Presentatie Francis Cave ACAP

1
gtgtgtgt Communicating with crawlersWhat ACAP has
to offer
gtgtgtgt
Francis Cave, EDItEUR ACAP Technical Project
Manager May 2008
WEBCONTENT Te Mooi Om Weg Te GevenNUV, Amsterdam
2
Communicating with crawlersWhat ACAP has to
offer

• What is ACAP (Version 1.0)?
• What has been the experience so far?
• What publishers should do now...

3
The ACAP Technical FrameworkACAP Version 1.0

• What it is
• a toolkit to enable communication of content
  access and usage policies
• adopting and building upon existing standards
• rooted in the requirements of real use cases
• a proof of concept
• What it isnt
• at this stage ACAP is not a formal standard
• a technical enforcement mechanism

4
The ACAP Technical FrameworkACAP Version 1.0

• What is it?
• Protocols for machine-to-machine messaging
• using a common vocabulary of access and usage
  terminology
• Guidance on methods of communication and access
  control
• Software tools to support implementation

5
The ACAP Technical FrameworkACAP Version 1.0

• What kinds of protocols?
• business layer protocols
• machines already know how to talk to one
  another
• physical layer PPP, ATM,
• network layer TCP/IP
• application layer HTTP, HTTPS, SMTP, FTP
• business layer RSS, ebXML, EDIINT, SOAP, web
  services,
• they just dont know what to say in the business
  of communicating access and usage policies

6
The ACAP Technical FrameworkACAP Version 1.0

• We need to tell the machines what to say to one
  another
• we need a common vocabulary
• so they knows what to say
• and how to interpret it
• and tell them how to say it
• using whatever protocols they already use to
  talk to one another

7
The ACAP Technical FrameworkACAP Version 1.0

• But machines arent going to do this on their
  own
• we need to provide guidance on how to implement
  the protocols
• we need to provide tools to support implementation

8
The ACAP Technical FrameworkACAP Version 1.0

• How has it been developed?
• We started with a set of real business use cases
• Nine publishers looking for ways of communicating
  access and use policies for their online content
• A national archive looking for ways of finding
  out what they were allowed to do with the content
  that they are preserving for posterity
• A search engine looking for ways to include more
  high-quality content in their index

9
The ACAP Technical FrameworkACAP Version 1.0

• What does ACAP Version 1.0 include?
• Extensions to the Robots Exclusion Protocol (REP)
• Part 1 specifies extensions to the robots.txt
  format
• enables policies to be expressed for an entire
  website
• leverages the established protocol for web
  server-crawler communication
• the existing format is used on millions of
  websites and understood by hundreds of crawlers
• Part 2 specifies extensions to the Robots META
  Tags format
• enables policies to be expressed within
  individual HTML pages
• existing format understood by major search
  engines
• Dictionary of access and usage terminology
• robots.txt conversion tool

10
The ACAP Technical FrameworkACAP Version 1.0

• Why does REP need to be extended?
• conventional REP has only a very limited
  vocabulary
• even if we include non-standard extensions that
  not every search engine has implemented
• conventional REP is inconsistently interpreted
• e.g. Disallow is interpreted differently means
  different things to different crawlers
• dont crawl?
• dont index?

11
The ACAP Technical FrameworkACAP Version 1.0

• ACAP Version 1.0 has been tested by four
  publishers against their priority use cases
• De Persgroep major Flemish news publisher
• Media 24 global news / media publisher based in
  South Africa
• Macmillan online book content hosting service
• Reed Elsevier scientific and business
  information publisher
• all the tested use cases concern text resources
• current technical work includes extension of ACAP
  Version 1.0 to enable communication of policies
  relating specifically to non-text resource such
  as images and video
• ACAP Version 1.0 has been implemented in a test
  crawler by search engine operator Exalead

12
The ACAP Technical FrameworkACAP Version 1.0

• Tool for converting existing robots.txt files
• converts conventional robots.txt files so that
  existing policies are expressed using ACAP
  terminology
• User-agent ? ACAP-crawler
• Disallow ? ACAP-disallow-crawl
• Allow ? ACAP-allow-crawl
• is implemented in perl
• can be used from the ACAP website
• http//www.the-acap.org/convert-robots-txt-to-acap
  .php

13
The ACAP Technical FrameworkACAP Version 1.0

• Guidance on crawler authentication
• How to identify crawler names and IP addresses by
  analysing web server access log files
• How to configure a server so that you can deliver
  different robots.txt files to different
  crawlers
• examples are based upon the Apache web server
• ACAP Version 1.0 Implementation Guide
• Step-by-step guide on how to make full use of the
  extensions to REP proposed in ACAP Version 1.0
• Illustrated with many examples

14
The ACAP Technical FrameworkACAP Version 1.0

• Review of test results
• We have tested ACAP Version 1.0 REP extensions in
  a range of use cases
• for most of the tested use cases there are no
  unresolved issues
• but protected content use cases
• have been particularly challenging to implement
• have highlighted need for further work on some
  terminology
• ACAP Version 1.0 is ready to implement
• for use cases in unprotected online content
  delivery
• for some use cases in protected online content
  delivery
• but ACAP needs further development
• all specifications will continue to be revised
  and extended

15
The ACAP Technical FrameworkFuture plans

• To be added in future
• corrections and clarifications of a few points in
  ACAP Version 1.0
• additional vocabulary required for expressing
  policies specific to
• the creation and use of web archives
• the presentation of images and other media
  content
• the communication of policies associated with
  page fragments
• mechanisms for embedding ACAP policies in PDF and
  media resources.
• an XML format for policy expression
• based upon ONIX for Licensing Terms developed by
  EDItEUR
• required for news and web syndication use cases

16
The ACAP Technical FrameworkACAP Version 1.0

• Experience to date
• ACAP Version 1.0 works
• it enables a richer form of expression of
  policies than is possible using conventional REP
  ...
• it doesnt interfere with current crawler
  activity ...
• ... but it only goes so far.
• ACAP Version 1.0 needs to be extended
• ACAP Version 1.1 (June/July 2008)

17
The ACAP Technical FrameworkACAP Version 1.0

• What should publishers do now?
• ACAP Version 1.0 needs to be implemented!
• use the conversion tool to convert existing
  robots.txt files to use ACAP forms of
  expression
• use the Implementation Guide to refine policy
  expressions
• consider creating crawler-specific policies in
  separate robots.txt files
• give us you feedback, to help us improve future
  versions of ACAP

18
The ACAP Technical Framework
gtgtgtgt Thank you! Questions? francis_at_franciscave.
com
gtgtgtgt
Francis Cave, EDItEUR ACAP Technical Project
Manager May 2008
WEBCONTENT Te Mooi Om Weg Te GevenNUV, Amsterdam
