CS 146 Lecture 7
Recursion

• Prof. S.M. Lee
• Department of Computer Science

2
(No Transcript)
3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
Recursion

• Recursion is more than just a programming
  technique. It has two other uses in computer
  science and software engineering, namely
• as a way of describing, defining, or
  specifying things.
• as a way of designing solutions to problems
  (divide and conquer).

9
Mathematical Examples

• factorial function
• factorial(0) 1
• factorial(n) n factorial(n-1) for ngt0
• Let's compute factorial(3). factorial(3)
• 3 factorial(2)
• 3 ( 2 factorial(1) )
• 3 ( 2 ( 1 factorial(0) ))
• 3 ( 2 ( 1 1 ) ))
  6

10
Fibonacci function

• fibonacci(0) 1
• fibonacci(1) 1
• fibonacci(n) fibonacci(n-1)
  fibonacci(n-2) for ngt1
• This definition is a little different than the
  previous ones because It has two base cases, not
  just one in fact, you can have as many as you
  like.
• In the recursive case, there are two recursive
  calls, not just one. There can be as many as you
  like.

11
Recursion

• Recursion can be seen as building objects from
  objects that have set definitions. Recursion can
  also be seen in the opposite direction as objects
  that are defined from smaller and smaller parts.
  Recursion is a different concept of
  circularity.(Dr. Britt, Computing Concepts
  Magazine, March 97, pg.78)

12

Finding the powers of numbers

• Suppose that we have a series of functions for
  finding the power of a number x.
• pow0(x) 1
• pow1(x) x x pow0(x)
• pow2(x) x x
• x pow1(x)
• pow3(x) x x x
• x pow2(x)

• We can turn this into something more usable by
  creating a variable for the power and making the
  pattern explicit
• pow(0,x) 1
• pow(n,x)
• x pow(n-1,x)

13
For instance

• 23 2 22 2 4 8
• 22 2 21 2 2 4
• 21 2 20 2 1
  2
• 20
  1

14
Almost all programminglanguages allow recursive
functions calls.

• That is they allow a function to call itself. And
  some languages allow recursive
• definitions of data structures. This means
  we can directly implement the recursive
  definitions and recursive algorithms that we have
  just been discussing.
• For example, the definition of the factorial
  function
• factorial(0) 1

• factorial(n) n
• factorial(n-1) for n gt 0 .
• can be written in C without the slightest change

• int factorial(int n)
• if (n 0) return 1
• else return n factorial(n-1)

15
Basic Recursion

• What we see is that if we have a base case, and
  if our recursive calls make progress toward
  reaching the base case, then eventually we
  terminate. We thus have our first two fundamental
  rules of recursion

16
Basic Recursion

• 1. Base cases
• Always have at least one case that can be solved
  without using recursion.
• 2. Make progress
• Any recursive call must make progress toward a
  base case.

17
Euclid's Algorithm

• In Euclid's 7th book in the Elements series
  (written about 300BC), he gives an algorithm to
  calculate the highest common factor (largest
  common divisor) of two numbers x and y where (x lt
  y). This can be stated as
• 1.Divide y by x with remainder r.
• 2.Replace y by x, and x with r.
• 3.Repeat step 1 until r is zero.
• When this algorithm terminates, y is the highest
  common factor.

18
GCF(34,017 and 16,966).

• Euclid's algorithm works as follows
• 34,017/16,966 produces a remainder 85
• 16,966/85 produces a remainder 51
• 85/51 produces a remainder 34
• 51/34 produces a remainder 17
• 34/17 produces a remainder 0
• and the highest common factor of 34,017 and
  16,966 is 17.

19
Euclid's algorithm involves several elements

• simple arithmetic operations (calculating the
  remainder after division),
• comparison of a number against 0 (test), and
• the ability to repeatedly execute the same set
  of instructions (loop).
• and any computer programming language has these
  basic elements. The design of an algorithm to
  solve a given problem is the motivation for a lot
  of research in the field of computer science.

20
Euclid's Algorithm

• Euclid's Algorithm determines the greatest common
  divisor of two natural numbers a, b. That is, the
  largest natural number d such that d a and d
  b.

• GCD(33,21)3
• 33 121 12
• 21 112 9
• 12 19 3
• 9 33

21
The main benefits of using recursion as a
programming technique are these

• invariably recursive functions are clearer,
  simpler, shorter, and easier to understand than
  their non-recursive counterparts.
• the program directly reflects the abstract
  solution strategy (algorithm).
• From a practical software engineering point of
  view these are important benefits, greatly
  enhancing the cost of maintaining the software.

22
Main disadvantage of programming recursively

• The main disadvantage of programming recursively
  is that, while it makes it easier to write simple
  and elegant programs, it also makes it easier to
  write inefficient ones.
• when we use recursion to solve problems we are
  interested exclusively with correctness, and not
  at all with efficiency. Consequently, our simple,
  elegant recursive algorithms may be inherently
  inefficient.

23
Consider the following program for computing the
fibonacci function.

• int s1, s2
• int fibonacci (int n)
• if (n 0) return 1
• else if (n 1) return 1
• else
• s1 fibonacci(n-1)
• s2 fibonacci(n-2)
• return s1 s2

24
The main thing to note here is that the variables
that will hold the intermediate results, S1 and
S2, have been declared as globalvariables

• . This is a mistake. Although the function looks
  just fine, its correctness crucially depends on
  having local variables for
• storing all the intermediate results. As
  shown, it will not correctly compute the
  fibonacci function for n4 or larger. However, if
  we move the declaration of s1 and s2 inside the
  function, it works perfectly.

