Bayesian networks
2
Motivation

• We saw that the full joint probability can be
  used to answer any question about the domain, but
  can become intractable as the number of variables
  grow.
• Furthermore specifying probabilities of atomic
  events is rather unnatural and can be very
  difficult unless a large amount of data is
  available from which to gather statistics.
• Human performance, by contrast, exhibits a
  different complexity ordering probabilistic
  judgments on conditional statements involving a
  small number of propositions are issued swiftly
  and reliably, while judging the likelihood of a
  conjuction of many propositions is done with a
  great degree of difficulty and hesitancy.
• This suggests that the elementary building blocks
  which make up human knowledge arent the entries
  of joint probability table but, rather, the
  low-order conditional probabilities defined over
  small clusters of propositions.

3
Bayesian networks

• A simple, graphical notation for conditional
  independence assertions and hence for compact
  specification of full joint distributions.
• Syntax
• a set of nodes, one per variable
• a directed, acyclic graph (a link means
  "directly influences")
• a conditional distribution for each node given
  its parents
• P (Xi Parents (Xi))
• The conditional distribution is represented as a
  conditional probability table (CPT) giving the
  distribution over Xi for each combination of
  parent values.

4
Example

• Topology of network encodes conditional
  independence assertions
• Weather is independent of the other variables
• Toothache and Catch are conditionally independent
  given Cavity, which is indicated by the absence
  of a link between them.

5
Another Example

• I'm at work, neighbor John calls to say my alarm
  is ringing, but neighbor Mary doesn't call.
  Sometimes it's set off by minor earthquakes. Is
  there a burglar?
• Variables Burglary, Earthquake, Alarm,
  JohnCalls, MaryCalls
• Network topology reflects "causal" knowledge
• A burglar can set the alarm off
• An earthquake can set the alarm off
• The alarm can cause Mary to call
• The alarm can cause John to call

6
Example contd
The topology shows that burglary and earthquakes
directly affect the probability of alarm, but
whether Mary or John call depends only on the
alarm. Thus our assumptions are that they dont
perceive any burglaries directly, and they dont
confer before calling.
7
Compactness of Conditional Probability Tables
(CPTs)

• A CPT for Boolean Xi with k Boolean parents has
  2k rows for the combinations of parent values
• Each row requires one number p for Xi true(the
  number for Xi false is just 1-p)
• If each variable has no more than k parents, the
  complete network requires O(n 2k) numbers

• I.e., grows linearly with n, vs. O(2n) for the
  full joint distribution
• For burglary net, 1 1 4 2 2 10 numbers
  (vs. 25-1 31)

8
Semantics

• The full joint distribution is defined as the
  product of the local conditional distributions

• P(x1, ,xn)
• ?i 1 P(xi parents(xi))
• e.g.,
• P(j ? m ? a ? ?b ? ?e)
• P(j a) P(m a) P(a ?b, ?e) P(?b) P(?e)

9
Constructing Bayesian networks

• 1. Choose an ordering of variables X1, ,Xn
• 2. For i 1 to n
• add Xi to the network
• select parents from X1, ,Xi-1 such that
• P(Xi Parents(Xi)) P(Xi X1, ... Xi-1)
• This choice of parents guarantees
• P(X1, ,Xn) ?i 1 P(Xi X1, , Xi-1)
  (chain rule)
• ?i 1P(Xi Parents(Xi))(by construction)

10
Example

• The ordering of variables is very important.
• E.g. suppose we choose the ordering M, J, A, B, E
• Adding MaryCalls No parents
• P(JM) P(J)?
• Is P(John calling) independent of P(Mary
  calling)?
• Clearly not, since, on any given day, if Mary
  called, then the probability that John called is
  much better than the background probability that
  he called.
• So, we add a link from MaryCalls to JohnCalls.

11
Example

• Suppose we choose the ordering M, J, A, B, E
• Adding the A (Alarm) node Is
• P(A J, M) P(A J)?
• P(A J, M) P(A)?
• No.
• Clearly, if both call, its more likely that the
  alarm has gone off that if just one or neither
  call, so we need both MaryCalls and JohnCalls as
  parents.

12
Example

• Suppose we choose the ordering M, J, A, B, E
• Adding B (Burglary) node Is
• P(B A, J, M) P(B A)?
• P(B A, J, M) P(B)?
• Yes for the first. No for the second.
• If we know the alarm state, then the call from
  John or Mary might give us information about the
  phone ringing or Marys music, but not about
  burglary.
• So, we need just Alarm as parent.

13
Example

• Suppose we choose the ordering M, J, A, B,
  E

• Adding E (Earthquake) node Is
• P(E B, A ,J, M) P(E A)?
• P(E B, A, J, M) P(E A, B)?
• No for the first. Yes for the second.
• If the alarm is on, it is more likely that there
  has been an earthquake.
• But if we know there has been a burglary, then
  that explains the alarm, and the probability of
  an earthquake would be only slightly above
  normal.
• Hence we need both Alarm and Burglary as parents.

14
Example contd

• So, the network is less compact if we go
  non-causal 1 2 4 2 4 13 numbers needed
  instead of 10 if we go in causal direction.

• Deciding conditional independence is hard in
  noncausal directions

• Causal models and conditional independence seem
  hardwired for humans!


15
So

• Bayesian networks provide a natural
  representation for (causally induced) conditional
  independence
• Topology CPTs compact representation of
  joint distribution
• Generally easy for domain experts to construct

16
Noisy-OR

• Even if the maximum number of parents k is small,
  filling the CPT for a node is tedius.
• Uncertain relationships can often be
  characterized by so-called noisy OR relation,
  which is generalization of logical OR.
• In propositional logic, we might say that Fever
  is true if Cold, Flu, or Malaria is true.
• The noisy-OR allows for uncertainty about the
  ability of each parent cause to cause the child
  to be true.
• The causal relationship may be inhibited, and so
  a patient could have cold, but not exhibit fever.

• So, suppose we managed to find out the
  probabilities of inhibitions
• P(?fever cold, ?flu, ?malaria) 0.6
• P(?fever ?cold, flu, ?malaria) 0.2
• P(?fever ?cold, ?flu, malaria) 0.1
• Now, we can easily construct the truth table

17
Observe that by using the noisy-OR we needed to
specify 3 entries only instead of 8. In general,
for k parents, we need to specify k entries
instead of 2k.
18
Exact Inference in Bayesian Networks

• The basic task for any probabilistic inference
  system is to compute the posterior probability
  for a set of query variables, given some observed
  event that is, some assignment of values to a
  set of evidence variables.
• Notation
• X denotes query variable
• E denotes the set of evidence variables E1,,Em,
  and e is a particular event, i.e. an assignment
  to the variables in E.
• Y will denote the set of the remaining variables
  (hidden variables).
• A typical query asks for the posterior
  probability P(Xxe), i.e. P(xe1,,em).
• E.g. We could ask Whats the probability of a
  burglary if both Mary and John calls, P(burglary
  johhcalls, marycalls)?

19
Inference by enumeration

• Slightly intelligent way to sum out variables
  from the joint without actually constructing its
  explicit representation

20
Numerically
Complete it for exercise

• P(b j,m) ? P(b) ?e P(e)?aP(ab,e)P(ja)P(ma)
  ? 0.00059
• P(?b j,m) ? P(?b) ?eP(e)?aP(a?b,e)P(ja)P(ma
  ) ? 0.0015
• P(B j,m) ? lt0.00059, 0.0015gt lt0.284, 0.716gt.
