described with a single rule
• Each row, column and region must contain all
  numbers from 1 to 9
• We can immediately deduce that for each row,
  column, and region the values in the cells have
  to be different. Moreover, this condition is
  sufficient thus, the unique rule could be
  reformulated as
• Each row, column and region must contain numbers
  from 1 to 9 that are all different

71
Sudoku - Example
An easy Sudoku puzzle containing 26 givens
A solution
72
Case Studies - Conclusions

• Benefits of non-binary constraints
• Compact, declarative models
• Efficient and effective constraint propagation
• Supported by many constraint toolkits
• alldifferent, atmost, cardinality,
• Modeling decisions
• Auxiliary variables
• Implied constraints
• Symmetry breaking constraints
• More to constraints than just declarative problem
  specifications!
• finding the right model can be hard

73
Non-binary Constraints in Practice

• Not just all-different
• Order constraints
• Constraints on values
• Partitioning constraints
• Timetabling constraints
• Graph constraints
• Scheduling constraints
• Bin-packing constraints
• And many more

All these are sometimes called global constraints
Second International Summer School of
the Association for Constraint Programming Advanc
ed School and International Workshop
on                 GLOBAL CONSTRAINTS
       Doryssa Bay Hotel
Samos, Greece                  June 18-23, 2006
74
Order constraints

• min(X,Y1,..,Yn) and max(X,Y1,..Yn)
• X lt minimum(Y1,..,Yn)
• X gt maximum(Y1,..Yn)
• min_mod(X,Y1,..,Yn,m) and max_mod(X,Y1,..Yn,m)

• X mod m lt minimum(Y1 mod m,..,Yn mod m)
• X mod m lt maximum(Y1 mod m,..,Yn mod m)
• min_n(X,n,Y1,..Ym) and max_n(X,n,Y1,..,Ym)
• X is nth smallest value in Y1,..Ym
• X is nth largest value in Y1,..Ym

75
Value constraints

• among(N,Y1,..,Yn,val1,..,valm)
• N vars in Y1,..,Yn take values val1,..,valm
• e.g. among(2,1,2,1,3,1,5,3,4,5)
• count(n,Y1,..,Ym,op,X) where op is ,lt,gt,?,? or
  ?
• relation Yi op X holds n times
• E.g. among(n,Y1,..,Ym,k)
  count(n,Y1,..,Ym,,k)

76
Value constraints

• balance(N,Y1,..,Yn)
• N occurrence of more frequent value -
  occurrence of least frequent value
• E.g balance(2,1,1,1,3,4,2)
• all-different(Y1,..,Yn) gt balance(0,Y1,..,Yn
  )
• Can you think of an application for this
  constraint?
• How can we propagate this constraint?

77
Value constraints

• min_nvalue(N,Y1,..,Yn) and max_nvalue(N,Y1,..,Y
  n)
• least (most) common value in Y1,..,Yn occurs N
  times
• E.g. min_nvalue(2,1,1,2,2,2,3,3,5,5)
• Can replace multiple count or among constraints
• common(X,Y,X1,..,Xn,Y1,..,Ym)
• X vars in Xi take a value in Yi
• Y vars in Yi take a value in Xi
• E.g. common(3,4,1,9,1,5,2,1,9,9,6,9)
• among(X,Y1,..,Yn,val1,..,valm)
  common(X,Y,X1,..,Yn,val1,..,valm)

• Can you think of an application?

78
Partitioning constraints

• all-different(X1,..,Xn)
• Other flavors
• all-different_except_0(X1,..,Xn)
• Xi ? Xj unless XiXj0
• 0 is often used for modeling purposes as dummy
  value
• Dont use this slab
• Dont open this bin ..

79
Partitioning constraints

• all-different(X1,..,Xn)
• Other flavors
• symmetric-all-different(X1,..,Xn)
• Xi ? Xj and Xij iff Xji
• Very common in practice
• Team i plays j iff Team j plays i..
• Regin has proposed very efficient algorithm

80
Partitioning constraints

• nvalue(N,X1,..,Xn)
• Xi takes N different values
• all-different(X1,..,Xn) nvalue(n,X1,..,Xn)
• gcc(X1,..,Xn,Lo,Hi)
• global cardinality constraint
• values in Xi occur between Lo and Hi times
• all-different(X1,..,Xn)gcc(X1,..,Xn,1,1)

81
Timetabling constraints

• change(N,X1,..,Xn),op) where op is
  ,lt,gt,lt,gt, ?
• Xi op Xi1 holds N times
• E.g. change(3,4,4,3,4,1, ?)
• You may wish to limit the number of changes of
  classroom, shifts,
• longest_changes(N,X1,..,Xn),op) where op
  is,lt,gt,lt,gt, ?
• longest sequence Xi op Xi1 is of length N
• E.g. longest_changes(2,4,4,4,3,3,2,4,1,1,1,)
• You may wish to limit the length of a shift
  without break,

82
Graph constraints

• Tours in graph a often represented by the
  successors
• X1,..,Xn means from node i we go to node Xi
• E.g. 2,1 represents the cycle
• (1)-gt(2)-gt(1)
• cycle(N,X1,..,Xn)
• there are N cycles in Xi
• e.g. cycle(2,2,1,4,5,3) as we have the 2
  cycles
• (1)-gt(2)-gt(1) and (3)-gt(4)-gt(5)-gt(3)
• Useful for TSP like problems (e.g. sending
  engineers out to repair phones)

