Title: Lecture 7: New toolkit input models: Garnet


1
Lecture 7New toolkit input modelsGarnet
Amulet
  • Brad Myers
  • 05-830Advanced User Interface Software

2
Overview
  • Try to provide more support so input handling
    isn't so difficult
  • Make easy things simple and complex things
    possible
  • Based on the "Model-View-Controller" architecture
    from Smalltalk
  • True separation of graphics (view) and input
    handling (controller)
  • Also uses idea from FoleyWallace of identifying
    types of input handlers
  • move
  • grow
  • rotate
  • text edit
  • gesture
  • select (pick)

3
Innovations
  • Identifying primitive "Interactor" objects and
    correct parameterizations so most direct
    manipulation UIs can be constructed by re-using
    built-in objects.
  • Only a few kinds of behaviors, and standard
    parameters
  • Real separation between input and output handling
  • Handles all input
  • insides of widgets
  • and for application programs
  • First successful separation of View from
    Controller in Smalltalk MVC
  • Integration of gestures with conventional
    interaction.
  • Easier to code because substantial re-use
  • Built-in support for multi-window dragging

4
General idea
  • Attach interactor objects to a set of graphical
    objects to handle their input.
  • Graphical objects don't handle input
  • No "event methods" in objects
  • Instead, define invisible "Interactor" objects
    and attach them to graphics
  • Interactors can operate on multiple objects
  • Strategy pick the right type of Interactor,
    attach to the objects to be moved, fill in
    necessary slots of interactor
  • Widgets use interactors internally
  • Can have multiple interactors on an object (e.g.,
    different mouse buttons)
  • Interactors directly set slots of objects using a
    standard protocol
  • constraints can be used to map those slots into
    behaviors
  • Details of input events and event processing is
    hidden
  • Used first in Garnet, refined in Amulet.

5
Full Documentation
  • Full Amulet Manual
  • http//www-2.cs.cmu.edu/afs/cs/project/amulet/amul
    et3/manual/Amulet_ManualTOC.doc.html
  • Tutorial
  • Interactors and Command Objects

6
Types of Interactors
  • Am_Choice_Interactor select one or more of a
    set of objects
  • Am_One_Shot_Interactor - single action, like
    Choice
  • Am_Move_Grow_Interactor move or grow objects
    with the mouse
  • Am_New_Points_Interactor to create new objects
    by entering points while getting feedback "rubber
    band" objects
  • Am_Text_Edit_Interactor mouse and keyboard edit
    of text
  • Am_Gesture_Interactor interpret freehand gestures

7
Parameters for all Interactors
  • Set of objects to operate on
  • To be active, Interactor must be attached to an
    object which is (recursively) attached to the
    screen
  • Equivalent to visibility of graphical objects
  • Unlike graphical objects which can only be added
    as parts of windows or groups, interactors can be
    added as parts of any object rect.Add_Part(my_in
    ter)
  • Default operates on the object attached to
  • But also common to operate on any member of a
    group.
  • Controlled by the Am_Start_Where_Test slot, which
    should contain a method

8
Example Start_Where_Test
  • SP_Ship_Mover    Am_Move_Grow_Interactor.Create(
    "SP_Ship_Mover")    .Set (Am_START_WHEN,
    "LEFT_DOWN")    .Set (Am_START_WHERE_TEST,
    Am_Inter_In_Part)ship_group.Add_Part(SP_Ship_Mov
    er)

9
More standard parameters
  • Multiple groups
  • interactor can span multiple windows
  • start, stop and abort events
  • single key, mousebutton, "any" mousebutton,
    modifiers, (shift, meta...), double click, click
    vs. drag, etc.
  • active?
  • priority levels

10
Parameters for specific types of Interactors
  • For buttons (Choice Interactors)
  • how many objects to select set, toggle,
    list-toggle
  • For move-grow
  • interim feedback object (while the mouse moves)
  • if missing then object itself is modified
  • gridding
  • move or grow
  • where-attach
  • center, n, ne, nw, w ... , where-hit
  • flip if change sides
  • minimum size

