PROTECT 3.M 15

1
PROTECT 3.M 15 120kVA
2
PROTECT 3.M the new generation
of uninterruptible power supplies (UPS)
with 3-phase Mains input and 3-phase Mains
output
3
PROTECT 3.M General data

• PROTECT 3.M will be offered in two cubicle
  variances.
• Variance 1
• Cubicle dimensions (W x H x D) 600mm x 1600mm x
  1000mm
• Maximum 6 modules each 15kVA 90kVA per cubicle
• Variance 2
• Cubicle dimensions (W x H x D) 600mm x 2000mm x
  1000mm
• Maximum 8 modules each 15kVA 120kVA per
  cubicle
• 15kVA per Modul (hot-swappable)
• Degree of redundancy selectable via Display
• Each Modul is independent , Controllcard/Display
  are just for Communication and Indication.
• Integrated Distribution with up to 36 breakers as
  an option
• LCD Display
• Communication via RS232, RS485, SNMP AS400

4
PROTECT 3.M General data
1.6 m cubicleMB at the bottom
2.0 m cubicleMB at the top
5
PROTECT 3.M

• High MTBF ability
• Each UPS module in the Protect 3.M is the
  full function UPS. There is no additional
  controlling module to the parallel application
  and load sharing. Regarding to the serious
  calculation on the system MTBF, if you have two
  more UPS modules for parallel redundancy, the
  system ability is above 99.999 and the MTBF
  will be close to 15 Million Hours.
• MTTR
• Once the system has one more UPS module for
  parallel redundancy, the system will still
  keepworking if one of the UPS modules fails. If
  the failed modules exceed the parallel redundancy
  modules, the module replacement procedure only
  need 5 minutes for system recover.

6
PROTECT 3.M Battery

• Battery
• /- 240Volt DC (20 bloc for each
  string)Integrated batteriecharger in each Module
  (2700W / 4.5A)
• Battery Management in two stepsStep 1) up to
  90 battery capacity ? constant currentStep 2)
  above 90 capacity? constant voltage

7
PROTECT 3.M Technical data part I
Classification VFI SS 111 acc. to IEC 62040-3 Protect 3.M 1.6m rack Protect 3.M 2.0m rack
Type power 90 kVA 120kVA
  72 kW 96 kW
max. modules per rack 6 8
UPS-input UPS-input UPS-input
Input voltage 400 / 230Vac (3/N/PE) 400 / 230Vac (3/N/PE)
Input voltage range without battery mode 277 - 520Vac(3ph) 277 - 520Vac(3ph)
Frequency 50 Hz / 60Hz 50 Hz / 60Hz
Current consumption (max.)  120A with 6 modules  160A with 8 modules
Power factor gt 0.99 at 100 Load gt 0.99 at 100 Load
THD(i) lt5 lt5
UPS-output UPS-output UPS-output
Rated output voltage 400V 2 400V 2
Frequency in battery mode 50 Hz 0.5 50 Hz 0.5
Output current 22 A / per module 132A with 6 modules 22 A / per module 176A with 8 modules
Transfer time at mains outage 0 ms ( zero transfer ) 0 ms ( zero transfer )
Voltage waveform Sinusoidal Sinusoidal
Overload response (online mode) 130 for 10min / 150 for 1min 130 for 10min / 150 for 1min
Crest factor 3 3
8
PROTECT 3.M Technical data part II
Battery Battery
Nominal voltage 240VDC (40pcs for each set in series connection. One battery neutral wire from the central)
Autonomy time Free to choose runtime extension with scalable external battery. Available configurations with 24,38 or 65 Ah)
Overload / deep discharge protection Yes
Communication
Interfaces RS232 / RS485 for status and measurement values, Communication slot ( for pot.-free contacts or SNMP adapter)
Shutdown software (on CD) Included for all typical operating systems (e.g. MS-Windows,Novell Netware,Mac OS,Linux,Unix derivates, etc.)
Failure indicators (acoustic/optical) LCD with digital information of input and output parameters (voltage,frequency,power etc.) battery parameter incl. failure diagnosis by password protect level, LED for status and main failures.
9
PROTECT 3.M Technical data part III
General data General data General data
Efficiency total gt 90 gt 90
Audible noise (1m distance) lt62 dB lt62 dB
Operating temperature range 0º - 40 ºC 0º - 40 ºC
Humidity 20 - 90 20 - 90
Installation height up to 1000m, at nominal load up to 1000m, at nominal load
Equipment colour RAL 7035 RAL 7035
Size approx.W x H x D (mm) 600 x 1600 x 1000  600 x 2000 x 1000
Weight appr. (kg) 250kg rack 35kg per module 300kg rack 35kg per module
Certification CE CE
10
PROTECT 3.M Applications

• Single - and multi-user systems (
  Workstations, FileServer, Application Server, ...
  )
• Network protection (client / server
  architecture) e.g. intranet / internet
  application
• EDP - equipment (CAD - systems, ...)
• Communication equipment (IT - sector)
• Component protection of telecommunication
• Cash systems (trade)
• Other user-critical applicationen
  (process systems (stored-program contoller, ... ))

