Utility and Collection Classes

1
Utility and Collection Classes

• CSC 313 Course Notes by
• Linda M. Hicks

2
Utility Classes

• In this chapter you will learn
• What the Enumeration interface is used for
• What a Vector is and how to use Vector objects in
  your programs
• How to manage Vector objects so that storing and
  retrieving elements is type safe
• What a Stack is and how you use it
• What facilities the Random class provides
• How to create and use Date objects

3
Utility Classes

• In this chapter you will learn
• How you store and retrieve objects in a hash
  table represented by a Hashtable object
• How you can generate hash codes for your own
  class objects
• How to use the Observable class and the Observer
  interface to communicate between objects
• What facilities the Random class provides
• How to create and use Date objects

4
Java.util Package
Key
5
The java.util Package

• The package java.util contains a number of
  useful classes and interfaces. Some of the
  classes and interfaces in java.util include
• The Hashtable class for implementing hashtables,
  or associative arrays.
• The Vector class, which supports variable-length
  arrays.
• The Enumeration interface for iterating through a
  collection of elements.

6
The java.util Package Cont.

• The StringTokenizer class for parsing strings
  into distinct tokens separated by delimiter
  characters.
• The EventObject class and the EventListener
  interface, which form the basis of the AWT event
  model in Java 1.1.
• The Calendar and TimeZone classes in Java. These
  classes interpret the value of a Date object in
  the context of a particular calendar system.

7
Utility Classes

• The utility classes are primarily a set of tools
  for storing and managing data in memory in a
  variety of ways, plus some other odds and ends.
• If you want an array that automatically expands
  to accommodate however many objects you throw
  into it, or you need to be able to store and
  retrieve an object based on what it is, rather
  than using an index or a sequence number, then
  look no further.
• You get all this and more in the java.util
  package.

8
Utility Classes
9
The Enumeration Interface

• An enumeration is a collection of objects that
  can be retrieved serially-traveling in one
  direction through the data. Since an enumeration
  is intended for one time use, it's usually
  created on demand by a collection of elements,
  such as a Vector or a Hashtable. You just ask the
  collection to create a new Enumeration object
  whenever you want to iterate through the objects
  you have stored in that collection.
• The Enumeration interface only declares two
  methods

10
The Enumeration Interface

• The Enumeration interface only declares two
  methods

11
Enumeration Interface nextElement()

• Because the nextElement() method returns an
  object of type Object, it can return any type of
  object and is thus completely general.
• However, when you retrieve an element, you'll
  usually want to cast the reference returned to
  the original type of the object.
• We will see how you use these methods to retrieve
  objects when we get into using Vector objects.

12
The Vector Class

• The Vector class defines a collection of elements
  of type Object that works like an array, but with
  the additional feature that it can grow itself
  automatically when you need more capacity.
• Because it stores elements of type Object, and
  Object is a superclass of every object, you can
  store any type of object in a Vector.
• Keep in mind that all the storage classes you're
  about to encounter hold object references.

13
Vector Constructors

• There are three constructors for the Vector
  class
• Vector ()
• Vector (int capacity)
• Vector (int capacity, int increment)
• Where capacity specifies than in initial
  number of elements for which to reserve space,
  and increment indicates how much the capacity
  should be incremented every time the Vector must
  grow.

14
Vector Class Size Capacity
15
Vector Example Program

• import java.io.
• import java.util.
• class vectorEx
• static BufferedReader keyboard new
• BufferedReader(new InputStreamReader(S
  ystem.in))
• static PrintWriter screen new
  PrintWriter(System.out, true)
• static public void main(String args) throws
  IOException
• final int INITIAL_SIZE 4
• Vector wordList new Vector(INITIAL_SIZE)
• int sizeOfVector, capOfVector, midIndex
• String word
• screen.println("Input single words, one per
  line, type EXIT to
• quit\n")

16
Vector Example Program

• screen.print("Word? ") screen.flush()
• word keyboard.readLine()
• while (! word.equals("EXIT"))
• wordList.addElement(word)
• screen.println ( "capacity "
  wordList.capacity() " size "
• wordList.size() " index "
• wordList.indexOf(word) "
  contents word )
•
• screen.print ("Word? ") screen.flush()
• word keyboard.readLine()

