CSCE 522

1

• CSCE 522
• Firewalls

2
Readings

• Pfleeger 7.4

3
Traffic Control Firewall

• Brick wall placed between apartments to prevent
  the spread of fire from one apartment to the next
• Single, narrow checkpoint placed between two or
  more networks where security and audit can be
  imposed on traffic which passes through it

4
Firewall
Private Network
security wall between private (protected) network
and outside word
Firewall
External Network
5
Firewall Objectives

• Keep intruders, malicious code and unwanted
  traffic or information out
• Keep proprietary and sensitive information in

Proprietary data
External attacks
6
Without firewalls, nodes

• Are exposed to insecure services
• Are exposed to probes and attacks from outside
• Can be defenseless against new attacks
• Network security totally relies on host security
  and all hosts must communicate to achieve high
  level of security almost impossible

7
Network Address Translation (NAT)
Organization uses private IP addresses on its
network ? increase address space Send packet to
Internet convert private IP address to globally
assigned IP address Receive packer from Internet
globally assigned IP addresses converted to
private IP addresses Firewalls may Establish
connections on behalf of the client Support NAT
8
Common firewall features

• Routing information about the private network
  can't be observed from outside
• traceroute and ping -o can't see' internal hosts

• Users wishing to log on to an internal host must
  first log onto a firewall machine (or else start
  behind' the firewall).

9
Trade-Off between accessibility and Security
Service Access Policy
Accessibility
Security
10
Firewall Advantages

• Protection for vulnerable services
• Controlled access to site systems
• Concentrated security
• Enhanced Privacy
• Logging and statistics on network use, misuse
• Policy enforcement

11
Protection For Vulnerable Services

• Filtering inherently insecure services gt fewer
  risks. For example,
• NFS services
• SNMP
• TFTP
• NetBIOS

12
Controlled Access

• A site could prevent outside access to its hosts
  except for special cases (e.g., mail server).
• Do not give access to a host that does not
  require access
• Some hosts can be reached from outside, some can
  not.
• Some hosts can reach outside, some can not.

13
Concentrated Security

• Firewall less expensive than securing all hosts
• All or most modified software and additional
  security software on firewall only (no need to
  distribute on many hosts)
• Other network security (e.g., Kerberos) involves
  modification at each host system.

14
Enhanced Privacy

• Even innocuous information may contain clues that
  can be used by attackers
• E.g., finger
• information about the last login time, when
  e-mail was read, etc.
• Infer how often the system is used, active
  users, whether system can be attacked without
  drawing attention
• SNMP picture of your network anyone?

15
Logging and Statistics on Network Use, Misuse

• If all access to and from the Internet passes
  through the firewall, the firewall can
  theoretically log accesses and provide statistics
  about system usage
• Alarm can be added to indicate suspicious
  activity, probes and attacks double duty as IDS
  on smaller networks

16
Policy enforcement

• Means for implementing and enforcing a network
  access policy
• Access control for users and services
• Cant replace a good education/awareness program,
  however
• Knowledgeable users could tunnel traffic to
  bypass policy enforcement on a firewall

17
Firewall Disadvantages

• Restricted access to desirable services
• Large potential for back doors
• No protection from insider attacks
• No protection against data-driven attacks
• Cannot protect against newly discovered attacks
  policy/situation dependent
• Large learning curve

18
Restricted Access to Desirable Services

• May block services that users want
• E.g., telnet, ftp, X windows, NFS, etc.
• Need well-balanced security policy
• Similar problems would occur with host access
  control
• Network topology may not fit the firewall design
• E.g., using insecure services across major
  gateways
• Need to investigate other solutions (e.g.,
  Kerberos)

19
Back Doors

• Firewalls DO NOT protect against back doors into
  the site
• e.g., if unrestricted modem access is still
  permitted into a site the attacker could jump
  around the firewall
• Legacy network topology in large networks

20
Little Protection from Insider Attacks

• Generally does not provide protection from
  insider threats
• Sneaker Net - insider may copy data onto tape or
  print it and take it out of the facility

21
Data-Driven Attacks

• Viruses
• users downloading virus-infected personal
  computer programs
• Executable Content
• Java applets
• ActiveX Controls
• JavaScript, VBScript
• End to End Encryption
• Tunneling/Encapsulation

22
Other Issues

• Throughput potential bottleneck (all connections
  must pass through firewall)
• Single point of failure concentrates security in
  one spot gt compromised firewall is disaster
• Complexity - feature bloat
• Some services do not work well with firewalls
• Lack of standard performance measurements or
  techniques

23
Firewall Components

• Firewall Administrator
• Firewall policy
• Packet filters
• transparent
• does not change traffic, only passes it
• Proxies
• Active
• Intercepts traffic and acts as an intermediary

