The Accedian EtherNID

1
The Accedian EtherNID

• Addressing the need for true carrier-grade
  Ethernet demarcation-points

2
Overview

• About Accedian Networks
• The shortcomings of traditional Ethernet
• The need for Ethernet Demarcation Points
• The EtherNID EE Applications
• The EtherNID OE Applications
• The EtherNID GE Applications
• Remote Management
• Conclusion

3
Accedian Networks Inc.

• Privately held company located in Montreal and
  supported by an experienced management team and
  advisory board cumulating more than 100 years of
  experience in the telecommunications industry.
• Founded in 2004
• Solidly backed by Tier1 Canadian Venture Cap
  investment.
• In-house leading-edge expertise on the forefront
  of emerging standards in OAM for Carrier-Grade
  Ethernet Services.
• Accedian Networks was selected to be part of the
  10 Hottest Technologies Pavilion at Supercomm
  2005.
• Contributing member of the Metro Ethernet Forum
  (MEF).

4
Management Team

• Patrick Ostiguy President CEO
• Co-founder of Avantas Networks which introduced
  industrys first (Y2000) portable Carrier
  Ethernet field services test-set (now EXFO).
• Part of the initial Positron Fiber Systems teams
  that commercialized industrys first (Y1995)
  Ethernet over SONET ADM (now Marconi).
• Claude Robitaille Chief Technology Officer
• Co-founder of Colubris Networks where he
  developed a leading-edge line of WiFi Access
  routers.
• Designed a broad Datacom access product portfolio
  at Eicon Networks (10 yrs.)
• Claude Haw Chairman and Director of the Board
• GP at Skypoint Capital (Investments in Avantas,
  Dragonwave, March Networks, Meriton, Nimcat,
  Native)
• Ex. VP and General Manager of Newbridges ATMnet
  Business Unit.

5
The shortcomings of traditional Ethernet

• Initially intended for LAN usage
• Lack of OAM (Operations, Administration and
  Maintenance)
• Lack of Performance Monitoring Capabilities
• Lack of SLA Assurance Capabilities
• No clear demarcation points between the Carrier
  and the End customer
• No loop-back capabilities
• Little or no testability of the carrier circuit
• No fault isolation features
• Consequence
• Though Telecommunication Service Providers are
  faced with overwhelming customer demand for
  Ethernet Services, theyre confronted with the
  operational shortcomings of Ethernet which was
  not initially designed for Carrier Networks.
• The CAPEX savings of Ethernet are quickly
  washed-out by increased OPEX

6
Accedians solutions Raison dêtre

• Despite customer demand and Competitive Pressure,
  certain Carriers hold-back the conversion rate of
  T1-Frame-Relay customers to Ethernet Private
  Line, because of operational shortcomings.
• The Accedian EtherNID is seen as an ENABLER and
  ACCELERATOR for the deployment of new revenue
  generating Ethernet Services (VOIP, E-Line,
  E-LAN, etc.).

7
Accedians EtherNID EE
8
Existing topology
Existing topology for Transparent LAN service
delivery in B-MTU
Business Multi-Tenant Building
No Demarc Point
CPE

• Ethernet media is often extended for substantial
  lengths between the Access Point and the customer
  IT closet.
• Loss of all OAM ability as soon as coming out of
  the transport network.
• No clear demarcation point between the carrier
  and the customer.

Customer A
No Demarc Point
CPE
Customer B
No Demarc Point
CPE
Customer C
No Demarc Point
CPE
Customer D
NO END-TO-END SERVICE VISIBILITY
Access Platform
Ethernet
Metro Transport Network
Access Point
Carrier Network Management Visibility (OAM)
Loss of Network Management Visibility
9
Transparent LAN service delivery
Business Multi-Tenant Building
Transparent LAN Service delivery The Accedian
EtherNID solution
NID
CPE
Customer A
Carrier Demarc Point

• EtherNID provides a clear carrier/customer
  demark point.
• Can be line-powered.
• Provides End-to-End visibility.
• The CSU of Ethernet

NID
CPE
Carrier Demarc Point
Customer B
Preserved Management Visibility (OAM) using NIDs
NID
CPE
Customer C
Carrier Demarc Point
NID
CPE
Carrier Demarc Point
Customer D
Access Platform
Ethernet
Metro Transport Network
Access Point
Carrier Network Management Visibility (OAM)
Preserved Network Management Visibility
10
In-line OAM operation
OAM
Network side
Client side
Loop-backs

