Strong Security for Network-Attached Storage

1
Strong Security for Network-Attached Storage

• Course CS795
• Advisor Dr. Ravi Mukkamala
• Speaker Sridhar Panigrahi
• Date March 24, 2004

Department of Computer Science, Old Dominion
University
2
Table of Contents

• Introduction
• Storage Architecture and Secure Network-Attached
  Disks (SNAD)
• SNAD System Design and Operations
• Basic Mechanism and Features
• SNAD Data Structure
• SNAD Schemes 1,2 and 3
• SNAD Security and Operation
• SNAD Performance
• Conclusions
• References

3
Introduction

• Why Secure Storage ?
• File system stored in a centralized Server is
  vulnerable to anyone who can obtain super-user
  access
• Files are stored in clear text
• NFS provides limited security
• Network-Attached Storage (NAS) can replace
  traditional centralized storage system

4
Storage Architecture
5
Secure Network-Attached Disks (SNAD)

• Disks are attached directly to a Network and rely
  upon own Security rather than Servers protection
• Provides authentication and Encryption
• System Stores and transfer encrypted data across
  the network and only decrypted at the client
  workstation
• Administrator backing up the storage system has
  access to only encrypted data
• Authorized Group/Users of a particular file(s)
  are only ones with access to its unencrypted
  contents.

6
SNAD System Design

• Three (3) Security Alternatives
• First two are CPU intensive because they use
  public-key encryption and are more secure
• Third alternative avoids use of public-key
  encryption resulting in high performance.
• Desirable Features
• Disk must not contain enough information to
  decrypt data.
• Data integrity User must be sure that data
  received from disk are those originally stored.
• Flexibility File sharing feasible
• High Performance and Scalability

7
SNAD Basic Mechanism

• System uses symmetric key for data encryption and
  decryption at the client
• Server Provided with sufficient information to
  authenticate the writer/reader to verify
  end-to-end data integrity
• Public-key cryptography is used to allow disks to
  store information to decrypt their files
• Symmetric keys are stored in the disk encrypted
  with public-key

8
SNAD Basic Mechanism contd

• Disk provides encrypted data blocks and encrypted
  keys to the client upon request
• User decrypt the symmetric key with his
  private-key to get the plaintext
• Employ strong password/smartcard authentication
  to access the system (client)
• The private key is stored at the client
• SNAD uses 128-bit keys for symmetric algorithm
• Can use longer than 128-bit keys

9
SNAD Basic Mechanism

• Client uses RC5 algorithm ( also Rijndael
  acceptable) to encrypt data before it leaves the
  client
• SNAD used cryptographic hashes and keyed hashes
  such as MD4, MD5, SHA-1 HMAC
• HMAC use a cryptographic hash in conjunction with
  a shared secret key to check integrity and
  authenticate writer

10
SNAD Data Structure

• Four Basic Structures
• Secure Blocks
• File Objects
• Key Objects
• Certificate objects
• Data need not be stored contiguously on the disk

11
Relationships between Objects in a Secure
Network-Attached Disks (SNAD)
Certificate Object
Key Object
Key Object
File Object
File Object
File Object
Secure Block
Secure Block
Secure Block
Secure Block
Secure Block
Secure Block
12
SNAD Data Structure contd.

• Multiple file objects use a single key object.
• This corresponds to a situation where two files
  have the same access control.
• Relatively few key objects on the disk just as
  there are few unique groups in a standard unix
  file system
• Each data object requires 36-100 bytes overhead
  depending on the security scheme
• File objects require little overhead just as a
  pointer to a key object.
• Key objects require 76 bytes for header and 72
  bytes for each user.

13
SNAD Data Structure contd.

• For 10,000 users is a part of 200 different
  groups
• there is need of 148 MB of Key Objects or 0.37
  of a 40 GB Disk
• CA object requires less than 300 bytes/user (3
  MB)
• SNAD occupies less than 3 overhead for a 40 GB
  disk.
• (Unix file system typically occupies 1-2 of
  total storage)

14
File Objects

• Composed of one or more secure blocks along with
  per-file metadata
• Metadata
• Block pointers
• file size
• timestamps
• A pointer to key object

15
Secure Blocks

• Minimum unit of data that can be read or written
  in the secure file system
• Block ID unique identifier for the file
  identifier and block number in a file
• User ID Determines which public-key or writer
  authentication key to use to check the security
  of the block
• Time Stamp Used to prevent Replay attacks
• Data is encrypted using symmetric key. Key is
  obtained from key object associated with the file

16
Secure Blocks
Block Security Information
Block ID (may be part of file metadata)
User ID (may be part of file metadata)
Timestamp
Data (encrypted)
17
Key Objects
Key file ID User ID Signature Ref Count
User ID Encrypted Key Permissions
User ID Encrypted Key Permissions

User ID Encrypted Key Permissions
18
Key Objects

• Key Object Header
• Key File ID Unique Identifier for the key object
• User ID Last user modified the key object
• Signature When a user writes the object, he
  hashes the entire object except for the reference
  count and signs the hash with his private key and
  store in the signature field
• Signature (H ( key Object Ref count) )
  private-key
• Ref Count System needs to know when this key is
  no longer needed
• Any authorized user who modifies the key object
  must sign to trace illegitimate modification to a
  particular user

19
Key Objects contd

• Each tuple of the key object includes a User ID ,
  encrypted key and user permission for that user
• User ID need not belongs to a single user may be
  of a group of users with shared access to a
  single private key
• Encrypted Key Key for symmetric RC5 algorithm.
  This is encrypted with Users public key
• Disk cannot decrypt unless it gets users private
  key (private keys are kept in the client
  machine, never sent to the disk)

