Title: Web Technology


1
Chapter 3
  • Web Technology

2
Web Publishing
  • Static documents
  • HTML, ASCII text, Postscript, PDF
  • GIF, JPEG, MOV, Quicktime, AVI
  • AU, WAV, MP3, RealAudio
  • Dynamic documents
  • executable content
  • Java, Javascript, Active-X, Dynamic HTML
  • Variable documents
  • Dynamically-generated (on-the-fly)
  • CGI, FastCGI, JSP, PHP

3
HyperText Markup Language
  • Document structure description
  • (sub-)sections
  • headings
  • tables
  • No (?) layout information
  • style sheets
  • font mapping
  • Defined in SGML / XML (XHTML)
  • Document Type Definition (DTD)

4
HTML Basic Elements
  • ltHTMLgt
  • ltHEADgt
  • ltTITLEgtHello Worldlt/HTMLgt
  • lt/HEADgt
  • ltBODYgt
  • Oh, what a beautiful morning....
  • lt/BODYgt
  • lt/HTMLgt

5
HTML Elements
  • physical text styles
  • logical test styles
  • test segmentation
  • tables
  • inline pictures
  • anchors/links
  • forms
  • specials
  • image maps (client/server)
  • background pic/audio, marquees

6
HTML Development
  • Browser war (NS Navigator vs. MSIE)
  • World Wide Web Consortium (W3C)
  • rendering
  • internationalization
  • forms
  • active content
  • object models

7
HTML History
  • HTML 2.0
  • 1st version conforming to SGML
  • Core HTML (lists, forms, headings, fonts, image
    maps, ...)
  • HTML 3.2 (no HTML 3.0 HTML 3.1)
  • many elements get additional attributes
  • font sizes, font faces, colors
  • form-based file upload
  • client-side image maps
  • tables, APPLET tag
  • STYLE and SCRIPT tags (placeholders, no exact
    mechanisms)

8
HTML 3.2
  • Script Tags
  • JavaScript, VBScript, Jscript
  • eventless
  • APPLET tag
  • Styles (CSS)
  • ALIGNs generalized
  • client-side image-maps
  • FONT
  • formulas
  • FORM based file upload

9
HTML 4.0
  • accessability
  • labels, legend, clusters
  • iterators, access keys
  • character encodings, language codes (lang)
  • bidrectional text (dir)
  • incremental rendering
  • tables, images
  • objects (nested)
  • scripts and events
  • frames

10
HTML 4.0 (Frames)
  • TARGETs
  • ltA href"slide2.html" target"dynamic"gtslide
    2.lt/Agt
  • IFRAMEs
  • ltIFRAME src"foo.html" width"400" height"500"
    scrolling"auto" frameborder"1"gt
  • Your user agent does not support frames
  • lt/IFRAMEgt

11
HTML 4.0 (Scripts)
  • client-side execution at
  • loading
  • user input (focus, pointer movement)
  • language selection
  • ltMETA http-equiv"Content-Script-Type"
    content"type"gt
  • ltSCRIPT type"text/vbscript" src"http//someplace
    .com/progs/vbcalc"gt
  • lt/SCRIPTgt
  • evaluation order, object modification (DOM)

12
HTML 4.0 (Events)
  • Loading
  • onload, unload
  • Pointer
  • onmousemove, onmousmoveover, ...
  • Keyboard
  • onkeypress, onkeydown, ...
  • Form handling
  • onsubmit, onreset, onselect, onchange
  • ltINPUT NAME"userName" onblur"validUserName(this.
    value)"gt

13
HTML 4.01
  • Common attributes for many elements Id, Title,
    Style, Class
  • Improved tables (Thead, Tbody, Tfoot, column
    handling, formatting), Incremental rendering of
    tables
  • Improved forms
  • STYLE element now encloses style sheet
    instructions (CSS)
  • Style sheets separation of content and styles
    (CSS)

14
HTML 4.01
  • Frames, Embedded documents (IFRAME)
  • APPLET element deprecated (OBJECT)
  • Intrinsic events (onclick, ondblclick,
    onmouseover, onmouseout, ...)
  • OBJECT element (IMAGE, APPLET, IFRAME)
  • SCRIPT element (client-side scripting -
    JavaScript, VBScript, ...)