24
Firewall Administrator

• Knowledge of underpinnings of network protocols
  (ex. TCP/IP, ICMP)
• Knowledge of workings of applications that run
  over the lower level protocols
• Knowledge of interaction between firewall
  implementation and traffic
• Vendor specific knowledge

25
Firewall Policy

• High-level policy service access policy
• Low-level policy firewall design policy

Firewall policy should be flexible!
26
Service Access Policy

• Part of the Network Security Policy
• Defines
• TCP/IP protocols
• Services that are allowed or denied
• Service usage
• Exception handling

27
Service Access Policy

• Goal Keep outsiders out
• Must be realistic and reflect required security
  level
• Full security v.s. full accessibility

28
Firewall Design Policy

• Refinement of service access policy for specific
  firewall configuration
• Defines
• How the firewall achieves the service access
  policy
• Unique to a firewall configuration
• Difficult!

29
Firewall Design Policy

• Approaches
• Open system Permit any service unless
  explicitly denied (maximal accessibility)
• Closed system Deny any service unless
  explicitly permitted (maximal security)

30
Simple Packet Filters

• Applies a set of rules to each incoming IP packet
  to decide whether it should be forwarded or
  discarded.
• Header information is used for filtering ( e.g,
  Protocol number, source and destination IP,
  source and destination port numbers, etc.)
• Stateless each IP packet is examined isolated
  from what has happened in the past.
• Often implemented by a router (screening router).

31
Simple Packet Filter
Private Network
Placing a simple router (or similar hardware)
between internal network and outside Allow/proh
ibit packets from certain services
Packet-level rules
Packet Filter
Outside
32
Simple Packet Filters

• Advantages
• Does not change the traffic flow or
  characteristics passes it through or doesnt
• Simple
• Cheap
• Flexible filtering is based on current rules

33
Simple Packet Filters

• Disadvantages
• Direct communication between multiple hosts and
  internal network
• Unsophisticated (protects against simple attacks)
• Calibrating rule set may be tricky
• Limited auditing
• Single point of failure

34
Stateful Packet Filters

• Called Stateful Inspection or Dynamic Packet
  Filtering
• Checkpoint patented this technology in 1997
• Maintains a history of previously seen packets to
  make better decisions about current and future
  packets
• Check out
• Stateful Inspection Technology at
  http//www.sofaware.com/html/Stateful_Inspection.p
  df
• Firewall Security Requirements at
  http//www.sofaware.com/html/tech_stateful.shtm

35
Proxy Firewalls
View
Reality
Private Network
Private Network
Proxy Server
Outside
Outside
36
Proxy Firewalls

• Application Gateways
• Works at the application layer ? must understand
  and implement application protocol
• Called Application-level gateway or proxy server
• Circuit-Level Gateway
• Works at the transport layer
• E.g., SOCKS

37
Application Gateways

• Interconnects one network to another for a
  specific application
• Understands and implements application protocol
• Good for higher-level restrictions

Server
Client
Application Gateway
38
Application Gateways

• Advantages by permitting application traffic
  directly to internal hosts
• Information hiding names of internal systems are
  not known to outside systems
• Can limit capabilities within an application
• Robust authentication and logging application
  traffic can be pre-authenticated before reaching
  host and can be logged
• Cost effective third-party software and hardware
  for authentication and logging only on gateway
• Less-complex filtering rules for packet filtering
  routers need to check only destination
• Most secure

39
Application Gateways

• Disadvantages
• Keeping up with new applications
• Need to know all aspects of protocols
• May need to modify application client/protocols

40
Circuit-Level Gateways

• Is basically a generic proxy server for TCP
• Works like an application-level gateway, but at a
  lower level
• SOCKS most widely know circuit-level gateway

41
Circuit-Level Gateways

• Advantages
• Dont need a separate proxy server for each
  application
• Provides an option for applications for which
  proxy servers dont yet exist
• Simpler to implement than application specific
  proxy servers
• Most Open-Source packages can be easily extended
  to use SOCKS

42
Circuit-Level Gateways

• Disadvantages
• No knowledge of higher level protocols cant
  scan for active content or disallowed commands
• Can only handle TCP connections new extensions
  proposed for UDP
• Proprietary packages, TCP/IP stacks must be
  modified by vendor to use circuit-level gateways

43
Checkpoint Firewall

• Check out
• Check Point Firewall-1
• http//www.tribecaexpress.com/checkpoint.htm
• PhoneBoys Firewall-1 FAQ
• http//phoneboy.com/
• Tiny Personal Firewall (free windows firewall)
• http//www.tinysoftware.com/home/tiny?s3190706199
  471800831A2pgtpf_summary

44
Firewall Evaluation

• Level of protection on the private network ?
• Prevented attacks
• Missed attacks
• Amount of damage to the network
• How well the firewall is protected?
• Possibility of compromise
• Detection of the compromise
• Effect of compromise on the protected network
• Ease of use
• Efficiency, scalability, redundancy
• Expense