17
Vector Example Program

• screen.println("\nsize of vector "
  wordList.size() )
• screen.println("capacity of vector "
  wordList.capacity())
• screen.println("first element "
  wordList.firstElement())
• screen.println("last element "
  wordList.lastElement())
•
• midIndex wordList.size() / 2
• screen.print ("middle element at index "
  midIndex " is "
• wordList.elementAt(midIndex))

•   wordList.trimToSize()
• capOfVector wordList.capacity()
• screen.println("\ntrimmed size capacity "
  capOfVector)
•
• screen.println("\nContents of Vector")
• for (int index0 index ! capOfVector
  index)
• screen.print( wordList.elementAt(index)
  " ")
• screen.flush()

18
Example Program Output

• Input single words, one per line, type EXIT to
  quit
• Word? lime capacity 4 size 1 index 0
  contents lime
• Word? pear capacity 4 size 2 index 1
  contents pear
• Word? apple capacity 4 size 3 index 2
  contents apple
• Word? grape capacity 4 size 4 index 3
  contents grape
• Word? lemon capacity 8 size 5 index 4
  contents lemon
• Word? peach capacity 8 size 6 index 5
  contents peach
• Word? mango capacity 8 size 7 index 6
  contents mango
• Word? cherry capacity 8 size 8 index 7
  contents cherry
• Word? orange capacity 16 size 9 index 8
  contents orange
• Word? banana capacity 16 size 10 index 9
  contents banana
• Word? tangerine capacity 16 size 11 index 10
  contents tangerine
• Word? pineapple capacity 16 size 12 index 11
  contents pineapple
• Word? blueberry capacity 16 size 13 index 12
  contents blueberry
• Word? raspberry capacity 16 size 14 index 13
  contents raspberry
• Word? watermelon capacity 16 size 15 index 14
  contents watermelon
• Word? cantaloupe capacity 16 size 16 index 15
  contents cantaloupe
• Word? strawberry capacity 32 size 17 index 16
  contents strawberry

19
Example Program Output

• Word? EXIT
• size of vector 18
• capacity of vector 32
• first element lime
• last element grapefruit
• middle element at index 9 is banana
• trimmed size capacity 18
•
• Contents of Vector
• lime pear apple grape lemon peach mango
  cherry orange banana tangerine pineapple
  blueberry raspberry watermelon cantaloupe
  strawberry grapefruit

20
Accessing Elements through an Enumeration

• We can replace the for loop in this program
• for (int index0 index ! capOfVector index)
• screen.print( wordList.elementAt(index) "
  ")
• screen.flush()
• with the following enumerator

21
Accessing Elements through an Enumeration

• // create an enumeration object to retrieve all
• // elements stored in vector.
• Enumeration theData wordList.elements()
• while (theData.hasMoreElements() )
• String theWord (String) theData.nextElement()

• System.out.println (theWord)
• screen.flush()

22
Accessing Elements through an Enumeration

• Enumeration theData wordList.elements()
• The method elements() returns all the elements
  in the Vector object, wordList, as an Enumeration
  object, so you can now process them serially
  using the methods declared in the Enumeration
  interface.
• while (theData.hasMoreElements() )
• When we've retrieved the last element from
  the Enumeration, the method hasMoreElements()
  will return false and the loop will end.

23
Removing items from a Vector

• Removing items by position
• You can remove the reference at a particular
  index position by calling the removeElementAt()
  method with the index position of the object as
  the argument. For example,
• wordList.removeElementAt(3)
• will remove the fourth reference from wordList.
  The references following this will now be at
  index positions that are one less than they were
  before, so that what was previously the fifth
  object reference will now be at index position 3.

• Of course, the index value that you specify must
  be legal for the Vector on which you're
  operating, meaning greater than or equal to 0 and
  less than its size(), otherwise an exception will
  be thrown.

24
Removing items from a Vector

• Removing items by reference
• Sometimes you'll want to remove a particular
  reference, rather than the reference at a given
  index. If you know what the object is that you
  want to remove, you can use the removeElement()
  method to delete it
• boolean deleted  wordList.removeElement(aWord)
• This will search the Vector, wordList, from the
  beginning to find the reference to the object
  aWord, and remove its first occurrence. If the
  object is found and removed, the method returns
  true, otherwise it returns false.