20
Key Objects contd

• Permission field is used by the disk to determine
  whether the user is allowed to write the key
  object
• A key object may be used for more than one file
• All files that use the key object are encrypted
  with the same symmetric encryption key and are
  accessible by the same set of users corresponds
  to a group

21
Certificate Objects

• Each Network-attached disk contains a single
  certificate object

User ID Public Key HMAC Key Timestamp
User ID Public Key HMAC Key Timestamp
User ID Public Key HMAC Key Timestamp
.
User ID Public Key HMAC Key Timestamp
22
Certificate Objects contd

• The disk uses the information in the certificate
  object to authenticate users and do basic storage
  management
• User ID Identifies user or group
• Public key
• stored in disk for convenience and need not
  consult a centralized key server
• For writer authentication

23
Certificate Objects contd

• HMAC key is used for Schemes 1,2
• Used to verify the user identity who is writing
  data and is stored encrypted
• the decryption key for the HMAC keys held in
  non-volatile memory on the disk.
• on disk startup HMAC keys are decrypted and
  cached into volatile memory.
• Timestamp field updates each time a user writes a
  file object and used to prevent replay attacks.

24
SNAD Security Scheme 1

• Disk Write Ops
• At the client ( H ( encrypt Data Block )
  File Object ) ) signed with private-key
• Disk Re-computes the hash using users public-key
  to authenticate the user before writes to disk
• Read Ops
• No operation at the SNAD Server CPU
• Client CPU check the hash and signature and
  then decrypt the data

25
SNAD Security Scheme 1
Read
Write
Operations Client NAS Client NAS
En/Decrypt X X
Hash X X X
Signature X
Verification X X
Cryptographic Operations used in Scheme 1
Network-attached storage (NAS)
26
SNAD Security Scheme 2

• Same as Scheme 1 except
• Signature verification is NOT done at SNAD Server
• Advantages Reduces load on SNAD disk CPU
• Client verifies the signature on Read operation

27
SNAD Security Scheme 2
Read
Write
Operations Client NAS Client NAS
En/Decrypt X X
Hash X X X
Signature X
Verification X
Cryptographic Operations used in Scheme 2
Network-attached storage (NAS)
28
SNAD SecurityScheme 3

• Write
• Uses keyed-hash (HMAC) approach to authenticate a
  writer of data block and verify block integrity
• Client encrypt secure block and computes HMAC
  over ciphertext and send it to disk
• Disk re-computes HMAC for authentication using
  the shared secret key
• Read
• Disk calculates HMAC using the key from the
  requesting user and sent the data object along
  with the new HMAC to the client

29
SNAD Security Scheme3
Read
Write
Operations Client NAS Client NAS
En/Decrypt X X
Hash X X X X
Signature
Verification
Cryptographic Operations used in Scheme 3
Network-attached storage (NAS)
30
Block Write Operation
HMAC
Block ID
UID
Time Stamp
IV
User (UID)
1.Generate RC5 keys 2. Encrypt this key
3. Send to drive 4.Break file into 64 KB Blocks
5. Encrypt each block a
to obtain Ba 6. Append timestamp
7. Append Keyed Hash
8. Send block to disk 9. Modify key object if
needed
Network Disk
1. Verify keyed-hash 2. Verify timestamp
3. Store new timestamp 4. Verify
write permission 5. Write block
Data
31
Block Read Operation
HMAC
Block ID
UID
Time Stamp
IV
User (UID)
Network Disk
1. Verify timestamp 2. Verify HMAC
3. Decrypt to obtain Ba
1.Receive request for a particular block
2. Calculate HMAC based on the user
authentication key (KEYmac) 3.
Update timestamp in certificate object
4. Send secure data object
Data
32
Performance

• Strong Security can be achieved without
  sacrificing performance
• Sequential Data transfer (read write)
• 15- 20 performance loss over raw data transfer.
• Penalty of between 1-20 depending on the work
  load. Can be reduced by introducing encryption
  hardware on CPUs.
• Random I/O operation (write read)
• Suffers almost no performance penalty

33
Performance
300 MHz Power PC with G3 processor Scheme 1, 2 Bandwidth (MB/sec) Scheme 3 Bandwidth (MB/sec)
Read 6.4 MB/sec 10.0MB/sec
Write 1.4 MB/sec 12.7 MB/sec
34
Cryptographic Overhead for SNADwith 300 MHz. MPC
750 (Power PC G3 processor)
Time (ms)
35
Conclusions

• SNAD offers strong security without reducing
  performance drastically
• Provides 88 of maximum for writes and 81 of
  maximum for reads for sequential operation
• Random access reads and writes suffers almost no
  penalty
• System provides user data Confidentiality and
  Integrity the moment it leaves the client
  computer
• SNAD performs better with the distributed storage
  than centralized storage
• User addition to access group is straightforward,
  but revocation is still an issue.

36
References

• 1 Ethan L. Miller, Darrell D. E. Long, William
  E. Freeman, Benjamin C. Reed. Strong Security for
  Network-Attached Storage. In Proceedings of the
  FAST 2002 Conference on File and Storage
  Technologies, Monterey, California, USA., January
  28-30, 2002
• 2 William Freeman, Ethan Miller. Design for a
  Decentralized Security System for Network
  Attached Storage. 8th NASA Goddard Conference on
  Mass Storage Systems, held jointly with the 17th
  IEEE Symposium on Mass Storage Systems, College
  Park, MD, March 2001.
• 3 Scott A. Brandt, Ethan L. Miller, Darrell
  D.E. Long, Lan Xue,
• Storage Systems Research Center, UC,Santa
  Cruz. Efficient Metadata
• Management in a Large Distributed Storage
  Systems, 20th IEEE/11th
• NASA Goddard Conference on Mass Storage
  Systems and Technologies,
• San Diego, CA, April 2003.