• This sort of bug is very hard to find, and bugs
  like this are almost certain to arise whenever
  you use global variables to storeintermediate
  results of a recursive function.

25

• Recursion is based upon calling the same function
  over and over, whereas iteration simply jumps
  back' to the beginning of the loop. A function
  call is often more expensive than a jump.

26
The overheadsthat may be associated with a
function call are

• Space Every invocation of a function call may
  require space for parameters and local variables,
  and for an indication of where to return when
  the function is finished. Typically this space
  (allocation record) is allocated on the stack and
  is released automatically when the function
  returns. Thus, a recursive algorithm may need
  space proportional to the number of nested calls
  to the same function.

27

• Time The operations involved in calling a
  function - allocating, and later releasing, local
  memory, copying values into the local
• memory for the parameters, branching
  to/returning from the function - all contribute
  to the time overhead.

28

• If a function has very large local memory
  requirements, it would be very costly to program
  it recursively. But even if there is
• very little overhead in a single function
  call, recursive functions often call themselves
  many many times, which can magnify a
• small individual overhead into a very large
  cumulative overhead.

29

• int factorial(int n)
• if (n 0) return 1
• else return n factorial(n-1)
• There is very little overhead in calling this
  function, as it has only one word of local
  memory, for the parameter n. However, when we try
  to compute factorial(20), there will end up being
  21 words of memory allocated - one for each
  invocation of the function

30

• factorial(20) -- allocate 1 word of memory,
• call factorial(19) -- allocate 1 word of
  memory,
• call factorial(18) -- allocate 1 word of
  memory,
• .
• .
• .
• call factorial(2) -- allocate
  1 word of memory,
• call factorial(1) --
  allocate 1 word of memory,
• call factorial(0) --
  allocate 1 word of memory,
• at this point 21 words of memory

31

• and 21 activation records have been allocated.
• return 1. --
  release 1 word of memory.
• return 11. -- release 1
  word of memory.
• return 21. -- release 1
  word of memory.

32
Iteration as a special case of recursion

• The first insight is that iteration is a special
  case of recursion.
• void do_loop () do ... while (e)
• is equivalent to
• void do_loop () ... if (e) do_loop()

• A compiler can recognize instances of this form
  of recursion and turn them into loops or simple
  jumps.

• E.g.
• void do_loop () start ... if (e) goto
  start
• Notice that this optimization also removes the
  space overhead associated with function calls.

33

• Most recursive algorithms can be translated, by a
  fairly mechanical procedure, into iterative
  algorithms. Sometimes this is very
  straightforward - for example, most compilers
  detect a special form of recursion, called tail
  recursion, and automatically translate into
  iteration without your knowing. Sometimes, the
  translation is more involved for example, it
  might require introducing an explicit stack with
  which to fake' the effect of recursive calls.

34
Non-recursive version of Power function

• FUNCTION PowerNR (Base real Exponent
  integer) real
• Preconditions Exponent gt 0
• Accepts Base and exponent values
• Returns Base to the Exponent power
• VAR Count integer Counts number of times
  BAse is multiplied
• Product real

• Holds the answer as it is being calculated
• BEGIN
• Product 1
• FOR Count 1 TO Exponent DO
• Product Product Base
• PowerNR Product
• END PowerNR

35

• We have seen one form of circularity already in
  our classes, with a For loop.
• Int x
• For (x0 xlt10 x)
• coutltltx

36
Problems solving used loops

• In a for loop, we have a set loop structure which
  controls the length of the repetition. Many
  problems solved using loops may be solved using a
  recursion. In recursion, problems are defined in
  terms of smaller versions of themselves.

37
Power function

• There are recursive definitions for many
  mathematical problems
• The function Power (used to raise the number y to
  the xth power). Assume x is a non-negative
  integer
• Yx 1 if x is 0 otherwise, YY(x-1)

38
Power Function

• 23 222 2 4 8
• 22 221 2 2 4
• 21 220 2 1 2
• 20 1

39
Factorial Function

• The factorial function has a natural recursive
  definition
• n! 1, if n 0 or if n 1 otherwise, n!
  n (n - 1)!

40

• For example
• 5! 54! 524
• 4! 43! 46
• 3! 32! 32
• 2! 21! 21
• 1! 1

41
Excessive Recursion

• When a program runs too deep
• When a simple loop runs more efficiently
• Fibonacci sequence

42
Ackermanns Function

• one of the fastest growing non-primitive
  recursive functions. Faster growing than any
  primitive recursive function.
• It grows from 0 to 265546 in a few breaths.

43
Basis for Ackermanns

• If A(0, n)n1, by definition
• If A(m, 0)A(m-1, 1)
• else, A(m, n)A(m-1, A(m, n-1))
• until A(0, A(1, A(m-2, n-1)))back to definition

44
Example

• A(2, 2)A(1, A(2, 1))A(0, A(1, A(2, 1)))
• A(1, A(2, 1))1A(0, A(1, A(2, 0)))1
• A(1, A(1, 1))2A(0, A(1, A(1, 0)))
• A(1, A(0, 1))3A(0, A(0, 0))57!!!

45
Shortcuts

• If A(0, n)n1
• If A(1, n)n2
• If A(2, n)2n3
• If A(3, n)2n3
• If A(4, n)2(n3)2
• If A(5, n)TOO MUCH!!!!!

46

• A(4, 1)13
• A(4, 2)65533
• A(4, 3)265536-3
• A(4, 4)2(2(65536)-3)

47

• Ackermanns function is a form of
  meta-multiplication.Dr. Forb.
• abadding the operand
• abadding the operand a to itself b times
• abmultiplying the operand a by itself b times
• a_at_bab, b timesa_at__at_ba_at_b, b times
