Heuristic Search

1
Heuristic Search

• Jacques Robin

2
Outline

• Definition and motivation
• Taxonomy of heuristic search algorithms
• Global heuristic search algorithms
• Greedy best-first search
• A
• RBFS
• SMA
• Designing heuristic functions
• Local heuristic search algorithms
• Hill-climbing and its variations
• Simulated annealing
• Beam search
• Limitations and extensions
• Local heuristic search in continuous spaces
• Local heuristic online search
• Local heuristic search for exploration problems

3
Heuristic SearchDefinition and Motivation

• Definition
• Non-exhaustive, partial state space search
  strategy,
• based on approximate heuristic knowledge of the
  search problem class (ex, n-queens, Romania
  touring) or family (ex, unordered finite domain
  constraint solving)
• allowing to leave unexplored (prune) the state
  space from zones that are either guaranteed or
  unlikely to contain a goal state (or a utility
  maximizing state or cost minimizing path)
• Note
• An algorithm that uses a frontier node ordering
  heuristic to generate a goal state faster,
• but is still ready to generate all state space
  states if necessary to find goal state
• i.e., an algorithm that does no pruning
• is not a heuristic search algorithm
• Motivation exhaustive search algorithms do not
  scale up,
• neither theoretically (exponential worst case
  time or space complexity)
• nor empirically (experimentally measured average
  case time or space complexity)
• Heuristic search algorithms do scale up to very
  large problem instances, in some cases by giving
  up completeness and/or optimality
• New data structure heuristic function h(s)
  estimates the cost of the path from a fringe
  state s n to a goal state

4
Best-First Global Search

• Keep all expanded states on the fringe
• just as exhaustive breadth-first search and
  uniform-cost search
• Define an evaluation function f(s) that maps each
  state onto a number
• Expand the fringe in order of decreasing f(s)
  values
• Variations
• Greedy Global Search (also called Greedy
  Best-First Search) defines f(s) h(s)
• A defines f(s) g(s) h(s)
• where g(s) is the real cost from the initial
  state to the state s,
• i.e., the value used to choose the state to
  expand in uniform cost search

5
Greedy Local Search Example
6
Greedy Local Search Example
7
Greedy Local Search Example
8
Greedy Local Search Example
9
Greedy Local Search Characteristics

• Strengths simple
• Weaknesses
• Not optimal
• because it relies only on estimated cost from
  current state to goal
• while ignoring confirmed cost from initial state
  to current state
• ex, misses better path through Riminicu and
  Pitesti
• Incomplete
• can enter in loop between two states that seem
  heuristically closer to the goal but are in fact
  farther away
• ex, from Iasi to Fagaras, it oscillates
  indefinitely between Iasi and Meant because the
  only road from either one to Fagaras goes through
  Valsui which in straight line is farther away to
  Fagaras than both

10
A Example
449
417
393
447
413
415
496
11
A Search Characteristics

• Strengths
• Graph A search is complete and Tree A search
  is complete and optimal if h(s) is an admissible
  heuristic, i.e., if it never overestimates the
  real cost to a goal
• Graph A search if optimal if h(s) admissible
  and in addition a monotonic (or consistent)
  heuristic
• h(s) is monotonic iff it satisfies the triangle
  inequality, i.e., ?s,s ? stateSpace (?a
  ? actions, s result(a,s)) ? h(s) ? cost(a)
  h(s)
• A is optimally efficient,i.e., no other optimal
  algorithm will expand fewer nodes than A using
  the same heuristic function h(s)
• Weakness
• Runs out of memory for large problem instance
  because it keeps all generated nodes in memory
• Why?
• Worst-case space complexity O(bd),
• Unless ?n, h(n) c(n) ? O(log c(n))
• But very few practical heuristics verify this
  property

12
A Search Characteristics

• A explores generates a contour around the best
  path
• The better the heuristic estimates the real cost,
  the narrower the contour
• Extreme cases
• Perfect estimates, A only generates nodes on
  the best path
• Useless estimates, A generate all the nodes in
  the worst-case, i.e., degenerates into
  uniform-cost search

13
Recursive Best-First Search (RBFS)

• Fringe limited to siblings of nodes along the
  path from the root to the current node
• For high branching factors, this is far smaller
  than As fringe which keeps all generated nodes
• At each step
• Expand node n with lowest f(n) to generate
  successor(n) n1, ..., ni
• Store at n
• A pointer to node n with the second lowest
  f(n) on the previous fringe
• Its cost estimate f(n)
• Whenever f(n) ? f(nm) where f(nm) minf(n1),
  ..., f(ni)
• Update f(n) with f(nm)
• Backtrack to f(n)

14
RBFS Example
15
RBFS Example
16
RBFS Example
17
RBFS Characteristics

• Complete and optimal for admissible heuristics
• Space complexity O(bd)
• Time complexity hard to characterize
• In hard problem instance,
• can loose a lot of time swinging from one side
  of the tree to the other,
• regenerating over and over node that it had
  erased in the previous swing to that direction
• in such cases A is faster

