Data Integrity
2
Data Management

• Effective management of data is critical in
  modern organisations. Significant problems that
  typically arise include
• Multiple definitions of the same data entity (in
  separate databases)
• Inconsistent definition of similar data, where
  there are such multiple definitions - this can be
  hazardous when attempting to merge, consolidate
  or aggregate data
• Missing primary and foreign keys - data retrieval
  is impossible
• Poor knowledge of existing data, their location,
  and their meaning

3
Data Management
4
Data Integrity

• Data Integrity is the correctness and
  completeness of data in a database
• Data integrity may be violated in several ways
• Inserting invalid data values
• Updating data to incorrect values
• Missing or ambiguous data
• Redundant orphan data not being purged
• Data operations lost because of system failure
• Partially-completed transactions applied
• Poor concurrency management
• Poor management of distributed transactions
• Inadequate data security

5
Data Integrity

• DBMS systems assure data integrity by
  implementing checks to
• enforce entity integrity
• enforce referential integrity
• validate fields - is value within specified
  domain ? (also called domain integrity)
• enforce uniqueness constraints
• enforce required-value constraints (NOT NULL)
• manage transactions and concurrent operations
• manage distributed operations
• recover data after system crash
• define security constraints
• enforce business rules - using triggers

6
Entity Integrity

• There are two critical aspects to Entity
  Integrity
• the primary key (identifier) of a table must
  always contain a value
• the primary key must always be unique
• In the case of composite (concatenated) primary
  keys, no part of the key can be null
• this has implications during logical database
  design when normalising relations
• The ANSI/ISO SQL standard specifies that the
  primary key should be defined as part of the
  CREATE TABLE statement.
• The DBMS invokes the non-null uniqueness
  constraint on every insertion or update.

7
Entity Integrity SQL

• In SQL, primary key is explicitly specified in
  CREATE TABLE statement
• Example (generic syntax)
• CREATE TABLE table_1 (
• field_1 data_type PRIMARY KEY,
• field_2 data_type,
• .
• .
• .
• field_n data_type )

8
Entity Integrity SQL

• Alternative example - composite key (generic
  syntax)
• CREATE TABLE table_1 (
• field_1 data_type,
• field_2 data_type,
• .
• .
• .
• field_n data_type,
• PRIMARY KEY (field_1, field_2) )
• However, SQL also permits a table to be created
  without specifying a primary key

9
Entity Integrity Microsoft Access

• Single-column or composite primary key can be
  specified when creating a new table or altering
  design of existing table

10
Entity Integrity Microsoft Access

• If a primary key is not defined when attempting
  to save the definition of a newly created table,
  Access prompts user - may create key of
  AutoNumber (Counter) type

11
Uniqueness

• Sometimes a column, other than the primary key,
  also contains a value which is unique to each
  record
• This would be the case for records where there
  might be alternative primary keys - for example
• Vehicle Registration Number, Chassis Number
• Employee Staff ID, RSI Number, Email Address
• Supplier Supplier Code, Telephone Number, Fax
  Number, WWW Address (URL)

12
Uniqueness SQL

• In SQL, unique columns (fields) are explicitly
  specified in CREATE TABLE statement
• Example (generic syntax)
• CREATE TABLE table_1 (
• field_1 data_type PRIMARY KEY,
• field_2 data_type,
• field_3 data_type UNIQUE,
• .
• .
• .
• field_n data_type )
• If a field is specified as (being part of) the
  primary key, it is unnecessary to specify it as
  UNIQUE
• in fact, if you try to do so, may cause errors
  in some dialects of SQL !

13
Uniqueness Microsoft Access

• Uniqueness can be specified in Field Properties
  by setting value of Indexed property to Yes (No
  Duplicates)

14
Required Data

• There will often be situations where fields,
  other than the primary key field, must contain a
  value
• Example (Structured English Algebraic Notation)
• CUSTOMER Customer_Code
• Customer_Name
• Customer_Address
• (Customer_PhoneNum)
• (Customer_Email)
• Every INSERT operation must specify a non-null
  value
• Every UPDATE operation must specify a non-null
  value
• NULL is not equivalent to zero or to the empty
  string ()

15
Required Data SQL

• The NOT NULL constraint is specified as part of
  the CREATE TABLE statement
• Example (generic syntax)
• CREATE TABLE table_1 (
• field_1 data_type PRIMARY KEY,
• field_2 data_type NOT NULL
  UNIQUE,
• field_3 data_type,
• field_4 data_type NOT NULL,
• .
• .
• .
• field_n data_type )
• If a field is specified as (being part of) the
  primary key, it is unnecessary to specify it as
  NOT NULL

16
Required Data Microsoft Access

• Required values can be specified in Field
  Properties by setting value of Required property
  to Yes - unnecessary for Primary Key field(s)

17
Required Data Microsoft Access

• Alternatively, required values can be specified
  in Field Properties by setting value of
  Validation Rule property to Is Not Null

18
Domain Integrity

• Appropriate checks must be designed to ensure
  that no field takes on a value that is outside of
  the range of legal values
• Correct data type ?
• Field size restrictions ?
• Set of discrete values ?
• Range of allowable values ? Upper and / or lower
  limits ?
• Pattern matching ? Standard input mask / format ?
• Special case foreign key domains (referential
  integrity)
• The DBMS should invoke these validation checks on
  every INSERT or UPDATE operation