• IEEE 802.3ah Ethernet OAM
• Layer 1-2-3-4 loopbacks (MAC address swap, IP
  address swap, and TCP/UDP port swap).
• Individual VLAN loop-backs
• Service Level Loopbacks
• Loop-back on specific MAC source and/or
  destination address
• Loop-back on specific IP source and/or
  destination address
• On-board storage of Ethernet Performance
  Monitoring data.
• Bandwidth usage statistics allow customer trend
  tracking.
• Integrated TDR cable integrity check on both
  sides of NID.
• Dying Gasp Messages

11
Assured Ethernet Performance

• Unique Fast-Thru architecture (vs. store
  forward).
• Assures Ultra-low Latency through unit (0.8
  microsecond)
• Assures Ultra-low Jitter through unit (0.1
  micro-second)
• Proprietary Silicon-based HW datapath (as opposed
  to SW / Network Processor)
• Full Gig wirespeed at all packet sizes
• Provides optimum Performance for VoIP and Video
  over IP.

Optimized for High-Performance Ethernet
Network side
Client side
12
Add reliability to Ethernet

• Can be Line-Powered via PoE (Power over
  Ethernet).
• Extends 48V power plant reliability up to the
  IT-closet.
• Avoids dependency on customer-provided power.
• Transparent fail-over bypass (does not create a
  single point of failure)
• Doesnt affect MTBF of the E-Line

Designed for High-Availability Ethernet
-48V PoE
Client side
Network side
13
Monitoring Access

• Dual Monitor Ports for non-intrusive
  trouble-shooting
• Provides individual access to eastbound and
  westbound directions, or combined access to both
  directions using Port Mirroring.
• True tap functionality allows non-intrusively
  seeing Layer1 errors and timing errors.
• Allows applying filters to monitor only selected
  parts of traffic (per VLAN, MAC, IP).

Network side
Client side
Test Set
Non-intrusive Monitor Ports
14
Test set interaction

• EtherNID reacts to in-band loop-back commands of
  industry-popular Ethernet Test Sets (such as
  Sunset MTT, FST-2802, T-BERD-8000, QT-600 and
  others).
• Provides for testing in Loopback mode vs.
  Head-to-Head (allowing for single-ended testing)

Customer device
NID
Test Set
Test Traffic
Access Platform
Access Platform
Metro Network
Test Head

• Reduces the amount of test-sets required in the
  field
• (Increases the amount of test-sets available for
  turn-ups)

REDUCES CAPEX AND OPEX
15
VLAN Tagging and Filtering

• Can be used for VLAN Tag-Detag at customer edge.
• Carrier can configure a table of VLANs to block
  or pass-through.
• Allows controlling the quantity of VLANs that the
  end-customer can use.
• Allows billing the customer on a per-VLAN basis.
• Allows BPDU (Spanning Tree) filtering.
• Supports .1Q in .1Q
• Supports oversized packets up to 1800 bytes on
  100Mbps (9600 on GigE).
• Can complement or replace the use of a VLAN-aware
  edge switch.
• Maintains per-flow statistics, all remotely
  available via SNMP.
• Ideal for delivery and validation of prioritized
  VLAN service delivery.
• Designed to comply with MEF service delivery
  model.

Block VLANs 2000 to 4095
VLAN 3056
VLAN 234
Pass-through VLANs 0 to 1999
Client side
Network
VLAN filter
16
Multi-carrier application
Customer LAN
Carrier A
Carrier B
Customer LAN
Carrier A
NID
NID
NID
NID

• End-to-end customer link spans across multiple
  Carriers
• EtherNID allows better sectionalization of the
  end-to-end link
• Eliminates finger pointing between Carriers

17
Central Office / Colocation Application

• Modular, Mix Match, Grow as you go
• Provides E-line monitoring troubleshooting
  facilities at the CO
• Ideal for collocation sites
• Gives visibility to Inter-carrier Ethernet
  Handoffs
• Fail-safe bypass nature (same MTBF as a passive
  device)

18
Accedians EtherNID OE
Ethernet-OAM-enabled optical port extension to
Metro Ethernet Access Platforms
19
Business Park FTTP/EFM Application
(single tenant applications)
NID
CPE
Metro Ethernet Core/Access Vehicle
NID
CPE
100Base-FX optical or Gig-E
NID
CPE
Metro POP
NID
CPE

• Versatile SFP modules
• Dual Fiber or Single-Bidi fiber
• Diagnostics supporting light levels (SFF-8472)
• Can be powered by PoE via Electrical side.