18
Heuristic Function Design

• Desirable properties
• Monotonic,
• Admissible, i.e., ?s ? stateSpace, h(s) ? c(s),
  where c(s) is the real cost of s
• High precision, i.e., as close as possible to c
• Precision measure effective branching factor
  b(h) ? 1,
• N average number of nodes generated by A over
  a sample set of runs using h has heuristic
• Obtained by solving the equation b(h)
  (b(h))2 ... (b(h))d N
• The closer b(h) gets to 1, the more precise h is
• h2 dominates h1 iff ?s ? stateSpace, h1(s) ?
  h2(s),i.e., if b(h1) closer to 1 than b(h2)
• hd(n) maxh1(n), .., hk(n) always dominates
  h1(n), .., hk(n)
• General heuristic function design principle
• Estimated cost actual cost of simplified
  problem
• computed using exhaustive search as a cheap
  pre-processing stage
• Problem can be simplified by
• Constraint relaxation on its actions and/or goal
  state, which guarantees admissibility and
  monotonicity
• Decomposition in independent sub-problems

19
Heuristic Function Design Constraint Relaxation
Example

• Relaxed problem 1
• Ignore all constraints
• h1 number of tiles out of place
• Relaxed problem 2
• Ignore only constraint 2
• h2 sum over all tiles t of the Manhattan
  distance between ts current and goal positions
• h2 dominates h1

• Constraints
• Tile cannot move diagonally
• Tile cannot move in occupied location
• Tile cannot move directly to non-neighboring
  locations

20
Heuristic Function DesignDisjoint Pattern
Databases

• Sub-problems
• A move tiles 1-4
• B move tiles 5-8

• Preprocessing for one problem class amortized
  over many run of different instances of this
  class
• For each possible sub-problem instance
• Use backward search from the goal to compute its
  cost,
• counting only the cost of the actions involving
  the entities of the sub-problem
• ex, moving tiles 1-4 for sub-problem 1, tiles
  5-8 for sub-problem 2
• store this cost in a disjoint pattern database
• During a given full problem run
• Divide it into sub-problems
• Look up their respective costs in the database
• Use the sum of these costs as heuristic
• Only work for domains where most actions involve
  only a small subsets of entities

21
Local Heuristic Search

• Search algorithms for complete state formulated
  problems
• for which the solution is only a target state
• that satisfies a goal or maximizes a utility
  function
• and not a path from the current initial state to
  that target state
• ex
• Spatial equipment distribution (N-queens, VLSI,
  plant plan)
• Scheduling of vehicle assembly
• Task division among team members
• Only keeps a very limited fringe in memory,
• often only the direct neighbors of the current
  node,
• or even only the current node.
• Far more scalable than global heuristic search,
• though generally neither complete nor optimal.
• Frequently used for multi-criteria optimization

22
Hill-Climbing (HC)

• Fringe limited to current node, no explicit
  search tree
• Always expand neighbor node which maximizes
  heuristic function
• This is greedy local search
• Strengths simple, very space scalable, works
  without modification for partial information and
  online search
• Weaknesses incomplete, not optimal, "an amnesic
  climbing the Everest on a foggy day"

23
Hill-Climbing Variations

• Stochastic HC randomly chooses among uphill
  moves
• Slower convergence, but often better result
• First-Choice HC generates random successors
  instead of all successors of current node
• Efficient for state spaces with very high
  branching factor
• HC with random restart to "pull out" from local
  maximum, plateau, ridges
• Simulated annealing
• Generates random moves
• Uphill moves always taken
• Downhill moves taken with a given probability
  that
• is lower for the steeper downhill moves
• decreases over time

24
Local Search

• Key parameter of local search algorithms
• Step size around current node (especially for
  real valued domains)
• Can also decrease over time during the search
• Local beam search
• Maintain a current fringe of k nodes
• Form the new fringe by expanding at once the k
  successors state with highest utility from this
  entire fringe to form the new fringe
• Stochastic beam search
• At each step, pick successors semi-randomly with
  nodes with higher utility having a higher
  probability to be pick
• It is a form of genetic search with asexual
  reproduction

25
Melhoras da busca em encosta

• Busca em encosta repetitiva a partir de pontos
  iniciais aleatórios
• Recozimento simulado
• Alternar passos de gradiente crescentes
  (hill-climbing) com passos aleatórios de
  gradiente descente
• Taxa de passos aleatórios diminuem com o tempo
• Outro parâmetro importante em buscas locais
• Amplitude dos passos
• Pode também diminuir com o tempo
• Busca em feixe local (local beam search)
• Fronteira de k estados (no lugar de apenas um)
• A cada passo, seleciona k estados sucessores de
  f mais alto
• Busca em feixe local estocástica
• A cada passo, seleciona k estados
  semi-aleatoriamente com probabilidade de ser
  escolhido crescente com f
• Forma de busca genética com partenogenesa
  (reprodução asexuada)