11
Example
  • Am_Object feedback_circle moving_circle.Create()
      .Set (Am_LINE_STYLE, Am_Dashed_Line)  .Set
    (Am_VISIBLE, false)my_win.Add_Part
    (feedback_circle)// The definition of the
    interactor Am_Object objs_grower
    Am_Move_Grow_Interactor.Create()  .Set
    (Am_START_WHERE_TEST, Am_Inter_In_Part)  .Set
    (Am_GROWING, true)   // grow instead of move
    .Set (Am_FEEDBACK_OBJECT, feedback_circle)objs_g
    roup.Add_Part (objs_grower)

12
Parameters for New_Point
  • interim feedback object (while the mouse moves)
  • gridding
  • minimum size
  • abort if too small

13
Parameters for Text_Interactor
  • editing translation table (to map keystrokes and
    mouse into editing functions)

14
Parameters for Gesture_Interactor
  • gesture recognizer table
  • If missing, can use this to get freehand drawings

15
Simple Example
  • To make an object movable with the mouse
  • Am_Object rect Am_Rectangle.Create()
    .Set(Am_LEFT, 40) .Set(Am_TOP, 50)
    .Set(Am_FILL_STYLE, Am_Red) .Add_Part(Am_Move_Grow
    _Interactor.Create())

16
Standard Behavior
17
Operation
  • Interactors do 3 things
  • modify objects directly
  • set Am_VALUE slot of their command
  • call the command's Am_DO_METHOD
  • Can just have a constraint from an object or
    widget to the Am_VALUE of the widget
  • Method to override for application-specific
    operations
  • Fill in the UNDO_METHOD to support undo

18
Operation Picture
19
Choice Interactor
  • Three ways to get the result
  • Access the Am_INTERIM_SELECTED and Am_SELECTED
    slot of the object itself
  • By default, sets the Am_INTERIM_SELECTED and
    Am_SELECTED slots of the affected objects
  • Constraints that depend on these slots
  • Access the Am_VALUE slot of the interactor
  • Write a Am_DO_METHOD for the command object, and
    access the command object's Am_VALUE slot

20
Example
  • Am_Define_Style_Formula (line_from_selected)
    if ((bool)self.Get(Am_INTERIM_SELECTED))return
    Am_Red  else if ((bool)self.Get(Am_SELECTED))re
    turn Am_Black  else return Am_BlueAm_Object
    my_prototype Am_Line.Create().Set(Am_LINE_STYL
    E, line_from_selected)my_group
    Am_Group.Create().Add_Part(Am_Choice_Interactor.C
    reate().Set(Am_START_WHERE_TEST,
    Am_Inter_In_Part)
  • Now add instances of my_prototype to my_group
  • Also collects a list of the selected objects in
    the Am_VALUE slot of the command object in the
    interactor

21
Values
  • Value of Command in Choice Interactor set to
    object selected
  • Value of Command in button-type widgets set to
    Label of command, or Am_ID field of the command
  • Remember, label can be a string or a graphical
    object

22
Debugging Tracing
  • Can turn on tracing and get print out of which
    Interactors run and what they do
  • Options trace all, trace only setting of slots,
    trace a particular interactor, short trace (only
    which interactors run), etc.
  • Inspector just toggles inspecting all or none
  • Printout to console window

23
Example
  • ltgtltgtltgtltgtltgt LEFT_DOWN x180 y289
    time3114329169Enter GO for ltgrow_inter_in_handl
    e_185gt, state0...Checking start event against
    wanted LEFT_DOWN SUCCESSChecking start
    where..  SUCCESSltAm_Rectangle_650gtMove_Grow
    starting over ltAm_Rectangle_650gt translated
    coordinates 169,268Calculated attach point for
    non-line is Am_ATTACH_SObject
    ltgrow_inter_in_handle_185gt setting Am_VISIBLE of
    ltSel_Rect_Feedback_197gt to trueObject
    ltgrow_inter_in_handle_185gt setting
    objltSel_Rect_Feedback_197gt setting
    objltSel_Rect_Feedback_197gt LEFT90 TOP142
    WIDTH182 HEIGHT148ltgtltgtltgtltgtltgt LEFT_UP x179
    y326 time3114329838 drawonableAmulet Test
    Selection Widget(0x4015b848)Enter GO for
    ltgrow_inter_in_handle_185gt, state1...Checking
    abort event against wanted CONTROL_g
    FAILEDChecking running where..
    SUCCESSltwindowgtChecking stop event against
    wanted ANY_MOUSE_UP SUCCESSMove_Grow
    stopping over ltAm_Rectangle_650gtObject
    ltgrow_inter_in_handle_185gt setting Am_VISIBLE of
    ltSel_Rect_Feedback_197gt to falseObject
    ltgrow_inter_in_handle_185gt setting
    objltAm_Rectangle_650gt setting objltAm_Rectangle_6
    50gt LEFT79 TOP121 WIDTH182 HEIGHT185