25
Removing all items from Vector

• If you want to discard all the elements in a
  Vector, you can use the removeAllElements()
  method to empty the Vector in all at once
• wordList.removeAllElements()    // Dump the whole
   lot

26
Searching a Vector

• You can get the index position of an object
  stored in a Vector by passing the object as an
  argument to the method indexOf(). For example,
  the statement,
• int position  wordList.indexOf(aWord)
• will search the Vector from the beginning for the
  object aWord. The variable position will either
  contain the index of the first reference to the
  object in wordList, or -1 if the object isn't
  found.

27
Searching a Vector

• You have another version of the method indexOf()
  available that accepts a second argument which is
  an index position where the search for the object
  should begin.
• The main use for this arises when an object can
  be referenced more than once in a Vector. You can
  use the method to recover all occurrences of any
  particular object, as follows

28
Searching a Vector

• int position  0                      // Search s
  tarting index
• while(positionltwordList.size() )   // Search with
  a valid index
•   position  transactions.indexOf
  (aTransaction, position)
• // Find next
•   if (position -1)               // If object no
  t found...
•     break                             // ...end t
  he loop
•   // Code to process the object in some way...
•   position                     // Search from t
  he next element

29
Searching a Vector
The while loop will continue as long as the
method indexOf() returns a valid index value and
the index doesn't get incremented beyond the end
of the Vector.
30
Stack Storage
31
Stack Storage
32
Stack Constructor

• The only constructor for a Stack object is the
  default constructor.
• This will call the default constructor for the
  base class, Vector, so you'll always get an
  initial capacity for 10 objects, but since it's
  basically a Vector, it will grow automatically in
  the same way.

33
Hash Table Storage

• A hash table, sometimes referred to as a map, is
  a way of storing data that minimizes the need for
  searching when you want to get an object back.
• Each object is associated with a key which is
  used to determine where to store the reference to
  the object, and both the key and the object are
  stored in the hash table.
• Given a key, you can always go more or less
  directly to the object that has been stored in a
  hash table based on the key.

34
Hash Table Storage

• In Java, hash tables are implemented by the class
  Hashtable.
• The keys used to store objects in a Hashtable
  object are objects too, but the object that you
  use as a key doesn't have to be the same as the
  object that you're storing-indeed it usually
  won't be.
• For example, you could use a String object
  containing a name as a key, for a Person object,
  which would typically contain all kinds of other
  information in addition to the name. If you know
  the name for a Person object, you can immediately
  retrieve that object by just supplying the name
  as the key.

35
The Hashing Process

• It's helpful to understand how the storage
  mechanism works for a hash table. A Hashtable
  object sets aside an array in which it will store
  key and object pairs.
• The index to this array, referred to as a hash
  value, is produced from the key object by a
  process known as hashing.
• This uses the hashCode() method for the object
  that's used as a key.

36
The Hashing Process

• Note that each key doesn't have to result in a
  unique hash value. When two or more different
  keys produce the same hash value, it's called a
  collision.
• The Hashtable object is able to deal with
  collisions by hooking the objects that share the
  same hash value together in a linked list, as
  shown below. For the sake of simplicity, the
  diagram only shows the objects stored in the
  table, but the key for each object is also
  stored.

37
The Hashing Process
38
The Hashing Process
39
The Hashing Process

• Generally, the better the uniqueness of the hash
  values, the more efficient the operation of the
  hash table is going to be.
• When you access one of the objects that share a
  common hash value, it will involve a serial
  search of the list of keys corresponding to that
  hash value.
• The price of reducing the possibility of
  collisions in a hash table is having plenty of
  empty space in the table.
• The class Object defines the method hashCode() so
  any object can be used as a key, and it will hash
  by default, but the method as it is currently
  implemented in Object in Java 1.1 isn't ideal.

40
The Hashing Process

• Since it uses the address where an object is
  stored to produce the hash value, distinct
  objects will always produce different hash
  values. This is a plus because it is more likely
  that a unique hash value will be produced for
  each key. The huge minus is that objects which
  use this default behavior and that are distinct,
  but have identical contents, will produce
  different hash values.
• The effect of this is disastrous if you use this
  default for objects of your own classes that
  you're using as keys.
• In this case, an object stored in a hash table
  can never be retrieved using an object for a key
  that is distinct from the original key object,
  even though it may be identical in all other
  respects.