NID
CPE
20
Streamlined Topology
Typical Book-end /Duct-Tape Topology
End-to-end Managed Standalone NIDs
21
Accedians EtherNID GE

• Gigabit Ethernet version of the EtherNID
• 4 ports 2 SFPs and 2 built-in RJ-45, all 4
  ports supporting tri-rate.
• All 4 ports can be assigned to be either Network,
  Client, Monitor A or B.
• Universal Applications also mix match copper
  SFPs for even more variety.
• Support for Jumbo Frames (9600 bytes)

22
In-Service Performance Assurance

• Existing performance verification methods are
  disruptive to the customers traffic.
• Accedian is proposing a method that allows
  characterizing network performance while it is
  IN-SERVICE (when the most interesting phenomenon
  usually happen).

Customer device
NID
Customer Traffic
Verification OAM packets
Access Platform
Access Platform
Metro Network

• Accedian introduces a technology and method to
  allow L2/L3 Service performance verification
  while customers traffic remains unaffected.
• Allows true SLA verification and enforcement.
• Avoids having to use EXPENSIVE maintenance
  windows (nights weekends) when network
  conditions are not like prime-time.

23
In-Service Performance Assurance Agent
In-Service Performance Assurance Agent (PAA)

• Monitors key performance health parameters
  (Latency, Jitter, One-Way Jitter,
• One Way Packet loss, End-to-end
  continuity)
• High Precision measurements 1 microsecond
  accuracy.
• Assures End-to-end performance across
  Multi-Vendor/Multi-Carrier Layer 2-3 networks
• Critical requirement for the delivery of
  end-to-end differentiated VoIP and Video services

24
Multi-Instance, Multi-SLA PAA

• Measurements on a multi-flow / multi-VLAN /
  multi-service basis.

• Runs on a continuous basis
• User settable threshold crossing alerts sends
  SNMP traps when SLAs are violated
• Up to 64 simultaneous PAA streams between two
  NIDs
• Each PAA stream can be tailored to mimic a
  specific service stream in terms of
• Packet size, VLAN, P-bit, QinQ, DSCP, ToS, ECN,
  dest IP, dest MAC

25
Multi-Instance, Point-to-Multipoint PAA
Map-out the Health of your Network
26
Mapping-out Network Health
Mapping-out Network Health
microSecond accurate SLA Performance Assurance
Increasing the revenue Dollar of every packet
SNMP MIBs
SNMP traps
27
Remote Management
Remote Management
28
Integrated web server interface

• The EtherNID comes with an integrated Secure
  Web Driven user interface included.
• No need for a special GUI software to install on
  Laptops for configuration
• (uses the web browser).
• Also, integrated CLI interface on serial port
  for manual configuration or Batch configurations
  via CLI scripts, also available remotely and
  securely via SSH.

29
If Access Platform supports 802.3ah
30
Management via VLAN tunnel
31
Direct Monitoring via SNMP
32
Other management features

• Embedded Linux OS
• Config Flash File System
• Remote Syslog
• NTP Client
• Radius Authentication Client
• DNS Client (e.g. use circuit ID as URL)
• DHCP Client
• TFTP, SFTP, FTP, HTTP

33
Other mounting configurations
Dual units in 1U rackmount
Wallmount
34
Carriers incentive for Accedian products

• Enables and Accelerates the deployment support
  maintenance of new revenue generating Ethernet
  Services (VOIP, E-Line, E-LAN, etc.).
• Reduces down-time and MTTR.
• Avoids Duct-tape/stacked solutions, more
  reliability and better integration.
• Creates clear demarc-point between the Carriers
  and Customers Network.
• Cuts the OPEX and CAPEX of turnup testing by
  half.
• Allows mapping-out the Health of a Network.
• Assures visibility of the Quality of Service
  SLA Assurance.
• Allows verifying, tracking, recording and
  defending SLAs and reducing penalties.
• Allows offering value-added SLAs (increases de
  revenue Dollar of every packet).
• Allows making the SLA service assurance data
  available to the end-customer.
• Reduces Carriers OPEX
• Reduces truck-roll with remote maintenance makes
  a better impression on customers
• price of 1 truck-roll price of 1 EtherNID
• Makes troubleshooting more efficient
• Eliminates finger-pointing
• Increases customer satisfaction and enhances
  perception of the service provider.

35
Conclusion

• The EtherNID is the industrys only
  purposely-designed Ethernet Demarcation Device
  (not a derivative of a media-converter or a
  switch).
• Accedian Networks provides innovation
• With unique differentiators
• At a price-point which unlocks the business-case
  for Carrier Ethernet deployment.
• Combination of EE, OE and GE versions provides a
  consistent feature set and look feel across the
  network.
• Field Evolvable SW Platform allows following
  emerging standards.