24
Advanced Feature Priorities
  • If two interactors want to run, priorities used
    to determine which
  • Am_PRIORITY slot contains a number. Default 1
  • When running, 100 added to it
  • Inspector interactors use 300.0
  • If multiple with same priority, runs the one
    attached closer to the leaf

25
Example
26
Advanced Feature Using Slots of Interactors
  • In addition to value set into Command, a number
    of slots are set into the Interactor itself,
    which might be useful.
  • Can get the interactor as the Owner of the
    command passed to the DO_METHOD
  • Am_START_OBJECT, Am_START_CHAR, Am_FIRST_X,
    Am_FIRST_Y, Am_WINDOW, Am_CURRENT_OBJECT

27
Doing something with results Command Objects
  • Each Interactor and Widget has a Command object
    as a part in the Am_COMMAND slot
  • Instead of executing a callback function,
    interactors and widgets create a "Command Object"
    and execute its "Do" method
  • Slots of command object
  • DO_METHOD
  • UNDO_METHOD
  • REDO_METHOD (undo the undo)
  • SELECTIVE_UNDO
  • SELECTIVE_REPEAT and SELECTIVE_REPEAT_On_NEW
  • HELP for "balloon" or status line
  • LONG_HELP
  • ACTIVE (enabled) -- usually contains a constraint
  • VALUE, OLD_VALUE
  • etc.
  • Like Command Objects in MacApp, but hierarchical
  • Customize by overriding default methods

28
Handling Undo
  • Add an undo-handler to the window
  • Each command will be registered with the undo
    handler
  • Built-in types of undo handlers
  • One undo then redo, like Mac
  • Infinite undo, one redo
  • Selective undo mechanism
  • Each DO method saves necessary information for
    undo in command object

29
Selective Undo
  • Implementing selective undo not much harder than
    regular undo
  • Allocates a new command object and adds to top to
    history list
  • Semantics is based on what the user would want
  • Undo the operation in a new context means to set
    the object back to its previous value
  • Enabled if object is still available
  • Undo of create is delete
  • Redo the operation means to set the value of the
    object again create a new object
  • Also, redo on new object

30
Original Interface
31
Commands in Widgets
  • Various kinds of button panels
  • Take list of items in the Am_ITEMS slot as an
    Am_Value_List
  • Contents of list can be strings, graphical
    objects, or instances of Am_Command
  • If commands, then the Am_LABEL field is used, and
    the DO_METHOD of that command is called
  • If not commands, then DO_METHOD of the top-level
    widget is called
  • For menu_bar, Am_ITEMS slot of each top-level
    command contains Am_Value_List of the sub-commands

32
Innovations
  • Better reuse
  • Many commands are in the library and are usually
    used without change
  • Cut, Copy, Paste, Create-Object, Delete-object,
    To-Top, etc.
  • Usually can be used without change
  • Easier to customize when necessary
  • Better modularization
  • Hierarchical means each level only has to deal
    with its own actions
  • New form of selective undo, repeat
  • Includes undo/repeat of selections and scrolling
  • Single place for enabling, help, label, etc.
  • Can be computed by constraints
  • Makes scripting easier
  • End-User programming by demonstration
  • Parameterization possible without help from
    application
  • May help with CSCW
  • Executing the command on multiple machines

33
Scripting
  • Added for CHI'98
  • Not in standard release
  • Select set of commands and specify that in a
    program
  • Can parameterize actions
  • Moving selection handles
  • Forwards, backwards, left, right, up, down, in,
    out
  • Search for object of a particular type or value
  • Little or no change to application if it supports
    Selective Repeat

34
Pictures for Scripting, 1
35
Pictures for Scripting, 2
36
Pictures for Scripting, 3
Write a Comment
User Comments (0)
About PowerShow.com
