MultiDimensional Array implementation for TSP

1
Multi-Dimensional Array implementation for TSP
Variations of Linked List
2
A Special Case of TSP
D
1
10
2
3
3
2
2
3
5
S
7
3
6
4
5
7
5
4
Note this is only one example, not a general
description of the problem.
3
Using Multi-Dimensional Array to Solve TSP- An
Idea

• Use a 2 dimensional array to store the distance
  between cities, named D
• Use permutation to generate all possible paths,
  store the paths in an array of structures, named
  P. Each element of the array can contain the
  order and the cost of a particular path.
• Trace D against every element in P to obtain the
  total cost.
• Compare total cost of all elements in P to obtain
  the best path.

4
Issues to be discussed

• Space needed
• Time complexity

5
Review of the Linked List

• Whats good about using linked list over the
  array structure?
• What are the basic operations?
• How do you implement the basic operations on a
  basic linked list structure?

A list
A node
6
Homework

• Write a C program with two classes Node
  LinkedList
• The Node class has 2 public data members a
  data (int type), and a pointer points to the
  next Node object. (Node).
• The LinkedList class has 2 public data members a
  pointer points to the first Node object, and the
  size of the list (int).
• The LinkedList has public member functions to
  conduct the 5 basic operations list_initialize,
  check_empty, traverse, insertion, and deletion.

7
Variations

• A standard linked list (1) only the first node
  is directly accessible (2) each node consists of
  a data part and a single link that connects to
  its successor
• Variations of the standard linked list exist
  circular-linked lists, linked stacks and queues,
  doubly-linked lists, multiply linked lists (in
  the text)

8
Linked Stacks and Queues

• Similar to the deficiency issues of the
  array-based implementation of list, stacks ad
  queues can have the same problem
• Using a linked list instead of an array allows
  the stack or queue to grow without limit (except
  for available memory) and to shrink without
  wasting unused storage.
• A stack is a essentially a list in which items
  can be accessed at only one end. The push
  operation is simple an insertion at the beginning
  of a linked list. While the pop operation is a
  deletion of the first node.

9
Linked Queue

• A linked implementation of a queue is a simple
  extension of the linked implementation of stacks.

queue
stack
10
Circular Linked List
A circular list
A node
11
Double Linked Lists
A double linked list
A node
12
Multiple-Linked Lists

• Nodes contain info with more than one link

List 1
List 2
13
Midterm ideas

• Coverage basics of algorithm analysis, sorting
  algorithms, multi-dimensional arrays, linked
  lists veriations
• Questions
• Styles