41
Using your own Class Objects as Keys

• For objects of one of your own classes to be
  usable as keys in a hash table, you must
  implement two methods in the class the equals()
  method which accepts an object of the same class
  as an argument, and returns a boolean value and
  hashCode() which returns the hash value for the
  object as type int. You'll be overriding the
  versions of these methods that are inherited from
  the class Object.

42
Hashtable Constructors
43
Storing and Retrieving Objects
44
Hashtable

• All objects in a hash table are stored as type
  Object.
• As with objects stored in a Vector, you can cast
  an object back to its original type when you
  retrieve it.
• Every object in a hash table must have a unique
  key. (Don't confuse the key with the hash code
  though. Even though all the keys are unique, the
  hash codes may not be. This will result is
  several object/key pairs jostling for the same
  position in the table. This will be taken care of
  under the covers by linking them together in a
  list.)
• You should check that the value returned from the
  put() method is null. If it isn't, you are
  displacing an object that was stored in the table
  earlier using the same key

45
Using your own Class Objects as Keys

• The equals() method is used by methods in the
  Hashtable class to determine when two keys are
  equal, so your version of this method should
  return true when two different objects are equal
  keys. This will generally amount to writing the
  method so that it returns true when the data
  members for the two objects that are used in the
  hashCode() method are identical.

46
Hashtable Example Code

• Hashtable theTable  new Hashtable()
• Hashtable myTable  new Hashtable(151)
• Hashtable aTable  new Hashtable(151, 0.6f)
•  // 60 load factor
• String myKey  "Goofy"
• Integer theObject  new Integer(12345)
• if (aTable.put (myKey, theObject) ! null
•   System.out.println("Uh-oh, we bounced an object.
  ..")

47
Hashtable Example Code cont.

• Note that the get() operation will return the
  object corresponding to a key, but it does not
  remove it from the table. To retrieve an object
  and delete it from the table, you must use the
  remove() method. This accepts a key of type
  Object as an argument, and returns the object
  corresponding to the key
• theObject  (Integer) aTable.remove(theKey)
• If there's no object stored corresponding to
  theKey, null will be returned. If theKey is null,
  the remove() method will throw NullPointerExceptio
  n. Note how we have to explicitly cast the object
  returned from the hash table to the correct
  class.

48
Processing all Elements in a Hash Table

• You can obtain an Enumeration for either of the
  objects or the keys in a hash table.
• The method elements() returns an Enumeration
  referencing the objects stored, and the method
  keys() returns an enumeration referencing the
  keys for those objects.
• You then have the choice of iterating through the
  keys, which you can use with the get() method to
  obtain the corresponding objects, so you have
  both the keys and the objects available to you,
  or using the elements() method and the
  Enumeration returned, when you only want to
  iterate through the objects.

49
Processing Hashtable Elements

• Enumeration theKeys  theTable.keys()   // Get th
  e keys
• Name key
      // Store a key
• while(theKeys.hasMoreElements())
•   key  (Name)theKeys.nextElement()     // Get ne
  xt key
•   // Output the key and the person
•   System.out.println("Key "  key  "\nPerson "

•
   theTable.get(key))

50
Other Hashtable Operations

• Remove all the objects references from a
  Hashtable object
• theTable.clear()       // Empty the hash tab
  le
• The Hashtable class has methods capacity() and
  size() to return the current capacity of the
  table, and the number of objects stored in it.
• You also have the isEmpty() method available
  which returns true if no objects are stored in a
  Hashtable object.

51
Other Hashtable Operations

• There are two methods which enable you to check
  whether an object is in a hash table.
• The method contains() returns true if the object
  passed as an argument is referenced at least once
  in the table.
• The method containsKey() returns true if the key
  object passed as an argument has been stored
  along with its associated object.
• Both are determined using the equals() method for
  the object passed as an argument, so if you want
  this to work properly when you reference objects
  of your own class, you'll need to have
  implemented the equals() method for your class.

52
Hashtable Program Examples

• See example programs from previous version of
  text
• Name.java
• Person.java
• TryHashTable.java

53
Thats All Folks!
