Agent-Based Decentralised Control of Complex
Distributed Systems
Alex Rogers School of Electronics and Computer
Science University of Southampton acr_at_ecs.soton.ac
.uk http//users.ecs.soton.ac.uk/acr/
2
Contents

• Agent-Based Decentralised Control
• Cooperative Systems
• Local Message Passing Algorithms
• Max-sum algorithm
• Graph Colouring
• Wide Area Surveillance Scenario
• Competitive Systems
• Game Theory
• Mechanism Design
• Eliciting Effort in Open Information Systems
• Decentralised Energy Systems

3
Electronics and Computer Science

• 5 for Electrical and Electronic Engineering
• 5 for Computer Science
• 100 academic staff
• 36 professors
• 150 research fellows
• 250 PhD students
• Research grant income
• 15 million per annum
• 10 million from UK Research Councils

4
Intelligence, Multimedia and Agents Research Group

• Design and application of computing systems for
  complex information and knowledge processing
  tasks
• Agent-Based Computing
• Digital Libraries
• Decentralised Information Systems
• E-Business Technologies
• Grid and Distributed Computing
• Human Computer Interaction
• Web Science
• Knowledge Technologies
• Trust and Provenance

5
Contents

• Agent-Based Decentralised Control
• Cooperative Systems
• Local Message Passing Algorithms
• Max-sum algorithm
• Graph Colouring
• Wide Area Surveillance Scenario
• Competitive Systems
• Game Theory
• Mechanism Design
• Eliciting Effort in Open Information Systems
• Decentralised Energy Systems

6
Agent-Based Decentralised Control

• Multiple conflicting goals and objectives
• Discrete set of possible actions

Agents
7
Agent-Based Decentralised Control

• Multiple conflicting goals and objectives
• Discrete set of possible actions

Sensors
8
Agent-Based Decentralised Control

• Multiple conflicting goals and objectives
• Discrete set of possible actions
• Some locality of interaction

Agents
9
Agent-Based Decentralised Control

• Multiple conflicting goals and objectives
• Discrete set of possible actions
• Some locality of interaction

Maximise Social Welfare
Agents
10
Agent-Based Decentralised Control

• Cooperative Systems
• All agents represent a single stakeholder
• We have access to these agents (closed system)
• We can design the strategies that the agents
  adopt and the mechanisms by which they interact
• Competitive Systems
• Agents represent multiple stakeholders
• We can not directly influence the strategies of
  the agents (open system)
• We can only design the protocols and mechanisms
  by which they interact

11
Cooperative Systems

• Decentralised control and coordination through
  local computation and message passing.
• Speed of convergence, guarantees of optimality,
  communication overhead, computability

• No direct communication
• Solution scales poorly
• Central point of failure

Central point of control
Agents
12
Landscape of Algorithms
Optimality
Complete Algorithms DPOP OptAPO ADOPT
Message Passing Algorithms Sum-Product Algorithm
Iterative Algorithms Best Response
(BR) Distributed Stochastic Algorithm (DSA)
Fictitious Play (FP)
Greedy Heuristic Algorithms
Communication Cost
13
Sum-Product Algorithm
Find approximate solutions to global optimisation
through local computation and message passing
A simple transformation allows us to use the
same algorithms to maximise social welfare
Factor Graph
Variable nodes
Function nodes
14
Graph Colouring
Graph Colouring Problem
Equivalent Factor Graph
Agent
function / utility
variable / state
15
Graph Colouring
Equivalent Factor Graph
Utility Function
16
Max-Sum Calculations
Variable to Function Information aggregation
Function to Variable Marginal Maximisation
Decision Choose state that maximises sum of all
messages
17
Graph Colouring
18
Optimality
19
Communication Cost
20
Robustness to Message Loss
21
Hardware Implementation
22
Wide Area Surveillance Scenario
Dense deployment of sensors to detect pedestrian
and vehicle activity within an urban environment.
Unattended Ground Sensor
23
Energy Constrained Sensors

• Maximise event detection whilst using energy
  constrained sensors
• Use sense/sleep duty cycles to maximise network
  lifetime of maintain energy neutral operation.
• Coordinate sensors with overlapping sensing
  fields.

duty cycle
time
duty cycle
time
24
Energy-Aware Sensor Networks
25
Future Work

• Continuous action spaces
• Max-sum calculations are not limited to discrete
  action space
• Can we perform the standard max-sum operators on
  continuous functions in a computationally
  efficient manner?
• Bounded Solutions
• Max-sum is optimal on tree and limited proofs of
  convergence exist for cyclic graphs
• Can we construct a tree from the original cyclic
  graph and calculate an lower bound on the
  solution quality?