11
PROTECT 3.M conceptual highlights

• Modularity with UPS plug-in modules in
  VFI (double-conversion) technology
• n x technology free choice of
  redundancy level
• scalable design for flexible power- /
  autonomy time requirements
• central simplified management more
  efficient service
• independent UPS - modules (without any
  central control logic)

12
PROTECT 1.M UPS classes
Voltage Phenomenon
Time e. g. IEC
UPS solution



62040-3
1. 2. 3. 4. 5. 6. 7. 8. 9. 10.
Outage - blackouts Sags / brownouts Dynamic
overvoltage Undervoltage Overvoltage Lightning Tra
nsients (Surge) Frequency variations Voltage
distortion (Burst) Voltage harmonics
gt 10 ms continuous continuous sporadic lt 4
ms sporadic periodic continuous
VFD Voltage Frequency Dependent VI Voltage Indep
endent VFI Voltage Frequency Independent
Classification 3 Offline Classification
2 LineInteractive Classification 1 (true)
Online real Double- Conversion
Publication by ZVEI UPS Guide
........... by additional
lightning arrestors
13
Protect 3.M System architecture
Integrated Distribution with up to 36 breakers as
an option Communication module incl.
communication port LCD-Display UPS-modules
each 15kVA
14
PROTECT 3.M UPS module design
Diagram of an UPS PROTECT module

• High power reserves as a result of a max. 24
  kVAtotal output
• High safety reserves asa result of nx technology

• Independent UPS modules (no central control)
  slide-in types suitable for rackmount

15
PROTECT 3.M n x technology redundancy
level
Quantity of UPS modules 1 2 3 4 5 6 7 8
Load modul modules modules modules modules modules modules modules
15 kVA noredundancy n 1 (15 kVA) n 2 (30 kVA) n 3 (45 kVA) n 4 (60 kVA) n 5 (75 kVA) n 6 (90 kVA) n 7 (105 kVA)
30 kVA   noredundancy n 1 (15 kVA) n 2 (30 kVA) n 3 (45 kVA) n 4 (60 kVA) n 5 (75 kVA) n 6 (90 kVA)
45 kVA     noredundancy n 1 (15 kVA) n 2 (30 kVA) n 3 (45 kVA) n 4 (60 kVA) n 5 (75 kVA)
60 kVA - - -     noredundancy n 1 (15 kVA) n 2 (30 kVA) n 3 (45 kVA) n 4 (60 kVA)
75 kVA   - - -     noredundancy n 1 (15 kVA) n 2 (30 kVA) n 3 (45 kVA)
90 kVA     - - -     noredundancy n 1 (15 kVA) n 2 (30 kVA)
105 kVA       - - - - - - - - - noredundancy n 1 (15 kVA)
120 kVA             - - - noredundancy
n x technologyadvantage

• Higher reliability
• Easy to increase overall capacity
• Modules hot - swapable (without any
  interruption)

16
Protect 3.M Usage gtgt Delivery
Cubicle packing
Module packing
17
Protect 3.M - Mains connection
Mains
Battery
Load
18
PROTECT 3.M LCD display
Appear green light Appear yellow
light Appear yellow light Appear red
light and warning alarm
19
PROTECT 3.M Communication interface

• Dual monitoring interface
• from left to the right
• - RS485
• RS485
• RS232
• - RS485

20
PROTECT 3.M SNMP-Adapter

• SNMP Slot-Adapter for UPS

• Features
• Agent for RFC1628 MIB UPS standard MIB
• Embedded Web-Server
• Monitoring via Web
• Configuration via Web
• Embedded Event Manager
• Start of different Jobs
• Net Broadcast
• E-Mail
• Monitoring of environmental conditions
• Temperature, Humidity, GenSet, Fire, Air
  condition, Smoke shutter...
• Support Software products
• Network Management Software NMS
• NMS special for Power Supply Systems
• Shutdown Software CompuWatch
• Direct multi-server shutdown of different OS with
  communication modules

SNMP Adapter Pro 6000001271 SNMP Adapter
6000004036
21
PROTECT 3.M AS/400 slotcard
Pin- assignment Description

1 UPS Failure
2 Summary alarm (signal of pins 1, 7and 9)
3 Emergency shutdown, e.g. connection of an external switch for EPO (closer)
4 Emergency shutdown, e.g. connection of an external switch for EPO (closer)
5 Common ground for pins 1, 2, 6, 7, 8 und 9
6 Bypass active
7 Battery low
8 UPS on
9 Utility Failure
Pin 1 UPS Fault Battery below cutoff
voltage Pin 2 Summary Alarm UPS failure,
Utility power failure, Battery low Pin 3 and
4 Short from Pin 3 to 4 generates an UPS
shutdown, e.g. by installing an external switch
for EPO. Pin 5 Common ground for relays (pins 1,
2, 6, 7, 8 und 9) Pin 6 Bypass active mains
operationPin 7 Battery low Battery voltage is
below the predetermined level Pin 8 UPS on
normal operation (relay closed during normal
operation) Pin 9 Utility Failure battery
operation Attention ! Contact load rating AC
/ DC ? 24 V / 0,5 A
22
UPS system PROTECT 3.M

• Graphical front-end of CompuWatch
  Normal operation

23
PROTECT 3.M