15
OBJECT Element Examples
16
More OBJECT examples
  • ltOBJECT data"canyon.png" type"image/png"gt
  • This is a ltEMgtcloseuplt/EMgt of the Grand
    Canyon.
  • lt/OBJECTgt
  • ltOBJECT classid"http//www.miamachina.it/clock.py
    "gt
  • An animated clock.
  • lt/OBJECTgt
  • ltOBJECT data"embed_me.html"gt
  • Warning embed_me.html could not be included.
  • lt/OBJECTgt

17
Client-side Scripting 1
  • Languages JavaScript, VBScript, Python, Tcl, ...
  • Security ?

18
Client-side Scripting 2
19
Client-side Scripting 3
20
Cascading Style Sheets
  • Separation of content (HTML, XML documents) and
    presentation style (CSS)
  • simplified Web authoring
  • easier Web site maintenance
  • CSS vs. XSL
  • CSS was defined earlier
  • XSL is still a draft while CSS is already
    supported by browsers
  • XSL is more powerful gt too complex for many
    users/applications

21
Style and HTML
22
External CSS and Cascasding
23
Without Style
24
Better do it stylish !
25
CSS by Example (1/3)
26
CSS by Example (2/3)
27
CSS by Example (3/3)
28
Extensible Markup Language
  • XML (1998) is an application of SGML
  • Standard Generalized Markup Language (1986)
    ISO8879
  • influenced by HTML (SGML Document Type
    Definifion)
  • Structure description language
  • Meta-language language to describe other
    languages
  • Tags enclose identifiable parts of a document
  • markup (type-setting systems)

29
XML Example
  • ltwarninggt
  • ltparagtThis substance is ltemphgthazardouslt/emphgt to
    healthlt/paragt
  • ltparagtSee procedure 12A.7 for information on
    protective clothing.lt/paragt
  • ltimage .../gt
  • lt/warninggt

30
XML Documents
logical structure division of documents into name units and sub-units unit element physical structure components of the document can be named and stored separately component entity

Document
Document
Unit
Sub-unit
31
Document Type Definition
  • DTD defines the elements allowed
  • A parser compares the DTD rules against a given
    XML document gt validation
  • XML DTDs can be applied for data-type definitions
    (XML-RPC), data exchange (EDI, push, RDBMS), etc.

32
XML Document Presentation
  • Style sheets specify output format
  • 1 XML document, n alternative style sheets
    depending on audience, media, etc.

WARNING
This substance is hazardous to health See
procedure 12A.7 for information on protective
clothing.
33
XML by Example (1/2)
34
XML by Example (2/2)
35
Extensible Stylesheet Language
  • XSL is a language for expressing stylesheets and
    consists of
  • a language for transforming XML documents (XSLT)
  • an XML vocabulary for specifying formatting
    semantics (Formatting Objects DTD - FO DTD)
  • CSS lt XSL lt DSSSL (SGML's Document Style
    Semantics and Specification Language)
  • Style sheets
  • target specific elements gt closely related with
    DTDs

36
XSL and XSLT Processing
XSL processor
XSLT stylesheet
XSLT processor
source DTD
document
new document
FO DTD
37
Document Reengineering
  • analysis
  • data sources, responsibilities and update
    dynamics
  • data model
  • EER (extended entity-relationship model)
  • mapping logical -gt physical
  • reverse association how to link back
  • forward association how to link forward

38
HTML Code Creation
  • Editors
  • Tags, Syntax
  • Validators
  • Halsoft, htmllint, ....
  • Converters
  • which HTML? DTD as parameter
  • how to map the document structure into HTML?
  • special symbols? mathematical formulas?
  • what happens with hyperlinks in original document?

39
HTML Creation (cont'd)
  • Development Environments
  • versioning
  • staging
  • TODO database
  • link consistency
  • upload to server
  • integration of functionality
  • CGIs
  • backend applications, databases
  • client-side scripting

40
Webserver State maintenance
  • HTTP interactions are "isolated", i.e., HTTP does
    not include means to hand over state information
    between interactions -gt difficult
  • Advanced web applications, e.g. shopping basket,
    require that state can be shared between
    interactions (between web client and web server)
  • External apps have their own state space

41
WWW Gateways
HTTP
Web browser
Web server
CGI (HTTP)
WWW
CGI gateway
Gateway-specific protocol
non WWW
Application
42
Stateful Gateways
  • A permanently running gateway process keeps up a
    connection with the external application and
    serves successive HTTP requests, i.e. the gateway
    maintains the session?s state.
  • Problem state bookkeeping
  • client caches
  • back button
  • interrupted requests (recover ?)
  • time-out for follow-up requests (bound resources
    ?)
  • Example DBs (expensive login)

43
Stateless Gateways
  • Gateway or external application generate
    state-information which is stored at the client
    and sent with every request.
  • State can be stored in
  • URLs
  • hidden fields
  • Cookies
  • Solve state consistency problem ?