26
Contents

• Agent-Based Decentralised Control
• Cooperative Systems
• Local Message Passing Algorithms
• Max-sum algorithm
• Graph Colouring
• Wide Area Surveillance Scenario
• Competitive Systems
• Game Theory
• Mechanism Design
• Eliciting Effort in Open Information Systems
• Decentralised Energy Systems

27
Competitive Systems

• Controlling open competitive systems is much more
  difficult
• Global credit crisis
• Key challenges
• Understanding the emerging macroscopic properties
  of a system of selfish competitive agents
• GAME THEORY
• Designing protocols and rules of the game such
  that these macroscopic properties are desirable
• COMPUTATIONAL MECHANISM DESIGN

28
Game Theory

• For a given game
• What action should a rational player take?
• What is the equilibrium action of all players?
• Nash equilibrium

A Beautiful Mind Genius and Schizophrenia in
the Life of John Nash Sylvia Nasar Faber and
Faber
29
Nash Equilibrium

• Two strategies s1 and s2 are in Nash equilibrium
  if
• under the assumption that agent i plays s1, agent
  j can do no better than play s2 and
• under the assumption that agent j plays s2, agent
  i can do no better than play s1.
• Neither agent has any incentive to deviate from a
  Nash equilibrium

30
Nash Equilibrium
Column Player Column Player Column Player
LEFT MIDDLE RIGHT
Row Player UP 4 , 3 5 , 1 6 , 2
Row Player MIDDLE 2 , 1 8 , 4 3 , 6
Row Player DOWN 3 , 0 9 , 6 2 , 8
NE
1
3
2
4
31
Computational Mechanism Design

• Mechanism design concern the analysis and design
  of systems in which the interactions between
  strategic, autonomous and rational agents leads
  to predictable global outcomes.
• Design interactions to ensure the system has
  desirable and predictable Nash equilibrium
• Computational mechanism design
• Limited communication
• Incomplete information
• Bounded computation

32
Nash Equilibrium
Column Player Column Player Column Player
LEFT MIDDLE RIGHT
Row Player UP 4 , 3 5 , 1 6 , 2
Row Player MIDDLE 2 , 1 8 , 4 3 , 6
Row Player DOWN 3 , 0 9 , 6 2 , 8
NE
1
3
2
4
33
(No Transcript)
34
(No Transcript)
35
First Price Auction

• Desirable properties
• Efficiency
• Allocation
• Item assigned to the highest bidder
• Payment
• Pay bid ( )
• Bidding strategy
• Shade bid
• Bayes Nash

36
Second Price (Vickrey) Auction

• Desirable properties
• Efficiency
• Allocation
• Item assigned to the highest bidder
• Payment
• Pay second bid
• Bidding strategy
• Bid true valuation
• Dominant strategy

37
Open Information System

• Information buyer requires a prediction of an
  uncertain
• Tomorrows temperature
• Requires certain minimum precision or
  certainty

c(?)
?
c(?)

• Identify cheapest provider
• Make prediction of precision of at least ?0
• Truthfully report this prediction to buyer
• Ensure providers utility is positive in
  expectation

?
?0
c(?)
?
38
Two Stage Mechanism

• Two stage Mechanism
• Ask information producers to declare their costs
• Ask cheapest producer to make measurement and
  reward him with a payment using a strictly
  proper scoring rule calculated from the second
  lowest cost
• Payment is made once the event is verified
• Desirable system wide properties
• Dominant strategy to truthfully declare costs
• Information buyer can always identify cheapest
  supplier
• Dominant strategy to commit effort and truthfully
  reveal prediction

39
Challenges

• Solution concepts
• Mechanisms with dominant strategy solutions are
  rare
• How do we automate the design process?
• Decentralised Mechanisms
• Remove need for a central auctioneer
• Payment Free Mechanism
• Non-transferable utility
• Induce cooperative behaviour through reciprocity
• Iterated Prisoners Dilemma
• Trust and reputation models
• Match making mechanisms to pair producers and
  buyers

40
Contents

• Agent-Based Decentralised Control
• Cooperative Systems
• Local Message Passing Algorithms
• Max-sum algorithm
• Graph Colouring
• Wide Area Surveillance Scenario
• Competitive Systems
• Game Theory
• Mechanism Design
• Eliciting Effort in Open Information Systems
• Decentralised Energy Systems

41
2016 Zero Carbon Home
Wireless Sensors
Appliances
Flywheel Storage
Micro-CHP
Plug-in Hybrid
42
Energy Exchange
43
Research Questions

• How to coordinate energy use and make optimal
  energy trading decisions within the home to
  minimise energy consumption / costs?
• Load management through smart appliances
• Predicting load (occupancy, activity, weather
  conditions)
• Understanding and learning thermal
  characteristics of home
• Price prediction in external and local markets
• Optimal use of storage devices
• Optimal decisions to buy electricity / use CHP

44
Research Questions

• What protocols and trading mechanisms generate
  desirable system wide properties?
• Stable, predictable and low prices
• Minimise CO2 emissions through flattening demand

45
Publications

• Farinelli, A., Rogers, A., Petcu, A. and
  Jennings, N. R. (2008) Decentralised Coordination
  of Low-Power Embedded Devices using the Max-Sum
  Algorithm. In Proceedings of the Seventh
  International Conference on Autonomous Agents and
  Multi-Agent Systems (AAMAS 2008), pp. 639-646,
  Estoril, Portugal.
• Papakonstantinou, A., Rogers, A., Gerding, E. and
  Jennings, N. (2008) A Truthful Two-Stage
  Mechanism for Eliciting Probabilistic Estimates
  with Unknown Costs. In Proceedings of the
  Eighteenth European Conference on Artificial
  Intelligence (ECAI 2008), pp. 448-452, Patras,
  Greece.
• R. K. Dash, N. R. Jennings, and D. C. Parkes.
  (2003) Computational Mechanism Design A Call to
  Arms. IEEE Intelligent Systems, pages 4047.

46
Questions

• Thank you for your attention.