83
Graph constraints

• derangement(N,X1,..,Xn)
• there are no length 1 cycles in Xi
• e.g. derangement(2,1,4,5,3) as the 2 cycles
• (1)-gt(2)-gt(1) and (3)-gt(4)-gt(5)-gt(3) have length
  2 and 3

84
Scheduling constraints

• cummulative(S1,..,Sn,D1,..,Dn,E1,..,En,H1,.
  .,Hn,L)
• schedules n (concurrent) jobs, each with a height
  Hi
• the height can denote machine usage for example
• ith job starts at Si, runs for Di and ends at Ei
• EiSiDi
• at any time, accumulated height of running jobs
  is less than L

85
Misc constraints

• element(Index,a1,..,an,Var)
• Vara_Index
• constraint programmings answer to arrays!
• e.g. element(Item,10,23,12,15,Cost)

86
Non-binary Constraints - Conclusions

• Real problems are full of non-binary constraints
• most problems are naturally modeled with
  non-binary constraints
• We can transform any non-binary constraint into a
  binary one, but
• we lose expressive power
• propagation
• search
• Efficient algorithms for many non-binary
  constraints exist
• there is still much work to be done

87
Alternative Search Strategies

• We have reviewed search algorithms for solving
  CSPs that are either based on depth-first search
  or on local search
• BT, FC, MAC, FC-CBJ
• Min-Conflicts, Stochastic variations of
  Min-Conflicts
• Many other alternative strategies for solving
  CSPs have been proposed in the literature
• Limited Discrepancy Search, Depth Bounded
  Discrepancy Search
• Genetic Algorithms (GENET project)
• Hybrids of Backtracking and Local Search

88
Limited Discrepancy Search (LDS)

• Discrepancy heuristic is not followed
• (a value different from the heuristic is chosen)
• Idea of Limited Discrepancy Search (LDS)
• first, follow the heuristic
• when a failure occurs then explore the paths
  when the heuristic is not followed maximally once
  (start with earlier violations)
• after next failure occurs then explore the paths
  when the heuristic is not followed maximally
  twice
• after next failure occurs then explore the paths
  when the heuristic is not followed maximally
  three times
• etc.

89
Limited Discrepancy Search (LDS)

• Example the heuristic proposes to use the left
  branches

1 discrepancy taken (make one decision contrary
to the heuristic)
90
Limited Discrepancy Search (LDS)

• Example the heuristic proposes to use the left
  branches

2 discrepancies taken
3 discrepancies taken
91
Limited Discrepancy Search (LDS)

• procedure LDS-PROBE(Unlabelled,Labelled,Constraint
  s,D)
• if Unlabelled then return Labelled
• select X in Unlabelled
• ValuesX ? D(X) - values inconsistent with
  Labelled using Constraints
• if ValuesX then return fail
• else select HV in ValuesX using heuristic
• if D0 then return LDS-PROBE(Unlabelled-X,
  Labelled?X/HV, Constraints, 0)
• for each value V from ValuesX -HV do
• R ? LDS-PROBE(Unlabelled-X, Labelled?X/HV,
  Constraints, D-1)
• if R ? fail then return R
• end for
• return LDS-PROBE(Unlabelled-X,
  Labelled?X/HV, Constraints, D)
• end if
• end LDS-PROBE
• procedure LDS(Variables,Constraints)
• for D0 to Variables do D is the number of
  allowed discrepancies
• R ? LDS-PROBE(Variables,,Constraints,D)
• if R ? fail then return R
• end for

92
Limited Discrepancy Search (LDS)

• LDS can be used as a search scheme in a variety
  of search problems (not only CSPs)
• Issues about LDS
• what happens when a variable has more than 2
  values? Which discrepancies are tried first?
• how can we combine LDS with constraint
  propagation?
• LDS is efficient only if we have a good value
  ordering heuristic
• Depth Bounded Discrepancy Search (DDS) is a
  variant that combines LDS with iterative
  deepening
• it uses an increasing depth bound to search for
  discrepancies high at the search tree (where they
  are more often and more important)

93
Optimization

• So far we have looked for feasible assignments
  only
• In many cases the users require optimal
  assignments where optimality is defined by an
  objective function
• Definition Constraint Satisfaction Optimisation
  Problem (CSOP) consists of the standard CSP P and
  an objective function f mapping feasible
  solutions of P to numbers
• Solution to CSOP is a solution of P minimising /
  maximising the value of the objective function f
• To find a solution of CSOP we need in general to
  explore all the feasible valuations. Thus, the
  techniques capable to provide all the solutions
  of CSP are used

94
Branch Bound

• Branch and bound is perhaps the most widely used
  optimisation technique based on cutting sub-trees
  where there is no optimal (better) solution
• It is based on a heuristic function h that
  approximates the objective function
• a sound heuristic for minimisation satisfies
  h(x) f(x)
• in case of maximisation f(x) h(x)
• a function closer to the objective function is
  better
• During search, the sub-tree is cut if
• there is no feasible solution in the sub-tree
• there is no optimal solution in the sub-tree
• bound h(x), where bound is max. value of
  feasible solution
• How to get the bound?
• It could be an objective value of the best
  solution so far