44
State in URLs / Hidden Fields
  • State information can become large
  • User can change state information (reservation ?)
  • Sessions may have to be replayed until the state
    for the next step is reached
  • Unreadable URLs are no solution
  • Passwords ?

45
Cookies
  • A cookie is a small data structure which holds
    name, value pairs which is sent back and forth
    between web client and web server for certain
    URLs
  • Several incompatible "standards"
  • original standard by Netscape (Set-Cookie)
  • RFC 2109 (Set-Cookie)
  • New Internet Draft (Set-Cookie2)

46
Cookie example
User shops around and gathers 2 items in his
shopping basket (server -gt client)
User decides to buy the 2 items and
selects http//www.supershop.com/cgi-bin/order/buy
.pl (client -gt server)
47
More about Cookies
  • Cookies can enhance or break privacy
  • tracking vs. no user database
  • Cookies are kept in memory
  • Persistent cookies cookies.txt file

creator (domain)
path
expiration
name
value
access for all hosts in domain ?
require secure connection ?
48
Server-side Includes
  • .shtml files are parsed for special commands
  • executed before the file is sent to the client

49
SSI Syntax
Main elements
exec execute a shell or CGI script
fsize print the size of a given file/URL
flastmod print last modification date
include insert contents of another document
set set the value of a variable
Variables (additionally to CGI environment
variables) DATE_GMT, DOCUMENT_NAME,
DOCUMENT_URI, LAST_MODIFIED
Flow control lt!--if expr"test
condition" --gt lt!--elif expr"test
condition" --gt lt!--else --gt
lt!--endif --gt
50
SSI problems
  • Performance
  • parsing
  • command execution
  • Security
  • exec command, etc.
  • IncludesNoExec
  • Unreadable -gt maintenance ?

51
SSI example
52
PHP
  • HTML-embedded scripting language
  • Syntax similar to C/Perl/Java
  • Powerful features
  • PHP scripts can replace CGIs
  • Powerful support for many databases
  • Support for HTTP, IMAP, SNMP, NNTP, POP3
  • Access to raw sockets
  • Security ?

53
PHP DB access example
54
Simple PHP example
55
JavaServer Pages
  • JSP "Java-based ASP"
  • Dynamic scripting
  • JSP pages can contain
  • HTML/XML
  • Java scriplets
  • special tags
  • JSP engine required

56
JSP example
57
Common Gateway Interface
  • Standard for interfacing external applications
    with web servers (databases, etc.)
  • CGI programs execute at the web server and
    produce output dynamically ("HTML document does
    not exist in advance")
  • Language-independent CGI programs can be written
    in any programming language (Perl, C, Java, Tcl,
    ...)

58
Simple CGI Example (1/3)
  • GET
  • CGI script is started by the web server
  • gets the parameters as environment variable
    QUERY_STRING (URL encoded)
  • QUERY_STRING"par1hellopar2world"

59
Simple CGI Example (2/3)
  • POST
  • CGI script is started by the web server and gets
    the parameters via standard input (URL encoded)
  • CGI script does not get EOF but must check the
    environment variable CONTENT_LENGTH how much to
    read from stdin

60
Simple CGI Example (3/3)
  • MyScript.pl print all set environment variables

61
FastCGI
  • Migrating of CGI programs is very easy
  • Performance
  • persistent (multi-threaded) processes
  • after finishing a request the processes continue
    to run and wait for new requests
  • Support for distributed computing
  • FastCGI programs can run remotely
  • load distribution

62
CGI vs. APIs
  • CGI
  • simple
  • language independent
  • isolated processes
  • open standard
  • architecture independent
  • single/multi-threaded
  • single/multi-tier

63
Servlets
  • Modules (pieces of code) which run on
    Java-enabled web servers
  • Servlet engine execution environment
  • Java Servlet API Specification (SUN)
  • Java package javax.servlet

Servlet engine
Load
Servlet code
Servlet engine
Client
Servlet code
Client
Servlet engine
Unload
Servlet code
64
Servlets vs. CGI
  • Portable code
  • Useful features (sessions, cookies, ...)
  • Multi-threading
  • Faster
  • does not run as a separate process
  • stays in memory between requests
  • a single servlet instance answer request
    concurrently
  • Sandbox for servlets possible

65
Apache Jserv Servlet Engine
  • Java Servlet API 2.0 compliant
  • Multi-threaded, separated from web server
  • Integrated load balancing features
  • Smart redirection of requests
  • AJP protocol allows creation of complex
    distributed applications
  • MD5 based connection authentication and IP
    filtering
Write a Comment
User Comments (0)
About PowerShow.com
