Multithreaded Microprocessors and Multiprocessor SoCs

1
Multithreaded Microprocessorsand Multiprocessor
SoCs

• Sam Sandbote
• CSE 8383 Advanced Computer Architecture
• February 23, 2006

2
Topics

1. Technical Drivers
2. Simultaneous Multithreading
3. Alternative Perspectives
4. What is an SoC, Anyway?

3
Topics

1. Technical Drivers
2. Simultaneous Multithreading
3. Alternative Perspectives
4. What is an SoC, Anyway?

4
Why Consider MP on Chip?

• The industry does not fundamentally change unless
  it is forced against a wall
• We would prefer to scale as we always have, if we
  could
• Most programmers are not skilled in the art of
  parallel programming
• Confluence of 3 trends has forced the industry to
  go MP
• Architectural tricks to speed up single programs
  have limits
• Locality of reference (cache size)
• ILP (superscalar issue width, window size)
• Building faster clocked logic is getting
  exponentially harder
• Process tech still shrinking designs must use
  that area!

5
Topics

1. Technical Drivers
2. Simultaneous Multithreading
3. Alternative Perspectives
4. What is an SoC, Anyway?

6
Simultaneous MT

• Concept multiplex the execution of 2 or more
  threads
• Each maintains its own architectural register
  state
• PC, R0-Rn, SP, CC, etc these are maintained
  per-thread
• What happens when we mix two instruction streams?
• They are guaranteed not to have any data
  dependencies between them
• Even for memory addresses!
• Only register dependencies are considered by
  out-of-order machines
• Conceptually, available ILP is doubled
• We have enough unrelated instructions from a
  second thread to fill in pipeline bubbles left by
  the first

7
Multithreaded Usage Models

• Coarse Application-Level Parallelism
• Each context corresponds to a process under OS
  control
• Make the OS believe two processors exist
• Still hard to implement Intel took 2 years to
  get the bugs out of Pentium 4 HT
• Fine Native Multithreaded ISA
• Constructs fork, join, quit are machine
  instructions
• What happens when we fork more threads than
  hardware supports?
• Ultra-Fine Well, basically same as ILP

8
What Can Be Shared, at What Cost?
Resource Impact on Single-Thread Performance Notes
Fetch Bandwidth High
Instruction Cache Medium Must support hit-under-miss
Branch Predictor State Medium
Exec Units None Small and cheap to replicate
Data Cache Very High Must support hit-under-miss
9
Athlon64 Die Photo
10
Proliferation of Context Arbitration

• Sharing implies
• Programmer declares a QoS for a thread upon its
  startup
• This QoS must be distributed
• Arbitration must exist for
• Fetch bandwidth
• Dispatch and/or Issue
• Cache and/or Branch Predictor Utilization
• This is a very good area for research
• External Access BW/latency
• Additional Pipeline Cycles for Arbitration
  Introduced
• This is BAD!

11
Why Simultaneous MT, Then?

• Most efficient in terms of aggregate IPC
• Consider 4 threads each with a typical
  instruction mix
• 20 loads, 10 stores
• 20 branching
• 50 in-CPU instructions ADD, MOV, etc.
• Using 4 superscalar speculative processors
• 4 processors, each IPC around 0.8
• Using a 4-way multithreaded processors
• 1 (larger) processor with IPC 1.4 or better

12
Topics

1. Technical Drivers
2. Simultaneous Multithreading
3. Alternative Perspectives
4. What is an SoC, Anyway?

13
Alternative The Fast Context Switch

• Argument Arbitration does not add value and
  detracts from performance
• Only fill in the giant bubbles when a cache
  misses or when a process is swapped out.
• Support register state for two or more processes
• OS may see that 2 processes may be running at the
  same time
• No arbitration at all - only executing one at a
  time
• These are the first commercial attempts at
  multithreading, because verification is much
  easier

14
Alternative Multiprocessor-on-Chip

• Argument Benefit of resource sharing does not
  outweigh cost of performance degradation on a
  single thread
• CTO of Intel plans to step-and-repeat a smaller,
  simpler core such as Centrino
• Each processor will have independent L1 D and I
• May or may not share very large central L2
• DRAM controller has long since been integrated
• For the foreseeable future the model will be
  tight SMP
• Processors connected to DRAM controller via their
  old front side bus, which is morphed into a
  cache-coherent switch fabric.

15
Mainstream CPU of 2008/2009 (45nm)
16
Alternative Heterogeneous MP

• Argument Most systems can benefit from having
  several different types of processors.
• TI wireless OMAP chips are necessarily
  heterogeneous. Multiple tasks are very
  different
• QoS requirements
• MIPS requirements
• Memory bandwidth and access patterns
• Word width (some custom hardware for deframing)
• and some analog sugar sprinkles, too

17
Topics

1. Technical Drivers
2. Simultaneous Multithreading
3. Alternative Perspectives
4. What is an SoC, Anyway?

18
BYOD Bring Your Own Definition

• Embedded memory?
• Embedded processor?
• Just a big ASIC?
• Just another buzz-word
• SSI
• MSI
• LSI
• VLSI
• ULSI were tired, here. Lets just call them
  SoCs.