19
Domain Integrity SQL

• Data types and field sizes are specified as part
  of the CREATE TABLE statement
• Example (generic syntax)
• CREATE TABLE table_1 (
• field_1 CHAR(20) PRIMARY KEY,
• field_2 CHAR(15),
• field_3 NUMBER(3),
• field_4 NUMBER(5,2),
• field_5 DATE,
• .
• .
• .
• field_n data_type )
• Note data types vary between dialects of SQL

20
Domain Integrity SQL

• Check constraints can also be specified as part
  of the CREATE TABLE statement
• Example (generic syntax)
• CREATE TABLE table_1 (
• field_1 CHAR(20) PRIMARY KEY,
• field_2 CHAR(15),
• field_3 NUMBER(3),
• field_4 NUMBER(5,2),
• field_5 DATE,
• .
• .
• .
• field_n data_type,
• CHECK (field_2 IN (EUROPE, FAR EAST,
  NORTH
• AMERICA, AUSTRALASIA)),
• CHECK (field_5 BETWEEN
• 01-JAN-1999 AND 01-JAN-2000) )

21
Domain Integrity Microsoft Access

• Microsoft Access supports a variety of data types

22
Domain Integrity Microsoft Access

• Further constraints can be specified in Field
  Properties using Field Size, Input Mask,
  Validation Rule, Validation Text

23
Referential Integrity

• Parent - Child relationships exist between
  tables in a relational database
• This distinction is also referred to as Master -
  Detail or Strong Entity - Weak Entity
• All relationships in a relational database are
  effectively one-to-many
• many-to-many are broken down into multiple
  equivalent one-to-many relationships using
  intersection tables
• one-to-one are subsumed by one-to-many
• The table at the many side of the relationship
  is the Child, and the table at the one side is
  the Parent
• One-to-many relationships are implemented by
  defining a foreign key in the Child table

24
Referential Integrity Problems

• When creating a record in the Child table, the
  value inserted into the foreign key must match
  one of the values in the primary key of its
  Parent
• Otherwise, the database is corrupted (an Orphan
  is created)
• Occasionally, NULL values are allowed in foreign
  keys
• The same rule applies when updating a record in
  the Child table
• When deleting a row from the Parent table, if
  there are matching rows in the Child table(s)
  which are not also deleted, they become orphans
• Likewise, when updating the value in the primary
  key of a Parent table, the relationship with
  associated records in the Child table(s) may be
  inadvertently severed

25
Referential Integrity Solutions

• Relationships should be explicitly defined in the
  database definition
• The second problem is overcome by checking the
  value of the updated foreign key and disallowing
  illegal unmatched values
• However, note a potential problem though a value
  might be matched, it need not be correct !
• Example if a clerk were keying credit card
  numbers, and mis-keyed a number, but if by
  coincidence the mis-keyed number was valid, the
  wrong person ends up getting billed !
• ? The third and fourth problems are similar and
  can be resolved in a variety of ways
• No Restriction
• Restrict
• Cascade
• Set Null
• Set to Default Value

26
Referential Integrity Solutions

• No Restriction
• Any record in the table may be updated / deleted
  without regard to any records in any other tables
• Restrict (Delete)
• A deletion of a record in a parent table must be
  disallowed until any matching records are deleted
  from child table(s)
• Cascade
• A deletion / update of a record in a parent table
  must be automatically followed by the deletion /
  update of matching records in related child
  table(s)
• Set Null / Set to Default Value
• A deletion / update of a record in a parent table
  must be automatically followed by setting any
  matching foreign keys in related child table(s)
  to NULL or specified default value

27
UPDATE and DELETE Operations

• The Restrict rule applies at a singular level
  it only affects the Parent table in a
  relationship
• Set Null / Set to Default Value are two-level
  rules which stop at the Child table
• In contrast, the Cascade rule applies to
  multiple levels, and should therefore be
  carefully used
• data can be inadvertently erased or changed if
  invoked in inappropriate circumstances

28
Referential Integrity SQL

• Foreign keys and update / delete rules are
  specified as part of the CREATE TABLE statement
• The consequence is that Parent tables must be
  created first
• Example (generic syntax)
• CREATE TABLE table_1 (
• field_1 CHAR(20) PRIMARY KEY,
• field_2 CHAR(15),
• field_3 DATE,
• .
• .
• .
• FOREIGN KEY (field_n) REFERENCES table_2
• ON DELETE CASCADE )

29
Referential Integrity Microsoft Access

• Microsoft Access supports referential integrity,
  and the Restrict and Cascade policies

30
Referential Integrity Microsoft Access

• Combo (drop-down) boxes or list boxes can be
  used in forms to assure valid domain for foreign
  key fields

31
Referential Cycles

• Occasionally, there may be more than a single
  relationship between a pair of tables
• If null values were not allowed in the Foreign
  Key columns, insertion deadlocks could arise
• SQL permits null values in a foreign key field
• The delete and update rules that can be defined
  are also affected by this cyclic relationship

32
Business Rules

• Many data integrity constraints are tied to
  business rules which fall beyond the immediate
  scope of SQL
• Enforcement of these rules is the responsibility
  of the Database Administrator through development
  of application programs
• Triggers / Event Procedures may be defined,
  being an action or set of actions to be
  automatically executed if a particular event were
  to occur
• Example a re-order may be triggered if stock
  levels of a particular item were to drop below a
  specified level
